SUZUKI AERIO 2007 1.G Owners Manual

Downloaded from www.Manualslib.com manuals search engine 13-3 FUSES AND PROTECTED CIRCUITS
54G27-03E
54G222
COLOR/SIZE (AMPS)
FUSE NAME PROTECTED CIRCUIT
Under the
dashboard FUSE
BOX(12) RED (10) HEATER Air Conditioning, Mirror Heater Switch
(13) BLANK – –
(14) YELLOW (20) REAR DEFOG Rear Defroster
(15) BLUE (15) RADIO·DOMEFuel Injection Controller, Dome Light, Spot Light,
Luggage Compartment Light, Radio, A/T Controller
(16) RED (10) AIR BAG 2 Air Bag
(17) RED (10) HAZARD Hazard Light, Keyless Entry
(18) BLANK – –
(19) RED (10) TAILParking/Marker Light (Front & Rear), License Plate
Light
(20) YELLOW (20) DOOR LOCK Door Lock Control
(21) BLANK – –
(22) BLUE (15) AIR BAG Air Bag
(12) (13) (14) (15) (16) (17) (18) (19)
(22) (23) (24) (25) (26) (27)(28) (29)(20) (21)
(33)
(34)
Fuses and Protected Circuits: 7

Downloaded from www.Manualslib.com manuals search engine 13-4 FUSES AND PROTECTED CIRCUITS
54G27-03E
54G222
COLOR/SIZE (AMPS)
FUSE NAME PROTECTED CIRCUIT
Under the
dashboard FUSE
BOX(23) BLUE (15) IGGenerator, Ignition Coil, O
2 Sensor Heater, Fuel
Injection Controller, A/T Controller
(24) RED (10) TURN·BACK Turn Signal Light, Back Up Light
(25) BLUE (15) WIPER WASHER Wiper & Washer
(26) RED (10) ABS Anti-lock Brake System
(27) RED (10) METER Meter
(28) BLUE (15) CIGAR Cigar Lighter, Mirror Heater, Radio, Power Mirror
(29) BLANK – –
CAS-
SETTE
FUSE(33) ORANGE (30) P/W Power Window
Under the
dashboard
(34) BLANK – –
(12) (13) (14) (15) (16) (17) (18) (19)
(22) (23) (24) (25) (26) (27)(28) (29)(20) (21)
(33)
(34)
Fuses and Protected Circuits: 7

Downloaded from www.Manualslib.com manuals search engine 14-1 SPECIFICATIONS
54G27-03E
14
SPECIFICATIONSNOTE:
Specifications are subject to change without notice.
4WD: 4-wheel drive
2WD: 2-wheel drive
ITEM: Dimensions UNIT: mm (in.)
Overall length4350 (171.3)
Overall width without side mold 1690 (66.5)
with side mold 1720 (67.7)
Overall height1545 (60.8)
Wheelbase2480 (97.6)
Tread Front 1450 (57.1)
Rear 1445 (56.9)
Minimum ground clearance 150 (5.9)
ITEM: Weight
Gross axle weight rating
See the safety certification label and the tire information label which
are located on the driver’s door lock pillar. Gross vehicle weight rating
Vehicle capacity weight
Specifications: 1, 2, 5, 6, 7, 10, 11

Downloaded from www.Manualslib.com manuals search engine 14-2 SPECIFICATIONS
54G27-03E
ITEM: Engine
Type J23A (16 valve DOHC)
Number of cylinders 4
Bore 90.0 mm (3.54 in.)
Stroke 90.0 mm (3.54 in.)
Piston displacement 2290 cm
3 (139.7 cu.in, 2290 cc)
Compression ratio 9.3 : 1
ITEM: Electrical
Ignition timing 3° – 17° B.T.D.C. at idle speed
Standard spark plug NGK IFR5J11
Battery GP24 12V
Fuses See “INSPECTION AND MAINTENANCE” and “FUSES AND PRO-
TECTED CIRCUITS” sections.
Specifications: 1, 2, 5, 6, 7, 10, 11

Downloaded from www.Manualslib.com manuals search engine 14-3 SPECIFICATIONS
54G27-03E
ITEM: Lights WATTAGE BULB No.
Headlight 12V 60/55W HB2
Turn signal light Front 12V 21W 7440
Rear 12V 21W 7440
Side marker light 12V 3.8W 194
Parking light 12V 5W –
Tail/brake light 12V 5/21W –
License plate light 12V 5W –
Back-up light 12V 21W –
Interior light 12V 10W –
Spot light 12V 8W W16W
Meter pilot, warning, indicator lights 12V 1.4W –
High-mount stop light 12V 18W 921
Front fog light Type A 12V 55W –
Type B 12V 35W –
Specifications: 1, 2, 5, 6, 7, 10, 11

Downloaded from www.Manualslib.com manuals search engine 14-4 SPECIFICATIONS
54G27-03E
ITEM: Wheel
Tire size, front and rear P185/65R14 or P195/55R15
Tire pressure For the specified tire pressure, see the Tire Information Label located
on the driver’s door lock pillar.
ITEM: Steering
Toe IN 1.0 ± 2 mm (0.04 ± 0.08 in.)
Camber angle –0° 10’ ± 1°
Caster angle 2° 11’
ITEM: Capacities
Coolant (including reserve tank) 7.0 L (14.8 US pt)
Fuel tank 50 L (13.2 US gal)
Engine oil (replaced with filter) 4.7 L (5.0 quarts)
Transaxle oil Manual transaxle: 2.3 L (4.9 US pt)
4-speed automatic transaxle: 7.7 L (16.3 US pt)
Rear differential oil 0.7 L (1.5 US pt)
Transfer gear box oil 0.75 L (1.6 US pt)
Specifications: 1, 2, 5, 6, 7, 10, 11

Downloaded from www.Manualslib.com manuals search engine 15-1 INDEX
15
54G27-03E
INDEXSymbols“AIR BAG” Light
..................................................................4-5
“CRUISE” Indicator Light
...................................................4-6
“O/D OFF” Indicator Light ..................................................4-6
“PANIC” button function
....................................................2-3
“PASS AIRBAG OFF” Indicator
..........................................4-14
“SET” Indicator Light
..........................................................4-6
Numerics4-Speed Automatic Transaxle
............................................6-4
AA/T Selector Position Indicator
..........................................4-7
Accelerator Pedal
................................................................5-2
Accessory Socket ................................................................5-10
Adding Engine Coolant
.......................................................9-18
Adjusting Seat Position ......................................................2-11
Adjusting Seatbacks
...........................................................2-12
Air Cleaner
...........................................................................9-20
Air Conditioning System
.....................................................9-43
All Seat Belts Except Rear Center
.....................................2-16
Anti-Lock Brake System (ABS)
..........................................6-7
Anti-Lock Brake System (ABS) Warning Light
.................4-3
Armrest
.................................................................................5-6
Assist Grips
.........................................................................5-7
Audio Systems .....................................................................4-26
Automatic Heating and Air Conditioning System
(Climate Control) .................................................................4-22
Automatic Locking Retractor (ALR)
..................................2-15
Automatic Transaxle Fluid
..................................................9-16
BBasic Operations
................................................................ 4-29
Battery
.................................................................................. 9-35
Brake Fluid
.......................................................................... 9-22
Brake Pedal ..................................................................5-2
, 9-23
Brake System Warning Light
............................................. 4-3
Brakes
.................................................................................. 9-22
Braking ................................................................................. 6-7
Break-In ................................................................................ 6-9
Brightness Control
............................................................. 4-8
Bulb Replacement ............................................................... 9-38
CCatalytic Converter
............................................................. 6-9
Changing Engine Oil and Filter
......................................... 9-12
Changing Wheels
................................................................ 9-31
Charging Light
.................................................................... 4-4
Child Lock System (rear side doors)
................................ 2-6
Child Restraint Systems
..................................................... 2-22
Cigarette Lighter and Ashtray
........................................... 4-11
Clock
.................................................................................... 4-13
Clutch Pedal
.................................................................5-2
, 9-25
Coat Hooks
.......................................................................... 5-8
Compact Spare Tire
............................................................ 9-30
Corrosion Prevention ......................................................... 11-1
Cruise Control
..................................................................... 3-6
Cup Holder and Storage Area
............................................ 5-9
DDaily Inspection Checklist
................................................. 6-1

Downloaded from www.Manualslib.com manuals search engine 15-2 INDEX
54G27-03E
Daytime Running Light (D.R.L.) Indicator Light
...............4-7
Daytime Running Light (D.R.L.) System
............................3-3
Door Locks
...........................................................................2-1
Driver’s Seat Belt Reminder Light
.....................................4-4
Driving on Hills
....................................................................7-1
Driving on Slippery Roads
..................................................7-2
EEmergency Locking Retractor (ELR)
.................................2-15
Emission Compliance Label (for U.S.A.)
...........................12-2
Engine Block Heater
............................................................6-3
Engine Coolant
....................................................................9-17
Engine Coolant Level Check
..............................................9-18
Engine Coolant Replacement .............................................9-18
Engine Hood
........................................................................5-8
Engine Oil and Filter
............................................................9-11
Engine Serial Number .........................................................12-1
Exhaust Gas Warning .........................................................6-1
Eyeglasses Holder
...............................................................5-8
FFluid Level Check
................................................................9-16
Fog Light Switch ..................................................................4-11
Folding Rear Seats ..............................................................5-4
Frame Hooks
........................................................................5-11
Front Passenger’s Seat Belt Reminder Light
...................4-13
Front Seat Back Pocket
......................................................5-13
Fuel Filler Cap
......................................................................5-3
Fuel Gauge
...........................................................................4-9
Fuel Pump Labeling
............................................................1-1
Fuel Recommendation ........................................................1-1
Fuses
....................................................................................9-35
FUSES AND PROTECTED CIRCUITS
.................................13-1Fuses in the Engine Compartment
.................................... 9-36
Fuses under the Dash Board
............................................. 9-36
GGasoline Containing MTBE
................................................ 1-1
Gasoline/Ethanol blends
.................................................... 1-1
Gasoline/Methanol blends ................................................. 1-1
Gear Oil
................................................................................ 9-14
Gear Oil Level Check
.......................................................... 9-15
Gear Oil Replacement ......................................................... 9-15
Gearshift Lever
.................................................................... 5-2
GLOSSARY OF TIRE TERMINOLOGY
............................... 9-32
Glove Box
............................................................................ 4-14
HHazard Warning Switch
...................................................... 4-10
Head Restraints
................................................................... 2-12
Headlight Aiming ................................................................ 9-37
Heating and Air Conditioning System
.............................. 4-15
Heating System
................................................................... 4-16
High Beam Indicator Light
................................................. 4-6
Highway Driving
.................................................................. 7-1
Horn
...................................................................................... 3-8
How the ABS Works
........................................................... 6-9
IIdentification Numbers
....................................................... 12-1
If the Engine is Flooded ..................................................... 10-6
If the Engine Overheats ...................................................... 10-6
If the Starter Does Not Operate
......................................... 10-6
If You Can Not Shift Automatic Transaxle Gearshift
Lever Out of “P” (PARK)
.................................................... 10-8
If Your Vehicle Gets Stuck ................................................. 7-2
Ignition Key Reminder
........................................................ 2-1

Downloaded from www.Manualslib.com manuals search engine 15-3 INDEX
54G27-03E
Ignition Switch
.....................................................................3-1
Improving Fuel Economy
....................................................6-10
Information Display
.............................................................4-12
Inside Rearview Mirror ........................................................2-10
Installation with Lap-Shoulder Seat Belts
(child restraint with no top strap)
......................................2-24
Installation with the LATCH System ..................................2-26
Installation-Child Restraint with Top Strap
.......................2-29
Instrument Cluster
...............................................................4-2
Instrument Panel
.................................................................4-1
Interior Light Switch ............................................................5-6
Internal Trunk Release ........................................................2-7
JJacking Instructions
............................................................10-1
Jump Starting Instructions
.................................................10-4
KKeyless Entry System
.........................................................2-3
Keys
......................................................................................2-1
LLane change signal
.............................................................3-4
Lap-Shoulder Belt
................................................................2-15
Lighting Operation ..............................................................3-3
Lighting/Turn Signal Control Lever
...................................3-3
Lights “On” reminder
..........................................................3-3
Listening to a CD
.................................................................4-33
Listening to the Radio
.........................................................4-31
Low Fuel Warning Light ......................................................4-5
MMaintenance Recommended under Severe Driving
Conditions
............................................................................9-7
Maintenance Schedule
........................................................9-2Malfunction Indicator Light
................................................ 4-5
Manual Heating and Air Conditioning System
................. 4-19
Manual Transaxle
................................................................ 6-6
Mirrors
.................................................................................. 2-10
NNational Highway Traffic Safety Administration
(NHTSA)
............................................................................... 12-4
OOdometer
............................................................................. 4-7
Oil Level Check
................................................................... 9-11
Oil Pressure Light ............................................................... 4-4
On-Board Vehicle Computers and Event Data
Recorders
............................................................................ 12-3
Open Door Warning Light
.................................................. 4-6
Outside Rearview Mirrors .................................................. 2-10
Outside Rearview Mirrors Defroster Switch
..................... 4-11
PParking Brake Lever
....................................................5-1
, 9-24
Pedals
.................................................................................. 5-1
Periodic Maintenance Schedule
........................................ 9-3
Power Assisted Brakes
...................................................... 6-7
Power Door Locking System
............................................. 2-2
Power Mirror Control
.......................................................... 2-11
Power Steering
.................................................................... 9-24
Power Steering Fluid
.......................................................... 9-24
Power Window Controls ..................................................... 2-8
Programming/Removing the transmitter code
yourself
................................................................................ 2-5
RRadio Antenna
..................................................................... 4-33
Rear Center Seat Belt
......................................................... 2-17

Downloaded from www.Manualslib.com manuals search engine 15-4 INDEX
54G27-03E
Rear Window Defroster Switch
..........................................4-10
Rear Window Wiper/Washer Switch
..................................3-5
Refill with Oil and Check for Leaks ....................................9-13
Refilling
................................................................................9-12
Remote Audio Controls
.............................................. 3-8
, 4-43
Replace the Oil Filter
...........................................................9-13
Replacement of the transmitter battery
.............................2-4
Reporting Safety Defects
....................................................12-4
SSafety Certification Label
...................................................12-2
Seat Adjustment
..................................................................2-11
Seat Belt Extender ...............................................................2-30
Seat Belt Hanger
..................................................................2-21
Seat Belt Inspection
............................................................2-22
Seat Belt Pretensioner System
..........................................2-31
Seat Belt Reminder
..............................................................2-19
Seat Belts and Child Restraint Systems
...........................2-13
Selection of Coolant
............................................................9-17
Shoulder Anchor Height Adjuster
......................................2-21
Side Door Locks
..................................................................2-1
Snow Tires
...........................................................................9-31
Spark Plugs ..........................................................................9-21
SPECIFICATIONS
................................................................14-1
Specified Fluid
.....................................................................9-16
Specified Gear Oil ................................................................9-14
Specified Oil
.........................................................................9-11
Speedometer ........................................................................4-7
Spot Light
.............................................................................5-7
Starting the Engine
..............................................................6-2
Steering Wheel
.....................................................................9-24
Stowing Rear Center Lap-Shoulder Belt
...........................2-19Sun Visor
............................................................................. 5-6
Supplemental Restraint System (air bags)
....................... 2-32
TTachometer
.......................................................................... 4-9
Temperature Gauge
............................................................ 4-10
Thermometer
....................................................................... 4-13
Tilt Steering Lock Lever
..................................................... 3-6
Tire Chains
.......................................................................... 7-3
Tire Changing Tools
........................................................... 5-12
Tire Inflation Pressure ........................................................ 9-26
Tire Inspection
.................................................................... 9-27
Tire Rotation
........................................................................ 9-29
Tire Sidewall Labeling
........................................................ 9-25
Tire Size
............................................................................... 9-26
Tires
..................................................................................... 9-25
Towing a Disabled Vehicle
................................................. 10-5
Towing Your Vehicle (recreational towing)
...................... 8-2
Trailer Towing
..................................................................... 8-2
Trip meter
............................................................................ 4-7
Troubleshooting
.................................................................. 4-47
Trunk Lid
.............................................................................. 2-7
Trunk Light .......................................................................... 5-13
Turn Signal Indicators
........................................................ 4-6
Turn Signal Operation ........................................................ 3-4
UUniform Tire Quality Grading
............................................. 9-29
Unlatching and Latching Detachable Connector
............. 2-18
Using the Transaxle
............................................................ 6-4
VVehicle Cleaning
................................................................. 11-3
Vehicle Identification Number
........................................... 12-1
