Page 10 of 33
8
Gauges
Outback 2.5i
Immediate Attention
Caution
Informational
Tachometer
Temperature gaugeTrip meter and odometerTrip meter reset button
Seatbelt warning
Front passenger
seatbelt warning
SRS airbag system
Security indicator light
Charge warning
Oil pressure warning
Brake system
Power steering warning
High beam indicator light
Engine oil level warning
AT OIL TEMP
(Automatic Transmission)
ABS warning
Low fuel
All-Wheel Drive
(Automatic Transmission)ECO gauge
2926966_18a_Subaru_Outback_QRG_050417.indd 85/4/17 3:34 PM
Page 11 of 33
9
Speedometer
Fuel gauge
Gauges
Vehicle Dynamics Control/
Vehicle Dynamics Control
operation
Vehicle Dynamics Control OFF
CHECK ENGINE/
Malfunction indicator
Tire pressure warning light
Front passenger airbag ON
(Located on overhead console)
Front passenger airbag OFF (Located on overhead console)
Low windshield washer fluid
Hill holder
Turn signals
Front fog light indicator
light (if equipped)
Headlight indicator light
Cruise control
indicator light
Cruise control SET
indicator light
2926966_18a_Subaru_Outback_QRG_050417.indd 95/4/17 3:35 PM
Getting
StartedInstrument
Panel Gauges
Personalize ControlsWhile
Operating Safety/In Case
of Emergency Additional
Information
Page 12 of 33
10
Tachometer
Temperature gauge Trip meter and odometer
Gauges
Outback 2.5i Premium
Outback 2.5i Limited
Outback 2.5i Touring
Outback 3.6R Limited
Outback 3.6R Touring
Immediate Attention
Caution
Informational
Trip meter reset button
ECO gauge
Seatbelt warning
Front passenger
seatbelt warning
SRS airbag system
Security indicator light
Charge warning
Oil pressure warning
Brake system
Power steering warning
Door open (if equipped)
High beam indicator light
Engine oil level warning
AT OIL TEMP
(Automatic Transmission)
ABS warning
Low fuel
All-Wheel Drive
(Automatic Transmission)
2926966_18a_Subaru_Outback_QRG_050417.indd 105/4/17 3:35 PM
Page 13 of 33
11
SpeedometerFuel gauge
Gauges
Vehicle Dynamics Control/
Vehicle Dynamics Control
operation
Vehicle Dynamics Control OFF
CHECK ENGINE/
Malfunction indicator
Tire pressure warning light
Front passenger airbag ON
(Located on overhead console)
Front passenger airbag OFF (Located on overhead console)
Low windshield washer fluid
Hill holder
Turn signals
Front fog light indicator
light (if equipped)
Headlight indicator light
Cruise control
indicator light
Cruise control SET
indicator light
2926966_18a_Subaru_Outback_QRG_050417.indd 115/4/17 3:35 PM
Getting
StartedInstrument
Panel Gauges
Personalize ControlsWhile
Operating Safety/In Case
of Emergency Additional
Information
Page 28 of 33
![SUBARU OUTBACK 2018 Quick Guide 26
Fuel
For both the 2.5 liter 4-cyl. engine and the 3.6 liter 6-cyl. engine, us\
e regular unleaded
gasoline with an octane rating of 87 AKI or higher. Consult the Owner’s Manual for more
detaile](/img/17/40470/w960_40470-27.png "SUBARU OUTBACK 2018 Quick Guide 26
Fuel
For both the 2.5 liter 4-cyl. engine and the 3.6 liter 6-cyl. engine, us\
e regular unleaded
gasoline with an octane rating of 87 AKI or higher. Consult the Owner’s Manual for more
detaile")
26
Fuel
For both the 2.5 liter 4-cyl. engine and the 3.6 liter 6-cyl. engine, us\
e regular unleaded
gasoline with an octane rating of 87 AKI or higher. Consult the Owner’s Manual for more
detailed information.
Fuel Capacity
• 18.5 US gal (70 liters, 15.4 Imp gal)
• When the low fuel indicator light is displayed on the instrument panel, \
approximately
2.6 US gal (10.0 liters, 2.2 Imp gal) of fuel remain.
• If you have recently fueled your vehicle, the check engine light on the instrument pa\
nel
may stay on due to a missing or loose fuel filler cap (the cap should\
be tightened until a
click is heard).
Fuel Filler Lid Release
The fuel fill lid release is located on the floor to the left of the
driver’s seat. To open the fuel filler lid, pull the fuel filler lever
up and release.
Additional Information
2926966_18a_Subaru_Outback_QRG_050417.indd 265/4/17 3:37 PM
Page 32 of 33
Steering Wheel & Instrument Panel
Master and Valet Keys, Keyless Access System* operation,
Push Button Start* and Remote Start*
Tilt/Telescopic Steering Column Adjustments and Paddle Shift operation*
Steering Wheel Controls
Headlights, DRL, Parking Lights, Hazard Lights, Interior Lights,
Fog Lights*, Autolights* and Welcome / Goodbye Lighting*
Front & Rear* Wiper and Washer Controls
Gauges, Warning Lights, Multi Function Display*, Information Display settings
and Parking Brake operation
Safety, Comfort & Convenience
All Wheel Drive System, Emergency towing of AWD,
VDC, X-MODE®* and Hill Holder* operation
Rear Vision Camera
All Weather Package operation - Heated Seats,
Exterior Mirrors & Windshield Wiper De-icer
Review operation of climate control system
Power windows, locks, exterior mirrors, seat including Memory Function*
and Power Moonroof* operation
Hood Release and fluid reservoir locations
Fuel Filler Door, Trunk Release, Rear Gate operation
and location of Spare Tire*, Jack & Tools
STARLINK Audio System, Bluetooth & Safety / Security
Bluetooth - Pair owner’s phone(s) & show operation
(Download SUBARU STARLINK and MySubaru Apps*)
STARLINK Audio and Navigation* system controls
Driver Assist Technologies
EyeSight™ System*
Reverse Automatic Braking System*
Blind Spot Detection*, Lane Change Assist* and Rear Cross Traffic Alert*
High Beam Assist*, Steering Responsive Foglights* and
Steering Responsive Headlights*
*If Applicable
Owner Signature(s) ________________________________________________________________
Subaru Sales Consultant ___________________________________________________________
Subaru Sales Manager _____________________________________________________________
2926966_18a_Subaru_Outback_QRG_050417.indd 305/4/17 3:37 PM
