turn signal bulb SUBARU OUTBACK 2012 5.G Owners Manual

3-22Instruments and controls
& Select lever/gear position in- dicator
1) Upshift/downshift indicator (AT and CVT
models)
This indicator shows the position of the
shift lever (MT models) or select lever (AT
and CVT models). ! Upshift/downshift indicator (AT and
CVT models)
When the manual mode is selected, the
gear position indicator (which shows the
current gear selection) and the upshift/
downshift indicator light up. Refer to“ Selection of manual mode ”F 7-21. !
Gear position indicator setting (MTmodels)
The gear position indicator light can be
activated or deactivated by performing the
following procedure.
1. Turn the ignition switch to the “LOCK ”
position.
2. Press the trip knob to show “
”or
“” on the trip meter display.
The display can be switched as shown in
the following illustration by pressing the
trip knob.
*1: “” or “”and “”or “”cannot
be displayed when the ignition switch is
in the “ON ”position.
*
2: MT models only
3. To change the current setting, press
the trip knob for at least 2 seconds.
: Activated
: Deactivated NOTE .
The initial setting for your vehicle of
the gear position indicator has been set
for activation “
”at the time of
shipment from the factory. . It is not possible to change the
setting of the gear position indicator
when the ignition switch is in the “ON ”
position. Change the setting when the
ignition switch is in the “LOCK ”or
“ Acc ”position.
& Turn signal indicator lights
These lights show the operation of the turn
signal or lane change signal.
If the indicator lights do not blink or blink
rapidly, the turn signal bulb may be burned
out. Replace the bulb as soon as possible.
Refer to “Replacing bulbs ”F 11-45.
& High beam indicator light
This light shows that the headlights are in
the high beam mode.
This indicator light also illuminates when
the headlight flasher is operated.

Maintenance and serviceTires and wheels .............................................. 11-30
Types of tires ................................................... 11-30
Tire pressure monitoring system (TPMS) (if equipped) ................................................... 11-30
Tire inspection ................................................. 11-32
Tire pressures and wear ................................... 11-32
Wheel balance .................................................. 11-34
Wear indicators ................................................ 11-35
Tire rotation direction mark .............................. 11-35
Tire rotation ..................................................... 11-35
Tire replacement .............................................. 11-36
Wheel replacement ........................................... 11-37
Aluminum wheels ............................................. 11-37
Windshield washer fluid .................................. 11-37
Replacement of wiper blades .......................... 11-39
Windshield wiper blade assembly ..................... 11-39
Windshield wiper blade rubber ......................... 11-40
Rear window wiper blade assembly (Outback) ....................................................... 11-41
Rear window wiper blade rubber (Outback) ... .... 11-41Battery
.............................................................. 11-43
Fuses ................................................................ 11-44
Installation of accessories .............................. 11-45
Replacing bulbs ............................................... 11-45
Headlight ......................................................... 11-45
Front turn signal light ...................................... 11-48
Front position light .......................................... 11-48
Front fog light (if equipped) .............................. 11-48
Rear combination lights ................................... 11-49
Tail/Back-up light (Outback) ............................. 11-51
License plate light ........................................... 11-52
Dome light ....................................................... 11-53
Map light ......................................................... 11-54
Vanity mirror light ............................................ 11-54
Door step light ................................................. 11-55
Cargo area light (Outback) ............................... 11-55
Trunk light (Legacy) ......................................... 11-55
Other bulbs ..................................................... 11-55

11-48Maintenance and service
& Front turn signal light
NOTE
It may be difficult to replace the bulbs.
We recommend that you have the bulbs
replaced by your SUBARU dealer if
necessary.
1. Turn over the protective cover of the
engine compartment.
2. Turn the socket counterclockwise and
pull it out.
3. Pull out the bulb from the socket and
replace the bulb with a new one.
4. After replacing the bulbs, reposition
the protective cover of the engine com- partment. &
Front position light
1. Turn the socket counterclockwise and
pull it out.
2. Pull out the bulb from the socket and
replace the bulb with a new one. &Front fog light (if equipped)
NOTE
It may be difficult to replace the bulbs.
We recommend that you have the bulbs
replaced by your SUBARU dealer if
necessary.
1. Pull off the fender lining. Refer to “ Pulling off the fender lining ”F 11-7.

11-50Maintenance and service
1) Brake/tail and rear side marker light
2) Rear turn signal light
3) Back-up light
2. Remove the bulb holder from the rear
combination light assembly by turning it
counterclockwise. Use pliers if necessary.
3. Pull the bulb out of the bulb holder and
replace it with a new one.
4. Set the bulb holder into the rear
combination light assembly and turn it
clockwise until it locks.
5. Securely lock the cover against the
trunk trim. !
Outback
1. Undo the clips. For the method to undo
the clips, refer to “Type C clips ”F 11-6.
2. Remove the cover.
3. Remove the upper and lower screws.
4. Slide the rear combination light as-
sembly straight rearward and remove it
from the vehicle.

1) Tail and rear side marker light
2) Brake light
3) Rear turn signal light
5. Remove the bulb holder from the rear
combination light assembly by turning itcounterclockwise.
6. Pull the bulb out of the bulb holder and
replace it with a new one.
7. Set the bulb holder into the rear
combination light assembly and turn it
clockwise until it locks.8. Reinstall the rear combination light
assembly by sliding the two-pronged part
of the combination light assembly securely
to each holder of the vehicle side.
9. Tighten the upper and lower screws.
10. Reinstall the side cover. &
Tail/Back-up light (Outback)
1. Apply a flat-head screwdriver to the
light cover as shown in the illustration, and
pry the light cover off from the rear gatetrim. Maintenance and service
11-51
– CONTINUED –

Wattage Bulb No.
1) High beam headlight 12V-60W HB3 (9005)
2) Front position light 12V-5W W5W
3) Low beam headlight 12V-55W H7
4) Front turn signal light 12V-21W W21W
5) Map light 12V-8W
6) Dome light 12V-8W
7) Door step light 12V-5W W5W
8) Front fog light 12V-55W H11
9) Front side marker light 12V-5W W5W
10) Vanity mirror light 14V-1.4W HTU
11) Cargo area light 12V-13W
12) Back-up light (Outback) 12V-16W 921
13) Tail light (Outback) 12V-5W W5W
14) Licence plate light (Outback) 12V-5W W5W
15) Rear turn signal light (Outback) 12V-21W WY21W Specifications
12-15
– CONTINUED –

12-16Specifications
Wattage Bulb No.
16) Brake light (Outback) 12V-21W W21W
17) Tail and rear side marker light (Outback) 12V-5W W5W
18) Trunk light (Legacy) 12V-5W W5W
19) Tail light (Legacy) 12V-5W W21/5W 20) Brake/Tail and rear side marker light (Legacy) 12V-21/5W W21/5W
21) License plate light (Legacy) 12V-5W W5W
22) Back-up light (Legacy) 12V-16W 921
23) Rear turn signal light (Legacy) 12V-21W WY21W
A) High mount stop light (Outback) ––
B) High mount stop light (Legacy) ––WARNING
Bulbs may become very hot while
illuminated. Before replacing bulbs,
turn off the lights and wait until the
bulbs cool down. Otherwise, there is
the risk of sustaining a burn injury.
CAUTION
Replace any bulb only with a new
bulb of the specified wattage. Using
a bulb of different wattage could
result in a fire.

Warning........................................................ 3-18, 7-34
Emergency Locking Retractor (ELR) ............................. 1-13
Engine
Compartment overview ........................................... 11-9
Coolant ........................................................ 11-17, 12-8
Exhaust gas (carbon monoxide) ............................. 6, 8-2
Hood .................................................................... 11-7
Low oil level warning light ....................................... 3-14
Oil............................................................... 11-12, 12-4 Overheating .......................................................... 9-13
Starting ................................................................... 7-8
Stopping ............................................................... 7-10
Exterior care .............................................................. 10-2
F
Flat tires ..................................................................... 9-6
Floor mat .................................................................. 6-14
Fluid level Automatic transmission .......................................... 11-21
Brake .................................................................. 11-25
Clutch .................................................................. 11-26
Power steering ..................................................... 11-24
Fog light
Bulb .................................................................... 11-48
Indicator light ......................................................... 3-23
Switch .................................................................. 3-30
Folding mirror switch .................................................. 3-51
Front Differential gear oil ........................................ 11-23, 12-7
Fog light ...................................................... 3-30, 11-48
Fog light indicator light ............................................ 3-23 Position light
........................................................ 11-48
Seatbelt pretensioners ............................................ 1-21
Turn signal light .................................................... 11-48
Front fog light ........................................................... 11-48
Front seats ................................................................. 1-2
Forward and backward adjustment ............................ 1-3
Head restraint adjustment ......................................... 1-6
Power seat ............................................................. 1-4
Reclining ................................................................ 1-3
Seat height adjustment (driver ’s seat) ........................ 1-4
Fuel ........................................................................... 7-2
Economy hints ........................................................ 8-2
Filler lid and cap ...................................................... 7-3
Gauge .................................................................... 3-7
Requirements ................................................. 7-2, 12-3
Fuses ..................................................................... 11-44
Fuses and circuits .................................................... 12-10
G
GAWR (Gross Axle Weight Rating) .. ............................. 8-14
Glove box ................................................................... 6-6
GVWR (Gross Vehicle Weight Rating) ........................... 8-14
H
Hands-free system. ..................................................... 5-49
Hazard warning flasher .......................................... 3-5, 9-2
Head restraint adjustment Front seat ............................................................... 1-6
Rear seat .............................................................. 1-10
Headlight ......................................................... 3-27, 11-45
Bulb wattage ........................................................ 12-14 Index
14-5

Lost transmitters (remote keyless entry system)......... 2-12
Replacing bulbs ........................................................ 11-45
Back-up light (Legacy) ........................................... 11-49
Brake light (Outback) ............................................. 11-50
Brake light (Station wagon) .................................... 11-50
Brake/Tail and rear side marker light (Legacy) .......... 11-49
Brake/Tail light (Sedan) .......................................... 11-49
Cargo area light .................................................... 11-55
Dome light ........................................................... 11-53
Door step light ...................................................... 11-55
Front fog light ....................................................... 11-48
Front position light ................................................. 11-48
Front turn signal light ............................................. 11-48
Headlight ............................................................. 11-45
License plate light ................................................. 11-52
Map light .............................................................. 11-54
Rear combination light ........................................... 11-49
Rear turn signal light (Sedan) ................................. 11-49
Rear turn signal light (Station wagon) ...................... 11-50
Tail and rear side marker light (Outback) .................. 11-50
Tail light (Station wagon) ........................................ 11-50
Tail/Back-up light (Outback) .................................... 11-51
Trunk light ............................................................ 11-55
Vanity mirror light .................................................. 11-54
Rocking the vehicle .................................................... 8-12
Roof rails with integrated cross bars ............................. 8-14
S Safety Precautions when driving ............................................. 4
Symbol ...................................................................... 2 Warnings
................................................................... 2
Seat
Fabric ................................................................... 10-5
Front ...................................................................... 1-2
Heater .................................................................... 1-6
Height adjustment .................................................... 1-4
Power .................................................................... 1-4
Rear ...................................................................... 1-7
Seatbelt. ................................................................ 4, 1-12
Fastening .............................................................. 1-14
Maintenance .......................................................... 1-20
Pretensioners ......................................................... 1-21
Safety tips ............................................................. 1-12
Warning light and chime ........................................... 3-9
Security Alarm system ......................................................... 2-15
ID plate .................................................................. 2-3
Immobilizer ............................................................. 2-3
Indicator light ......................................................... 3-21
Shock sensors ....................................................... 2-19
Select lever ............................................................... 7-18
Position indicator .................................................... 3-22
Shift lock function ................................................... 7-20
Shock sensors ........................................................... 2-19
Shopping bag hook ..................................................... 6-13
Snow tires ....................................................... 8-11, 11-30
Snowy and icy roads .................................................. 8-10
Sounding a panic alarm .............................................. 2-10
Spark plugs ..................................................... 11-20, 12-9
Specifications ............................................................. 12-2
Speedometer .............................................................. 3-6 Index
14-9
