Intelligent All Wheel Drive (i-AWD)
Indicator Light (if equipped)
57L30044
When the 2WD/i-AWD switch is in the “i-
AWD” mode with the engine switch in the
“ON” mode, the light comes on and stays
on.
For details, refer to “Using the 2WD/i-AWD
Switch” in the “OPERATING YOUR VEHI-
CLE” section.Daytime Running Light (D.R.L.) Indi-
cator Light (if equipped)
60B245
With the D.R.L. system, the headlights
light, but are dimmer than the low beam,
when the following three conditions are all
met. Whenever the D.R.L. system is oper-
ating, the D.R.L. indicator light remains on.Conditions for D.R.L. system operation
1) The engine is running.
2) The parking brake is released.
3) The headlights are off.
Transaxle Warning Light (if
equipped)
80J219
This light comes on when you press the
engine switch to change the ignition mode
to “ON” if there is any problem with the
continuously variable transaxle (CVT).
 The light should normally come on when
the ignition mode is changed to “ON” by
pressing the engine switch and stay on
for about 2 seconds before going out.
NOTE:
The following conditions may indicate
some problem with the CVT system. If any
of these conditions occurs, have your vehi-
cle inspected by an authorized SUZUKI
dealer.
 The light comes on while driving.
 The light does not come on even when
the ignition mode is changed to “ON” by
pressing the engine switch. The light does not go out in about 2 sec-
onds after changing the ignition mode to
“ON” by pressing the engine switch.
Immobilizer/Keyless Start System
Warning Light
80JM122
When you press the engine switch to
change the ignition mode to “ON”, the light
comes on briefly so you can check that the
light is working. If this light stays on, there
is a problem with the system. This light
flashes if you press the engine switch while
the system is not sensing the remote con-
troller. For details, refer to “Immobilizer
System” in this section.i-AWD Warning Light (if equipped)
57L30042
When you press the engine switch to
change the ignition mode to “ON”, the light

2-100
BEFORE DRIVING
57L20-03E
Lighting Control Lever
57L21128
Lighting Operation (if equipped)
57L21062
To turn the lights on or off, twist the knob
on the end of the lever. There are three
positions:
OFF (1)
All lights are off.
(2)
Front position lights, tail lights, license
plate light and instrument lights are on, but
headlights are off.
(3)
Front position lights, tail lights, license
plate light, instrument lights and headlights
are on.
57L21063
With the headlights on, push the lever for-
ward to switch to the high beams (main
beams) or pull the lever toward you to
switch to the low beams. When the high
beams (main beams) are on, a light on the
instrument panel will come on. To momen-
tarily activate the high beams (main
beams) as a passing signal, pull the lever
slightly toward you and release it when you
have completed the signal.
WARNING
To avoid possible injury, do not oper-
ate controls by reaching through the
steering wheel.
(1)(2)(3)

2-103BEFORE DRIVING
57L20-03E
57L21065
With the headlights on, push the lever for-
ward to switch to the high beams (main
beams) or pull the lever toward you to
switch to the low beams. When the high
beams (main beams) are on, a light on the
instrument panel will come on. To momen-
tarily activate the high beams (main
beams) as a passing signal, pull the lever
slightly toward you and release it when you
have completed the signal.
Auto-On Headlight System
57L21118
The Auto-on headlight system automati-
cally turns on all lights that are operated by
the lighting control lever on the steering
column, when the following three condi-
tions are all met.
Conditions for Auto-on headlight system
operation:
1) It is dark around the light sensor (5).
2) The lighting control lever is in the
“AUTO” position.
3) You press the engine switch to change
the ignition mode to “ON”.
This system is operated by a signal from
the light sensor (5) on the front wind shield.
Do not cover the sensor (5). If you do, the
system will not work correctly.NOTE:
The light sensor reacts even to infrared
rays, so it may operate incorrectly when
there are strong infrared rays.
Reprogramming the Automatic Light
Function
The following settings of the automatic light
function can be customized to your prefer-
ence. Please contact an authorized
SUZUKI dealer if you want the function
reprogrammed.
EXAMPLE
(5)
WARNING
It takes about 5 seconds for the light
sensor to react to a change in light-
ing conditions. To help avoid an acci-
dent due to reduced visibility, turn on
your headlights before driving into a
tunnel, parking structure or the like.

2-104
BEFORE DRIVING
57L20-03E
Sensitivity of the light sensor
The amount of outside light needed to turn
the lights on and off is pre-set at the fac-
tory. The sensitivity of the light sensor can
be adjusted so that the lights are turned on
and off when it is:
 lighter outside than the pre-set condition,
or
 darker outside than the pre-set condition
Rain-triggered automatic lighting oper-
ation
The setting of the auto-on headlight sys-
tem can be changed to make it turn on the
headlights:
 when the rain sensor senses heavy rain-
fall (pre-set at the factory)
 when the rain sensor senses light and
heavy rainfall (in coordination with rain-
sensing wiper operation), or
 independently from rain-sensing wiper
operation.
Light Reminder BuzzerThe interior buzzer continuously beeps if
you open the driver’s door without turning
off the headlights and position lights. This
function is triggered under the following
condition:
 The headlights and position lights are on
even after you change the ignition mode
to “LOCK” (OFF) by pressing the engine
switch.
The buzzer stops sounding when you turn
off the headlights and position lights.
NOTE:
A message is indicated on the information
display in the instrument cluster while the
buzzer is sounding.
Daytime Running Light (D.R.L.)
System
57L21129
(1) D.R.L. indicator light
(2) Illumination indicator light
The headlights light, but are dimmer than
the low beam, when the following three
conditions are all met. Also, the D.R.L. indi-
cator light (1) on the instrument panel
comes on.
Conditions for D.R.L. system operation:
1) The engine is running.
2) The parking brake is released.
3) The headlights are off, or the lighting
switch in the “AUTO” position and it is
light around the light sensor.
(1) (2)

2-105BEFORE DRIVING
57L20-03E
NOTE:
Be sure to turn the headlights on at night
or at any time of the day when driving or
weather conditions require the headlights
to operate at full brightness and the tail-
lights to be on.
Lights “On” reminder
A buzzer sounds to remind you to turn off
the lights if they are left on when you press
the engine switch to change the ignition
mode to “LOCK” (OFF) and the driver’s
door is opened.
NOTE:
The warning and indicator message and
the illumination indicator light (2) will be
shown on the information display when this
reminder is activated.
Front Fog Light Switch
(if equipped)
64J058
The front fog light comes on when the fog
light switch is pushed in with the headlights
are on and the beams set to the low beam
position.
Turn Signal Control Lever
57L21128
WARNING
To avoid possible injury, do not oper-
ate controls by reaching through the
steering wheel.

7-46
INSPECTION AND MAINTENANCE
57L20-03E
Spot light
57L71016
Pull down the lens by using a flat blade
screwdriver covered with a soft cloth as
shown. To install it, simply push it back in.
Vanity mirror light
57L71017
Pull down the lens by using a flat blade
screwdriver covered with a soft cloth as
shown. To install it, simply push it back in.
The bulb can be removed by simply pulling
it out. When replacing the bulb, make sure
that the contact springs are holding the
bulb securely.
Courtesy light
57L71018
Pull down the lens by using a flat blade
screwdriver covered with a soft cloth as
shown. To install it, simply push it back in.
HeadlightsLow beam light
1) Open the engine hood.
57L71019
2) Remove the cover (1) using a flat blade
screwdriver as shown in the illustration.
57L71020(1)
(3)
(2)

7-47INSPECTION AND MAINTENANCE
57L20-03E
3) Remove the bolts (2) to remove the
bracket (3).
57L71021
4) Turn the cover (4) counterclockwise to
remove it.
57L71022
5) Disconnect the coupler (5).
57L71023
6) Push the retainer (6) in the direction of
the arrow (see the illustration) to detach
it from the hook (7).
7) Replace the bulb, then follow the above
steps in reverse to restore the original
state.High beam light
1) Open the engine hood.
57L70036
2) To create the space necessary for per-
forming the steps that follow, discon-
nect the coupler (1) by pressing the
claw.
(4)
(5)
(7)
(6)
(2)(1)

13-3
INDEX57L20-03E
Head Restraints .......................................................... 2-27, 2-29
Headlight Aiming ................................................................. 7-44
Heated Rear Window and Heated Outside Rearview
Mirrors (if equipped) Switch ............................................. 2-111
High Beam Indicator Light .................................................. 2-75
Highway Driving..................................................................... 4-3
Hill Hold Control System..................................................... 3-34
HomeLink
®........................................................................... 5-93
Horn .................................................................................... 2-111
How the ABS Works ............................................................ 3-30
IIdentification Numbers ........................................................ 10-1
If the Engine is Flooded ........................................................ 8-8
If the Engine Overheats......................................................... 8-8
If the Starter Does Not Operate ............................................ 8-7
If You Cannot Shift CVT Gearshift Lever Out of
“P” (PARK) ............. .............................................................. 3-18
If Your Vehicle Gets Stuck .................................................... 4-4
Illumination Indicator Light................................................. 2-75
Immobilizer System ........................................................ 2-2 , 3-4
Immobilizer/Keyless Start System Warning Light ............ 2-76
Improving Fuel Economy ............... ....................................... 4-2
Information Display ............................................................. 2-80
Inside Rearview Mirror ........................................................ 2-20
Installation of Child Restraint with Top Strap ................... 2-52
Installation with Lap-Shoulder Seat Belts
(child restraint with no top strap)....................................... 2-46
Installation with the LATCH System .................................. 2-49
Instantaneous fuel consumption ....................................... 2-82
Instrument Cluster ............................................................... 2-68
intelligent All Wheel Drive (i-AWD) Indicator Light .......... 2-76 Interior Light Switch ............................................................ 5-78
Interior Workable Area for Engine Starting, Power
Supply Mode Selection
and “Remote Controller
Outside” Warning................................................................... 3-6
Internal Trunk Release........................................................... 2-6
JJacking Instructions .............................................................. 8-2
Jump Starting Instructions ................................................... 8-6KKeyless Push Start System ................................................... 3-4
Keyless Start System Remote Controller ............................ 2-6
Keys......................................................................................... 2-1LLap-Shoulder Belt ................................................................ 2-36
Lidded Instrument Panel Box ............................................. 5-87
Light Reminder Buzzer ...................................................... 2-104
Lighting Control Lever....................................................... 2-100
Lighting Operation ............................................................. 2-100
Locking Rear Seatback........................................................ 2-34
Low Fuel Warning Light ...................................................... 2-74
Low Tire Pressure Warning Light .............................. 2-69 , 3-35
Luggage Under-box ............................................................. 5-92MMaintenance Recommended under Severe Driving
Conditions ..................................................................... 7-7 , 7-11
Maintenance Schedule ................. ......................................... 7-2
Malfunction Indicator Light ................................................. 2-74
Manual Transaxle ................................................................. 3-13
Master Warning Indicator Light .......................................... 2-77
Mirrors ................................................................................... 2-20
