TOYOTA 4RUNNER 1997 Workshop Manual

54
To adjust a mirror, use the switches.
1. Master switchÐTo select the m
irror to
be adjusted.
Place the switch at Lº (le ft) or Rº (rightº).
2. Control switchÐTo move the mirror
Push the switch in the desired direc- tion.
If the engine is not running, the key mustbe in the ACCº position.
NOTICE
If ice should jam the mirror, do not operate the control or scrape the
mirror face. Use a spray de-icer tofree the mirror.
The rear view mirrors can be folded
backward for parking in restriced areas.
To fold the rear view mirror, push back- ward.To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror. Daylight drivingÐLever at position 1
The reflection in the mirror has greater
clarity at this position. Night drivingÐLever at position 2 Remember that by reducing glare you
also lose some rear view clarity.
ÐFolding rear view mirrors
Anti-glare inside rear view mirror

Part 1Headlights and turn signals
55
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-4
Lights, Wipers and Defogger
Headlights and turn signals
Emergency flashers
Instrument panel light control
Interior lights
Personal lights
Luggage compartment light
Ignition switch light
Windshield wipers and washer
Back window wiper and washer
Back window defogger
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob. Position 1ÐParking, tail, license plate,
side marker and instrument panel lights Position 2ÐHeadlights and all of the above
If you turn the ignition switch to the lockº
position with the headlights left on, a
buzzer reminds you to turn the lights off
when you open the driver's door.
NOTICE
To prevent the battery from being discharged, do not leave the lights
on for a long period when theengine is not running.
Daytime running light system (Canada only)
The headlights turn on when the parking brake is released with the engine started,
even with the light switch in the OFFº position. They will not go off until the igni-
tion switch is turned off.
To turn on the other exterior lights and in-
strument panel lights, twist the knob to the
position 1.
Under the daytime running light system,
the headlights turn on at reduced intensi-
ty. Twist the knob to the position 2 to turn
to full intensity for driving at night.

56
High-Low beamsÐFor high beams,
turn the headlights on and push the lever away from you (position 1). Pull the lever
toward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will tell
you that the high beams are on.
Flashing the high beam headlights
(position 3)ÐPull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights with knob turned to OFFº.TURN SIGNAL
To signal a turn, push the headlight/
turn signal lever up or down to posi-
tion 1. The key must be in the ONº position. The lever automatically returns after you make a turn, but you may have to return it by hand after you change lanes.
To signal a lane change, move the lever
up or down to the pressure point (position 2) and hold it.
If the turn signal indicator lights (green
lights) on the instrument panel flash faster
than normal, a front or rear turn signal bulbis burned out.To turn on the emergency flashers,
push the switch.
All the turn signal lights will flash. To turn
them off, push the switch once again.
Turn on the emergency flashers to warn other drivers if your vehicle must be
stopped where it might be a traf fic hazard.
Always pull as far off the road as possible.
The turn signal light switch will not work
when the emergency flashers are operat- ing.
Emergency flashers

57
NOTICE
To prevent the battery from being discharged, do not leave the lights
on for a long period when the engine is not running.
To adjust the brightness of the instru-
ment panel lights, turn the knob.To turn on the interior light, slide the switch.
The interior light switch has the following positions: ONºÐ Keeps the light on all the time.
OFFºÐ Turns the light off.
DOORºÐ Turns the light on when any of
the side door is opened. The light goes off
when all the side door is closed.
Instrument panel light control Interior light

58
To turn on the personal light, push the
switch. To turn the lights off, push the
switch once again.To turn on the luggage compartment
light, slide the switch.
The luggage compartment light switch has the following positions: ONºÐ Keeps the light on all the time.
OFFºÐ Turns the light off.
DOORºÐ Turns the light on when the
back door is opened. The light goes off
when all the side door is closed.For easy access to the ignition switch,
the ignition switch light comes on
when the driver's door is opened.
The light remains on for a some time after
the driver's door is closed.
Ignition switch light
Personal lights Luggage compartment light

59
To turn on the windshield wipers, move the lever to the desired setting. The key must be in the ONº position.Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
The INT TIMEº band lets you adjust the wiping time interval when the wiper lever is in the intermittent position (position 1).
Twist the band upward to increase the
time between sweeps, and downward to
decrease it. To squirt washer fluid, pull the lever to-
ward you and release it.
If the windshield wipers are off, they will
operate a
couple of times after the washer
squirts.
For instructions on adding washer fluid, see Adding washer fluidº in Chapter 7-3.
In freezing weather, warm the windshield with the defroster before using the wash-
er. This will help prevent the washer fluid
from freezing on your windshield, which can block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It may scratch the
glass.To turn on the windshield wipers, move the lever to the desired setting. The key must be in the ONº position.
Lever position
Speed setting
Position 1Slow
Position 2Fast
For a single sweep of the windshield, push the lever up and release it.
To squirt washer fluid, push the button
at the end of the lever.
For instructions on adding washer fluid, see Adding washer fluidº in Chapter 7-3.
Windshield wipers and washer (intermittent type)
Wind shield wipers andwasher (mist type)

60In freezing weather, warm the windshield with the defroster before using the wash-
er. This will help prevent the washer fluid
from freezing on your windshield, which can block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It may scratch the
glass.
To turn on the back window wiper,
twist the lever knob upward. The key must be in the ONº position.
Lever position
Speed setting
Position 1Intermittent
Position 2Normal
To squirt washer fluid on the back window,
twist the knob upward or downward as far
as it will go (position 3 or 4). The knob au-
tomatically returns from these positions
after you release it.
For instructions on adding washer fluid, see Adding washer fluidº in Chapter 7-3.
NOTICE
Do not operate the back window wipers if the back window is dry. It
may scratch the glass.
Back window wiper and washer

61
To defog or defrost the back window,
push the switch. The key must be in the ONº position.
The thin heater wires on the inside of the back window will quickly clear the surface.
An indicator light will illuminate to indicate the defogger is operating. Push the switch once again to turn the de-
fogger off.
Make sure you turn the defogger off when
the window is clear. Leaving the defogger on for a long time could cause the battery
to discharge, especially during stop-and-
go driving. The defogger is not designed
for drying rain water or for melting snow.
NOTICE
Avoid driving with the tailgate open.
To prevent the battery from being
discharged, turn the switch onwhen the engine is running.
When cleaning the inside of theback window, be careful not to
scratch or damage the heaterwires.
Back window defogger

62

Part 1Fuel gauge
63
OPERATION OF INSTRUMENTS ANDCONTROLSÐ
Chapter 1-5 Gauges, Meters and Service reminderindicators
Fuel gauge
Engine coolant temperature gauge
Tachometer
Odometer and trip meter
Service
reminder indicators and
warning buzzers
The gauge works when the ignition
switch is on and indicates the approxi-
mate quantity of fuel remaining in the tank. Nearly fullÐNeedle at Fº Nearly emptyÐNeedle at Eº
It is a good idea to keep the tank over 1/4 full.
This fuel gauge has a non-return type
needle wh ich remains at the last indicated
position when the ignition switch is turned
off.
If the fuel level approaches Eº or the low fuel level warning light comes on, fill the fuel tank as soon as possible. If the fuel tank is completely empty, the malfunction
indicator lamp comes on. Fill
the fuel tank immediately.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer assoon as possible.
