garage door opener TOYOTA 4RUNNER 2000 Owners Manual

22000 4Runner (OM35762U)
Instrument panel overview
1. Side vents
2. Tilt steering lock release lever
3. Instrument cluster
4. Center vents
5. Garage door opener box or eyeglass
holder
6. Electric moon roof switch
7. Personal lights
8. Glove box
9. Power door lock switches
10. Power window switches
11. Automatic transmission selector lever
or manual transmission gear shift lever
12. Parking brake lever
13. Front drive control lever
14. Lower vent
15. Hood lock release lever
16. Fuel filler door opener
17. Window lock switch
18. Power rear view mirror control switch
(with power windows)
ProCarManuals.com

1532000 4Runner (OM35762U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Other equipment
Clock154 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermometer154 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray155 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlets156 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box156 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garage door opener box157 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Eyeglass holder159 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary box160 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning reflector holder160 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear console box161 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Card holder162 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front cup holders162 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear cup holders163 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tie- down hooks164 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage cover164 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat165 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1- 9
ProCarManuals.com

1572000 4Runner (OM35762U)
Garage door opener box
The box is designed to store a garage
door opener transmitter.
Open the cover and remove the Velcro
loop.Remove the paper strip covering the adhe-
sive on back side of loop and adhere loop
to back side of the transmitter near cen-
ter.Please note if transmitter has wire clip for
sun visor, this clip must be removed prior
to adhesion of the Velcro.
ProCarManuals.com

1582000 4Runner (OM35762U)
Place the transmitter with Velcro loop fac-
ing inside of box into the box. Make sure
the transmitter button is located above
button pins.Remove spacers from the box. Place the
largest spacer on the pin that would be
below transmitter button when the cover is
closed. Close the cover.When the garage door opener transmitter
is properly installed, you can operate the
transmitter by pushing the cover.
ProCarManuals.com

1592000 4Runner (OM35762U)
If the spacer does not contact with your
garage door opener transmitter:

Check to see if spacer is on correct
pin.

Attach another spacer to the top of
original spacer. Check operation. If re-
quired, continue add spacers until con-
tact is achieved.
If the transmitter is clattering during driv-
ing, fill in a piece of felt or pad to prevent
the transmitter from clattering.Put the remained spacers back in its
place.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the garage door opener
box closed while driving.
Eyeglass holder
To use the eyeglass holder, open the
lid.
CAUTION

To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the eyeglass
holder closed while driving.

As this holder is designed for hold-
ing eyeglasses, do not place any
object heavier than approximately
50g (0.11 lb.) in it. Heavier objects
may cause the holder to open and
contents to fly out resulting in inju-
ries.
