SUBARU TRIBECA 2011 1.G Navigation Manual
Manufacturer: SUBARU, Model Year: 2011, Model line: TRIBECA, Model: SUBARU TRIBECA 2011 1.GPages: 126, PDF Size: 20.27 MB
Page 91 of 126
90
3
Set the memory point using the preferred method available on the
displayed screen.
NOTEUp to 100 memory points can be stored. Once that number has been reached, you must delete memory points that you no longer require
(see Page 94) before you can store new memory points. The number of memory points you can store is indicated on the screen.
Stored Locations
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 90
Page 92 of 126
91
Stored Locations
■Reviewing and modifying memory points Using this function, you can review the stored memory points in the form of a list on the screen and modify
names, icons, telephone numbers, and other memory point data.1
Select the category of the memory point to be modified.
2
Select (list).
Press the button or select , then select (stored locations), and then select
(memory
points
).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 91
Page 93 of 126
92
3
Select the memory point to be modified.You can change the sequence in which memory points are listed by selecting
(distance), (icon), (name), or (date).
4
Select the category key corresponding to the memory point to be
modified.
(icon):Selecting this key allows you to choose a display icon. and
of the CHANGE ICON screen contain standard icons, whereas
the “With Sound” (with sound) page contains icons that are
accompanied by response sounds. Select (with sound) to
listen to these sounds.
NOTE
The “With direction” ( / ) keys in the “With Sound” page are used to activate response
sounds only when you come near the memory point from the specified direction. Select or
and set the direction using or .
Stored Locations
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 92
Page 94 of 126
93
Stored Locations
(category):Use this key to change the storage category. After selecting
this key, select the key of the new category.
(name):Select this key to change the name of a memory point. When
the change has been completed, select (OK). Then select
(on) if the name is to be displayed on the map, or
(off) if it is not to be displayed.
(position):Select this key to review the memory points and modify a
memory point on the map screen. After checking or modifying
it, select (OK).
(telephone):Select this key to modify a telephone number. When the
modification has been completed, select (OK).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 93
Page 95 of 126
94
■Deleting memory pointsYou can delete stored memory points by using this function.1
Select the category of the memory point to be deleted.
2
Select (delete).
3
Select the memory point to be deleted.
4
Confirmation message will be displayed. Select (yes).Select (no) to cancel the deletion.
Stored Locations
Press the button or select , then select (stored locations), and then select
(memory
points
).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 94
Page 96 of 126
95
Stored Locations
■Deleting all memory pointsUsing this function, you can delete all memory points.1
Select the category of the memory points to be deleted.
2
Select (delete all).
3
Confirmation message will be displayed. Select (yes).Select (no) to cancel the deletion.
Press the button or select , then select (stored locations), and then select
(memory
points
).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 95
Page 97 of 126
96
■Modifying category namesUse this function if you want to change the category names - (marked point), (personal),
(business), and (entertainment) .1
Select the category for which the name is to be changed.
2
Select (edit category).
3
Erase the letters of the category name using , enter the new
letters, and then select .
Stored Locations
Press the button or select , then select (stored locations), and then select
(memory
points
).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 96
Page 98 of 126
97
Stored Locations
Avoid area
■Storing avoid areasIf you use this function to store into the system’s memory the areas you want to avoid, the system will avoid the
areas when calculating routes.1
Select (add).
2
Set an avoid area using your preferred method.A map including the specified avoid area will appear.
The method of setting avoid areas is identical to that of setting destinations.
Press the button or select , then select (stored locations), and then select
(avoid area
).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 97
Page 99 of 126
98
3
Select (reduce) or (enlarge).
(reduce):Reduces the size of the avoid area.
(enlarge):Increases the size of the avoid area.
4
Select (OK).
NOTE• Reduce the scale of the map to specify a larger area.
• Avoid areas can be set only when the scale of the map is 0.6 mile (1 km) or less.
Stored Locations
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 98
Page 100 of 126
99
Stored Locations
■Reviewing and modifying avoid areasUsing this function, you can review the stored avoid areas in the form of a list and modify them if necessary.1
Select (list).
2
Select the avoid area to be modified.
3
Select the key corresponding to the item to be modified.For details regarding the function of each key, refer to “Reviewing and modifying
memory points” on Page 91.
NOTE
The methods for deleting individual and all avoid areas are the same as those described on Page 94 and 95 for memory points.Press the button or select , then select (stored locations), and then select
(avoid area
).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 99
