height TESLA MODEL Y 2023 Owners Manual

CAUTION: Depending on configuration (such as
suspension height or wheel selection), your
vehicle

Wearing Seat Belts
Using seat belts and child safety seats is the most
effective way to protect occupants if a collision occurs.
Therefore, wearing a seat belt is required by law in most jurisdictions.
Both the driver and passenger seats are equipped with three-point inertia reel seat belts. Inertia reel belts are automatically tensioned to allow occupants to move
comfortably during normal driving conditions.
To
securely hold child safety seats, all passenger seating
positions are equipped with an automatic locking
retractor (ALR) feature that, by fully extracting the seat
belt (beyond the length needed for a typical adult
occupant), locks the belt into place until the seat belt is
unbuckled.
The seat belt reel automatically locks to prevent
movement of occupants if
Model Y experiences a force
associated with hard acceleration, braking, cornering, or
an impact in a collision.
Seat Belt Reminders
The seat belt reminder on the touchscreen
alerts you if a seat belt for an occupied driver or passenger seat is unbuckled. If all
occupants are buckled up and the
reminder stays on, re-buckle seat belts to
ensure they are correctly latched. Also
remove any heavy objects (such as a
briefcase) from an unoccupied seat. If the
reminder light continues to stay on,
contact Tesla.
You can temporarily disable a seat belt reminder associated with a rear seating position. This is useful when you are carrying an object in a rear seat that
triggers the seat belt reminder alert. To disable the
reminder, touch the associated seat on the seat belt reminder popup message that displays on the touchscreen when a seat belt reminder is active. When a reminder is disabled, the seat belt reminder icon is replaced by a seat icon, for the current drive only. Touch the seat again to re-enable the reminder.
WARNING: Seat belts must be worn by passengers
in all seating positions. Do not disable a seat belt
reminder when the seating position is occupied by
a passenger.
To Fasten a Belt
1.
Ensure correct positioning of the seat (see Correct
Driving Position on page 27).
2.
Draw the belt out smoothly, ensuring the belt lays flat
across the pelvis, chest and mid-point of your collar
bone, between the neck and shoulder.
3. Insert the latch plate into the buckle and press
together until you hear a click indicating it is locked
in place.4.
Pull the belt to check that it is securely fastened.
5.
Pull the diagonal part of the belt toward the reel to
remove excess slack.
To Adjust the Shoulder Anchor
Height
Model Y is equipped with an adjustable shoulder anchor
for each front seat to ensure that the seat belt is positioned correctly. The seat belt should lay
flat across
the mid-point of your collar bone while in the correct driving position
(see Correct Driving Position on page
27). Adjust the height of the shoulder anchor if the seat
belt is not positioned correctly:
1.
Press and hold the button on the shoulder anchor to release the locking mechanism.
2.
While holding the button, move the shoulder anchor up or down, as necessary, to correctly position the seat belt.
3.
Release the button on the shoulder anchor so that it
locks into position.
4.
Without pressing the button, pull on the seat belt webbing and attempt to move the shoulder anchor
downward to check that it is locked into position.
Seat Belts
33Seating and Safety Restraints

Jacking Procedure
Follow the steps below to lift Model Y. Ensure that any
non-Tesla repair facility is aware of these lifting points.
1.
Position Model Y centrally between the lift posts.
2.
Position the lift arm pads under the designated body lift points at the locations shown.
WARNING: DO NOT position the lift arm pads
under the Battery or side rails.
NOTE: The following illustration is provided to
improve conceptual understanding. The exact location of the lift points may
differ slightly. Check
the vehicle itself for exact location of lift points.
3.
Adjust the height and position of the lift arm pads to ensure that they are correctly located.
4.
With assistance, raise the lift to the desired height, ensuring the lift arm pads remain in their correct positions.
5.
Engage any lift safety locks. Follow the lift
manufacturer

Exterior DimensionsAOverall Length187 in4751 mm
B
Overall Width (including mirrors)Overall Width (including folded mirrors)Overall Width (excluding mirrors)83.8 in 77.9 in
75.6 in2129 mm 1978 mm1921 mmCOverall Height64 in1624 mm
DWheel Base113.8 in2890 mm
EOverhang - Front34.4 in875 mm
FOverhang - Rear38.8 in986 mm
GGround Clearance (with 2 passengers)Performance 6.2 in
Non-Performance 6.8 inPerformance 157 mm
Non-Performance 172 mm
H
Track, non 21" wheels - Front
Track, non 21" wheels - Rear
Track, 21" wheels - Front
Track, 21" wheels - Rear
64.4 in
64.4 in
64.8 in 64.2 in
1636 mm
1636 mm
1646 mm
1630 mm
*Values are approximate. Dimensions can vary depending on a vehicle

Understanding Tire Markings
Laws require tire manufacturers to place standardized information on the sidewall of all tires. This information
identifies and describes the fundamental characteristics of the tire. It also provides the tire identification number
(TIN) for certification of safety standards, and in case of a recall.
1.
Tire category: P indicates that the tire is for passenger vehicles.
2.
Tire width: This 3-digit number is the width (in millimeters) of the tire from sidewall edge to sidewall edge.
3.
Aspect ratio: This 2-digit number is the sidewall height as a percentage of the tread width. So, if the tread width is
205 mm, and the aspect ratio is 50, the sidewall height is 102 mm.
4.
Tire construction: R indicates that the tire is of Radial ply construction.
5.
Wheel diameter: This 2-digit number is the diameter of the wheel rim in inches.
6.
Load index: This 2 or 3-digit number is the weight each tire can support. This number is not always shown.
7.
Speed rating: When stated, indicates the maximum speed (in mph) at which the tire can be used for extended
periods. Q=99 mph (160 km/h), R=106 mph (170 km/h), S=112 mph (180 km/h), T=118 mph (190 km/h), U=124 mph (200 km/h), H=130 mph (210 km/h), V=149 mph (240 km/h), W=168 mph (270 km/h), Y=186 mph (300 km/h),
(Y)=vehicle

lane assist: 119
lane change, automatic: 98
Lane Departure Avoidance: 119
liftgate: 18
adjust opening height: 18
opening: 18
lifting: 197
lights: 58, 59, 60
hazard warning: 60
headlights after exit: 59
turn signals: 60
load limits: 208
location tracking: 153
locking: 14
lug nut covers: 187
lumbar adjustment: 27
M
maintenance: 177, 178, 184, 191, 195, 196
cleaning: 191
daily checks: 177
fluid replacement intervals: 178
monthly checks: 177
replacing wiper blades: 195
service intervals: 177
tires: 184
washer fluid, topping up: 195
washer jets, cleaning: 196
map orientation: 153
map updates: 158
mats: 194
media: 159, 162
settings: 159
sources, show and hide: 159
mileage upon delivery: 284
mirrors: 54
mobile app: 151
mobile app access: 151
Mobile Connector: 165, 169
description: 165
using: 169
modifications: 198
motor specifications: 213
My Apps: 8
my car does what?: 162
myQ: 145
programming and using: 145
N
naming your vehicle: 9
Navigate on Autopilot: 101
NHTSA, contacting: 286
O
Obstacle-Aware Acceleration: 122
occupancy sensor, front passenger: 45
occupant classification: 47
odometer: 76
Off-Peak Charging: 174
off-road assist: 69
offset from speed limit: 125
Online Routing: 157
overtake acceleration: 91
Owner Information, about: 281
P
parcel shelf: 19
Park Assist: 70
parking brake: 67
parking, using Autopark: 111
parking, using Summon: 113
parts replacement: 198
passenger detection: 45
passenger detection, front: 45
pedestrian warning: 78
personal data, erasing: 9
phone: 10, 133
authenticating as a key: 10
using: 133
phone app: 134
phone key: 10, 13
adding as a key: 13
removing as a key: 13
PIN: 51
PIN to Drive: 138
power: 66
gained from regenerative braking: 66
power cycling: 55
power socket: 24
power windows: 17, 206
powering on and off: 55
Preconditioning: 174
Proposition 65: 284
public charging stations: 165
R
radio: 159, 162
Radio regulatory information: 286
range: 66, 175
driving tips to maximize: 175
Index
