4RUNNER (1998)
CAUTION
Always observe the following pre-
cautions to minimize the risk of
serious personal injury or damage
to your vehicle: Avoid sharp turns or abrupt ma-
neuvers, if at all possible. As
with other vehicles of this type,
failure to operate this vehicle
correctly may result in loss of
control or vehicle rollover.
Avoid loading any items on the
roof that will make the center
of gravity even higher.
Always slow down in gusty
crosswinds. Because of its high
center of gravity, your vehicle
is more sensitive to side winds
than an ordinary passenger car.
Slowing down will allow you to
have much better control.
Do not drive horizontally across
steep slopes. Driving straight
up or straight down is pre-
ferred. Your vehicle (or any sim-
ilar off- road vehicle) can tip
over sideways much more easi-
ly than forward or backward.When driving off- road or in
rugged terrain, do not drive at
excessive speeds, jump the ve-
hicle, or strike objects, etc.
This may cause loss of control
or vehicle rollover. You are also
risking expensive damage to y-
our vehicle's suspension and
chassis.
Break- in period
Drive gently and avoid high speeds.
Your vehicle does not need an elabo-
rate break- in. But following a few sim-
ple tips for the first 1600 km (1000
miles) can add to the future economy
and long life of your vehicle:
Do not drive over 88 km/h (55
mph).
Run the engine at moderate speed
between 2000 and 4000 rpm.
Avoid full- throttle starts.
Try to avoid hard stops during the
first 300 km (200 miles).
Do not drive slowly with the manu-
al transmission in a high gear.
Do not drive for a long time at any
single speed, either fast or slow.
Do not tow a trailer during the first
800km (500miles).

4RUNNER (1998)
Part 4
IN CASE OF AN
EMERGENCY
If your vehicle will not start
If your engine stalls while
driving
If your vehicle overheats
If you have a flat tire
If your vehicle needs to be
towed
If you cannot shift automatic
transmission selector lever
If you lose your keys
Before making these checks, make
sure you have followed the correct
starting procedure given in ºHow to
start the engineº in Part 3 and that
you have sufficient fuel.
If the engine is not turning over or
is turning over too slowlyÐ
1. Check that the battery terminals are tight and clean.
2. If the battery terminals are O.K., switch on the interior light.
3. If the light is out, dim or goes out when the starter is cranked, the
battery is discharged. You may try
jump starting. See º(c) Jump start-
ingº for further instructions.
If the light is O.K., but the engine still
will not start, it needs adjustment or
repair. Call a Toyota dealer or quali-
fied repair shop.
NOTICE
Do not pull- or push- start the ve- hicle. It may damage the vehicleor cause a collision when the en-
gine starts. Also the three- way
catalytic converter may overheatand become a fire hazard.
If the engine turns over at its nor-
mal speed but will not startÐ
1. Check that all the push- on connec- tors are tight. (For example, con-
nections at the spark plugs, ignition
coil and/or distributor)
2. If the connectors are O.K., the en- gine may be flooded because of
repeated cranking. See º(b) Start-
ing a flooded engineº for further
instructions.
If your vehicle will not start
Ð
(a) Simple checks

4RUNNER (1998)
(b) Starting a flooded engine
If the engine will not start, your
engine may be flooded because of
repeated cranking.
If this happens, turn the key to
ºSTARTº with the accelerator pedal
held down. Keep the key and acceler-
ator pedal so for 15 seconds and re-
lease them. Then try starting the en-
gine with your foot off the accelerator
pedal.
If the engine does not start after 15
seconds of cranking, release the key,
wait a few minutes and try again.
If the engine still will not start, it
needs adjustment or repair. Call a
Toyota dealer or qualified repair shop
for assistance.
NOTICE
Do not crank for more than 30 seconds at a time. This may over-heat the starter and wiring sys-tems.
(c) Jump starting
To avoid serious personal injury
and damage to your vehicle which
might result from battery explosion,
acid burns, electrical burns, or dam-
aged electronic components, these
instructions must be followed pre-
cisely.
If you are unsure about how to follow
this procedure, we strongly recom-
mend that you seek the help of a
competent mechanic or towing service.
CAUTION
Batteries contain sulfuric acid
which is poisonous and corro-
sive. Wear protective safety
glasses when jump starting, and
avoid spilling acid on your skin, clothing, or vehicle.
If you should accidentally get
acid on yourself or in your
eyes, remove any contaminated
clothing and flush the affected
area with water immediately.
Then get immediate medical
attention. If possible, continue
to apply water with a sponge or
cloth while en route to the med-
ical office.
The gas normally produced by
a battery will explode if a flame
or spark is brought near. Use
only standardized jumper cables
and do not smoke or light a
match while jump starting.
NOTICE
The battery used for boosting
must be 12 V. Do not jump startunless you are sure that thebooster battery is correct.

4RUNNER (1998)
JUMP STARTING PROCEDURE
1. If the booster battery is installed in another vehicle, make sure the ve-
hicles are not touching. Turn off all
unnecessary lights and accesso-
ries.
2. If required, remove all the vent plugs from the booster and dis-
charged batteries. Lay a cloth over
the open vents on the batteries.
(This helps reduce the explosion
hazard, personal injuries and
burns.)
3. If the engine in the vehicle with the booster battery is not running, start
it and let it run for a few minutes.
During jump starting run the engine
at about 2000 rpm with the accel-
erator pedal lightly depressed.

4RUNNER (1998)
CAUTION
When making the connections, to
avoid serious injury, do not lean
over the battery or accidentally
let the jumper cables or clamps
touch anything except the correct
battery terminals or the ground.
5. Start your engine in the normal
way. After starting, run it at about
2000 rpm for several minutes with
the accelerator pedal lightly de-
pressed.
6. Carefully disconnect the cables in the exact reverse order: the nega-
tive cable and then the positive
cable.
7. Carefully dispose of the battery cover clothsÐthey may now con-
tain sulfuric acid.
8. If removed, replace all the battery vent plugs.
If the cause of your battery discharg-
ing is not apparent (for example,
lights left on), you should have it
checked. If your engine stalls while driving...
1. Reduce your speed gradually, keep- ing a straight line. Move cautiously
off the road to a safe place.
2. Turn on your emergency flashers.
3. Try starting the engine again.
If the engine will not start, see ºIf
your vehicle will not startº.
CAUTION
If the engine is not running, the
power assist for the brakes and
steering will not work so steering
and braking will be much harder
than usual.
If your vehicle overheats
If your engine coolant temperature
gauge indicates overheating, if you
experience a loss of power, or if
you hear a loud knocking or ping-
ing noise, the engine has probably
overheated. You should follow this
procedure... 1. Pull safely off the road, stop the vehicle and turn on your emergen-
cy flashers. Put the transmission in
ºPº (automatic) or neutral (manual)
and apply the parking brake. Turn
off the air conditioning if it is being
used.
2. If coolant or steam is boiling out of the radiator or reservoir, stop the
engine. Wait until the steam sub-
sides before opening the hood. If
there is no coolant boiling over or
steam, leave the engine running.
CAUTION
To help avoid personal injury,
keep the hood closed until there
is no steam. Escaping steam or
coolant is a sign of very high
pressure.
