Indicator symbols on the instrument panel
or
Driver ’s seat belt reminder light∗
1
Low oil pressure warning light∗
1
Low fuel level warning light∗
1
Brake system warning light∗
1
Malfunction indicator lamp∗
1
Discharge warning light∗
1
Antilock brake system warning light∗
1
Automatic transmission fluid temperature
warning light∗
1
SRS warning light∗
1
Unengaged “Park” warning light∗
1
Open door warning light∗
1
Low windshield washer fluid level warning
light∗
1
Headlight high beam indicator light Turn signal indicator lights
Front passenger ’s seat belt reminder light∗
1
Vehicle skid control system and traction control
system (twowheel drive models) or active
traction control system (fourwheel drive models)
warning light
∗
1
ProCarManuals.com

’01 4Runner_U (L/O 0008)
842001 4RUNNER (OM35768U)
Headlights and turn signals
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1—Parking, tail, license plate,
side marker and instrument panel lights
Position 2—Headlights and all of the
above
The lights automatically turn off when the
driver ’s door is opened with the ignition
switch turned off. To turn them on again,
turn the key to the “ON” position or actu-
ate the headlight switch. If you are going
to park for over one week, make sure the
headlight switch is off.
NOTICE
To prevent the battery from being dis-
charged, do not leave the lights on
for a long period when the engine is
not running.
Daytime running light system (on some
models)
The headlights turn on when the parking
brake is released with the engine started,
even with the light switch in the “OFF”
position. They will not go off until the
ignition switch is turned off.
To turn on the other exterior lights and
instrument panel lights, twist the knob to
the position 1.
Under the daytime running light system,
the headlights turn on at reduced intensity.
Twist the knob to the position 2 to turn
to full intensity for driving at night.
HighLow beams—For high beams, turn
the headlights on and push the lever away
from you (position 1). Pull the lever to-
ward you (position 2) for low beams.
The headlight high beam indicator light
(blue light) on the instrument panel will
tell you that the high beams are on.
Flashing the high beam headlights
(position 3)—Pull the lever all the way
back. The high beam headlights turn off
when you release the lever.
You can flash the high beam headlights
with the knob turned to “OFF”.
ProCarManuals.com

’01 4Runner_U (L/O 0008)
2752001 4RUNNER (OM35768U)
Engine compartment
(with daytime running light system)
5. DOME 15 A: Interior lights, personal
lights, luggage compartment light,
clock, car audio system, gauges and
meters, ignition switch light, vanity mir-
ror light, daytime running light
6. OBD 7.5 A: Onboard diagnosis sys-
tem
7. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
8. HEAD(RH) 10 A: Righthand headlight,
gauges and meters
9. HEAD(LH) 10 A: Lefthand headlight
Instrument panel
10. TAIL 10 A: Tail lights, license plate
lights, instrument panel lights
11. A.C 10 A: Air conditioning system
12. MIR HTR 10 A: Outside rear view mir-
ror heaters
13. DEFOG 15 A: Back window defogger
14. ETCS 15 A: Multiport fuel injection
system/sequential multiport fuel injec-
tion system
15. DRL 7.5 A: Daytime running light sys-
tem
16. HEAD (HI RH) 10 A: Righthand head-
light (high beam), gauges and meters17. HEAD (HI LH) 10 A: Lefthand head-
light (high beam)
18. HEAD (LO RH) 10 A: Righthand
headlight (low beam)
19. HEAD (LO LH) 10 A: Lefthand head-
light (low beam)
20. TOWING 25 A: Trailer lights (backup
lights, rear turn signal lights, stop/tail
lights)
21. SEAT HTR 20 A: Seat heater
22. FOG 15 A: Front fog lights
23. ECUIG 10 A: Cruise control system,
antilock brake system, vehicle skid
control system, SRS airbag system,
electronically controlled automatic
transmission system, power antenna,
power window, electric moon roof, pow-
er back window, back window defogger,
back window wiper
24. TURN 10 A: Turn signals lights, emer-
gency flashers
25. WIPER 25 A: Windshield wipers and
washer, power door lock control sys-
tem, back window defogger, horns,
theft deterrent system
26. 4WD 20 A: A.D.D. control system,
fourwheel drive control system, center
differential lock system
