fuel SUZUKI MARUTI 2005 1.G Owners Manual

Downloaded from www.Manualslib.com manuals search engine 183KTABLE OF CONTENTS
1
VEHICLE DETAILS
2
WARRANTY POLICY
3
FUEL RECOMMENDATION
4
BEFORE DRIVING
5
OPERATING YOUR VEHICLE
6
DRIVING TIPS
7
OTHER CONTROLS AND EQUIPMENT
8
VEHICLE LOADING AND TOWING
9
INSPECTION AND MAINTENANCE
10
EMERGENCY SERVICE
11
APPEARANCE CARE
12
GENERAL INFORMATION
13
SPECIFICATION

Downloaded from www.Manualslib.com manuals search engine 383K
MODIFICATION WARNING
w ww w
w WARNING
Do not modify your vehicle.
Modification could adversely affect
safety, handling, performance, or
durability and may violate
governmental regulations. In addition,
damage or performance problems
resulting from modification may not
be covered under warranty.
0-2
t tt t
tWARNING/
t tt t
tCAUTION/
NOTICE/
NOTE
Please read this manual and follow its
instructions carefully. To emphasize special
information, the symbol and the words
WARNING, CAUTION,
NOTICE
and
NOTE
have special meanings. Pay particular
attention to messages highlighted by these
signal words:IMPORTANT
w ww w
w WARNING
Indicates a potential hazard that could
result in death or serious injury.
Indicates a potential hazard that could
result in minor or moderate injury.
t tt t
t CAUTION
NOTICE
Indicates a potential hazard that could
result in vehicle damage.NOTE:
Indicates special information to make
maintenance easier or instructions clearer.
76G-00-001
The circle with a slash in this manual
means “Don’t do this” or “Don’t let this
happen”.
NOTICE
Improper installation of mobile
communication equipment such as
cellular telephones or CB (Citizen’s
Band) radios may cause electronic
interference with your vehicle’s
ignition system, resulting in vehicle
performance problems. Consult your
MARUTI SUZUKI dealer for advice on
installing such mobile communi-cation
equipment.
w ww w
w WARNING
Severe damage may be caused by the
use of either poor quality fuel and/or
lubricants not recommended by
MARUTI SUZUKI.

Downloaded from www.Manualslib.com manuals search engine 883K
Maruti Suzuki offers the Emission Warranty on all Maruti Suzuki vehicles (apart from the Regular warranty and will run parallel
to the regular product warranty) only in four metropolitan cities (New Delhi, Kolkata, Mumbai and Chennai) with effect from
July 1st, 2001.
Terms:
The Emission Warranty will be applicable for 80,000 kms or 3 years (Which ever comes earlier) from the date of delivery to
the first owner. The remaining warranty terms will be valid in case of any change in ownership provided the production of all
valid document.
Conditions:1. Under Emission Warranty, Warranty claims will be admitted for a prima facie examination, in case vehicle fails to meet to the
Emission Standard as specified in sub rule (2) of rule no. 115 of Central Motor Vehicles Rules (CMVR), 1989.
2. The warranty claims will only be accepted after examination carried out by Maruti Suzuki or it's dealer which leads to firm conclusions
that the
a) Original settings have not been tempered in any case.
b) Part (as given in Annexure-A) has a manufacturing defect.
c) Vehicle is unable to meet the Emission Standards (as given in 1.), inspite of the vehicle having been maintained and used
in accordance with the instructions as specified in Owner's Manual and Service Booklet and the used fuel and different oils
(Engine oil, Transmission oil, Brake oil etc.) are also as per specification.
3. The method of examination for deciding the warranty of the parts will be at the sole discretion of Maruti Suzuki and it's dealer
and results of the examination will be final and binding. If after examination, the warrantable condition is not established, Maruti
Suzuki and it's dealer has the right to charge all, or part of the cost of such examination.
4. Under Emission Warranty, the parts (as given in Annexure-A) will be changed free of cost, but the consumables will be charged
as per actual.
5. If the part covered under Emission Warranty or the associated parts, are not independently replaceable, on account of these being
integral parts a complete assembly, Maruti Suzuki and it's dealer will have the sole discretion to replace entire assembly or by
using some of the parts of the system through suitable repair or modifications.EMISSION WARRANTY
2-3EMISSION WARRANTY

Downloaded from www.Manualslib.com manuals search engine 983K6. Any consequential repairs or replacement of parts which may be found necessary to establish compliance of Emission Warranty,
will not be considered under warranty, unless the same is under product warranty. The consumable will be charged as per actual
under such repair or replacement.
7. Maruti Suzuki will not be responsible for the cost of transportation of the vehicle to the nearest Maruti Suzuki dealer workshop
or any loss due to non-availability of the vehicle during the period of lodging of a warranty claim and examination and/or repair
by Maruti Suzuki dealer.
8. Maruti Suzuki will not be responsible for any penalty that may be charged by statutory authorities on account of failure to comply
with the EMISSION STANDARDS.
9. Emission Warranty will not be affected on the change of owner, provided all the documents are available.
10. All maintenance actions (as specified in the Owner's Manual and Service Booklet) need to be followed and recorded in the manual
for emission warranty.
11. The customer needs to produce the PUC (Pollution Under Control) certificate valid for the period preceding the test during which
the failure is discovered. The receipts (for the maintenance of the vehicle as per specification in Owner's Manual and Service
Booklet from the date of original purchase of the vehicle) will also be required.Condition Under which the Emission Warranty is not APPLICABLE
1. In the absence of valid PUC certificate.
2. Vehicle not serviced from Maruti Suzuki authorised workshop as per the schedule specified in the Owner's Manual.
3. Vehicle subjected to abnormal use (accident, motor race, rallies or for the purpose of establishing the records etc.)
4. Use of non MGP (Maruti Genuine Part).
5. Vehicle tempered in an unauthorised manner.
6. Tampering with odometer so that the actual kilometer reading can not be read.
7. Use of adulterated fuel and/or unspecified oils (Engine oil, Transmission oil and Brake oil etc.)
EMISSION WARRANTY
2-4

Downloaded from www.Manualslib.com manuals search engine 1083K
Annexure-A
List of parts covered under Emission Warranty
1. Fuel injection Assembly, Pressure Regulator, Throttle Body Assembly.
2. Electronic Control Module (ECM).
3. Intake Manifold.
4. EGR valve.
5. Distributor and internal parts.
6. Ignitions coil.
7. Canister Assembly.
8. Vapour Liquid Separator.
9. Fuel Tank and Filler Cap.
10. PCV (Positive Crankcase Ventilation) Valve.
11. Oil Filler Cap.
12. Catalytic Convertor.
13. Exhaust manifold.
14. All fuel injection System related SENSORS.
15. High Pressure Fuel Pump.
16. Glow Plug.
17. Glow Plug Controller.
18. ManiverterEMISSION WARRANTY
2-5

Downloaded from www.Manualslib.com manuals search engine 1183KFUEL RECOMMENDATION
FUEL RECOMMENDATION
Petrol Engine
You must use unleaded petrol with an
octane number (RON) of 91 or higher.
Diesel Engine
The diesel fuel should be with cetane num-
ber (CN) higher than 51 and sulphur con-
tent less than 350 ppm (parts per million).
Do not use marine diesel fuel, heating oils
and so forth.
Petrol/Ethanol blends
Blends of unleaded petrol and ethanol (grain
alcohol), also known as gasohol, are
commercially available in some areas.
Blends of this type may be used in your
vehicle if they are no more than 10% etha-
nol. Make sure this petrol-ethanol blend has
octane ratings no lower than those
recommended for petrol.
Petrol/Methanol blends
Blends of unleaded petrol and methanol
(wood alcohol) are also commercially avail-
able in some areas. DO NOT USE fuels
containing more than 5% methanol under any
circumstances. Fuel system damage or
vehicle performance problems resulting from
the use of such fuels are not the
responsibility of MARUTI SUZUKI and may
not be covered under the New Vehicle
Warranty.Fuels containing 5% or less methanol may
be suitable for use in your vehicle if they
contain cosolvents and corrosion inhibitors.
NOTE:
If you are not satisfied with the driveability
or fuel economy of your vehicle when you
are using a petrol/alcohol blend, you should
switch back to unleaded petrol containing no
alcohol.The fuel tank has an air space to
allow for fuel expansion in hot
weather. If you continue to add fuel
after the filler nozzle has automatically
shut off or an initial blowback occurs,
the air chamber will become full.
Exposure to heat when fully fuelled in
this manner will result in leakage due
to fuel expansion. To prevent such
fuel leakage, stop filling after the filler
nozzle has automatically shut off, or
when using an alternative non
automatic system, initial vent
blowback occurs.
CAUTION
CAUTION
Be careful not to spill fuel containing
alcohol while refueling. If fuel is
spilled on the vehicle body, wipe it up
immediately. Fuels containing alcohol
can cause paint damage, which is not
covered under the New Vehicle
Limited Warranty.
3-1

Downloaded from www.Manualslib.com manuals search engine 1283K
BEFORE DRIVING
Keys ...................................................................................................................................... 4-1
Door Locks.......................................................................................................................... 4-2
Keyless Entry System Transmitter (if equipped)......................................................... 4-4
Mirrors................................................................................................................................ 4-13
Heated Rear Window Switch (if equipped).................................................................4-14
Front Seats........................................................................................................................ 4-14
Rear Seats......................................................................................................................... 4-16
Seat Belts and Child Restraint Systems.....................................................................4-18
Supplemental Restraint System (air bags) (if equipped).........................................4-24
Instrument Cluster (For Petrol & Diesel)....................................................................4-28
Warning and Indicator Lights........................................................................................4-29
Speedometer/Odometer/Trip meter/Meter Illumination Control................................4-34
Tachometer (if equipped)................................................................................................4-35
Fuel Gauge........................................................................................................................ 4-35
Lighting Control Lever....................................................................................................4-38
Front Fog Light Switch (if equipped)..........................................................................4-39
Rear Fog Light Switch (if equipped)............................................................................4-39
Headlight Leveling Switch.............................................................................................. 4-39
Turn Signal Control Lever.............................................................................................. 4-40
Hazard Warning Switch...................................................................................................4-40
Windshield Wiper and Washer Lever...........................................................................4-40
Rear Window Wiper/Washer Switch (if equipped).....................................................4-41
Tilt Steering Lock Lever (if equipped) ......................................................................... 4-42
Horn ..................................................................................................................................... 4-42
BEFORE DRIVING

Downloaded from www.Manualslib.com manuals search engine 4083K
BEFORE DRIVING
4-28
1. Speedometer
2. Display
3. "MODE" knob
4. Tachometer (if equipped)
83K-02-07183K-02-070
5. Fuel gauge
6. Warning and indicator lights
7. Clock knob
Instrument Cluster (For Petrol & Diesel)Petrol
Diesel
Service on or around air bag components
or wiring must be performed only by an
authorized MARUTI SUZUKI dealer.
Improper service could result in unintended
air bag deployment or could render the air
bag inoperative. Either of these two
conditions may result in severe injury.
To prevent damage or unintended inflation
of the air bag system, be sure the battery
is disconnected and the ignition switch has
been in the “LOCK” position for at least 90
seconds before performing any electrical
service work on your MARUTI SUZUKI. Do
not touch air bag system components or
wires. The wires are wrapped with yellow
tape or yellow tubing, and the couplers are
yellow for easy identification.
Scrapping a car that has an uninflated air
bag can be hazardous. Contact your
MARUTI SUZUKI authorized dealer, body
repair shop or scrap yard for help with dis-
posal.
According to accident statistics, children are
safer when properly restrained on rear seats
than front passenger’s seat. Whenever
possible, MARUTI SUZUKI recommends
that child restraint systems be installed on
the rear seat.

Downloaded from www.Manualslib.com manuals search engine 4383K
BEFORE DRIVING
4-31
Continuing to drive the vehicle when
the malfunction indicator light is on
can cause permanent damage to the
vehicle’s emission control system, and
can affect fuel economy and
driveability.
CAUTION
Have the system inspected by an authorized
MARUTI SUZUKI dealer.
This light comes on when the ignition switch
is turned to the “ON” position, and goes off
when the engine is started.
If this light comes on while driving, the
power steering system may not work prop-
erly. Have the system inspected by your
MARUTI SUZUKI dealer.NOTE:
If the power steering system does not work
properly, you will feel heavier to steer but
you still will be able to steer.
83K-02-077
Electric Power Steering Light
This light comes on when the ignition switch
is turned to the “ON” position, and goes out
when the engine is started. The light will
come on and remain on if there is
insufficient oil pressure. If the light comes
on when driving, pull off the road as soon
as you can and stop the engine.
Check the oil level and add oil if necessary.
If there is enough oil, the lubrication sys-
tem should be inspected by your MARUTI
SUZUKI dealer before you drive the vehi-
cle again.Oil Pressure Light
83K-02-078
CAUTION
If you operate the engine with this
light on, severe engine damage can
result.
Do not rely on the Oil Pressure
Light to indicate the need to add oil.
Be sure to periodically check the
engine oil level.
Charging LightThis light comes on when the ignition switch
is turned to the “ON” position, and goes off
when the engine is started. The light will
come on and remain on if there is
something wrong with the battery charging
system. If the light comes on when the
engine is running, the charging system
should be inspected immediately by your
MARUTI SUZUKI dealer.High Engine Coolant Temperature
Warning Light (red color)
83K-02-07983K-02-080
When the ignition switch is turned to the
“ON” position, this light comes on briefly so
you can check that the light is working. If
this light blinks while driving, it means the
engine is running hot. Avoid driving condi-

Downloaded from www.Manualslib.com manuals search engine 4583K
BEFORE DRIVING
4-33
will flash along with all of the turn signal
lights.Main Beam (high beam) Indicator
Light
83K-02-086
This indicator comes on when headlight
main beams (high beams) are turned on.
83K-02-087
Water in fuel filter warning light (if
equipped) (For diesel only)If this light comes on, and keeps on glow-
ing, get the water drained from the fuel fil-
ter.
83K-02-08883K-02-088A
Automatic Transmission Warning
Light (if equipped)This light comes on for several seconds
when the ignition switch is turned to the
“ON” position so you can check the light is
working. If this light comes on, there is the
problem with the automatic transmission
system. Ask your MARUTI SUZUKI dealer
to have the system inspected.
Transmission Selector Position
Indicator (if equipped)
83K-02-089
EXAMPLEWhen the ignition switchs in the "ON"
position, the indicator shows the selector
position of automatice transmission.
Rear Fog Light Indicator Light (if
equipped)The rear fog light indicator light comes on
when the rear fog light operates.
