display TOYOTA 4RUNNER 2003 N210 / 4.G Navigation Manual

4Runner_Navi_U (L/O 0208)
872003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
INFORMATION
If you try to change the map to an
inappropriate scale, a message ap-
pears.
 For magnification or reduction of
the map scale, see page 57.
1. Touch the “Delete” switch to display the “Del ete area to avoid” screen.
L00126
2. Select the area you want to delete.
(c) Deleting area to avoid

4Runner_Navi_U (L/O 0208)
882003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
Delete all: All the areas to avoid regis-
tered in the system are deleted.
L00127
L00128
3. Either of the above messages appears.
To delete the area(s), touch the
“Yes”
switch.
If you want to try again or cancel the
deletion, touch the
“No” switch. The
previous screen will return. The current vehicle position mark will
be automatically corrected during driv-
ing on reception of GPS signals. If
your vehicle cannot receive GPS sig-
nals, you can correct the current posi-
tion mark manually.
L00059
1. Touch the “MENU” tab on the screen to display
the “Menu” screen, and touch the “Setup” switch.
Current position calibration

4Runner_Navi_U (L/O 0208)
932003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
You can set the values shown on the
Setup screen.
1. Touch the
“MENU” tab on the screen.
L00059
2. Touch the “Setup” switch to display the “Setup” screen. Select your desired items you want to set. Selected items
will be highlighted in green.
L00147
3. Touch the “OK” switch on the screen and the previous screen returns.
To default: Touch the
“Default”
switch on the screen. All of the settings
can be defaulted.
Map color (day or night): You can se-
lect your desired map color. Auto reroute:
You can set the system
will or will not automatically search for a
new route to the destination. Estimated travel time:
You can set to
display the time required to reach the
destination on the road guidance screen.
Adjust time zone: You can select your
desired time zone.
Setup

4Runner_Navi_U (L/O 0208)
942003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
Distance: You can change “km” or
“miles” to display your desired units.
Notify seasonal restrict: You can select
to notify or not to notify a seasonal re-
striction.
Voice guidance in all modes: You can
set the voice guide in all mode or not.
Current street name: You can select to
show or not to show a current street
name on the map screen.
1. Touch the
“MENU” tab on the screen.
2. Touch the
“Setup” switch.
L00152
3. Select your desired day and/or night map color and then touch the “OK” switch to return to the map screen. See “Map
color list” below for details.
Touch the
“Normal” switch to select
the default the map color.
Touch the
“Auto” switch to have the
map color selected automatically. The
map color changes every three months. Map color list
Switch NO.Map color“Auto”
mode
1GreenMar. −May
2BlueJun. −Aug.
3GraySep. −Nov.
4BeigeDec. −Feb.
Map color

4Runner_Navi_U (L/O 0208)
962003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
1. Touch the “MENU” tab on the screen to display the “Menu” screen, and touch the “Setup” switch.
L00059
L00133
2. Touch the “On” switch of “Auto reroute”. If you can not find the item on the list, touch or to scroll up or
down the list.
INFORMATION
If your vehicle leaves the guidance
route, the system searches for a new
route to the destination. The new
route may or may not take you back
to the previous route depending on
how far you are off the original guid-
ance route.When the “Estimated travel time” fea-
ture is turned on, the time required to
reach the destinatio n is displayed on
the route guidance screen.
L00059
To turn the “Estimated travel time” on:
Estimated travel time

4Runner_Navi_U (L/O 0208)
972003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
1. Touch the “MENU” tab on the screen to display the “Menu” screen, and touch the “Setup” switch.

4Runner_Navi_U (L/O 0208)
1002003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
INFORMATION
The displayed time to the destina-
tion is the approximate driving time
calculated based on the speeds
you selected and y our actual posi-
tion along the guidance route.
 The time shown may vary greatly
depending on your progress along
the route (which may be affected
by road conditions such as traffic
jams, construction work, etc.)
 Up to 99 hours 59 minutes can be
displayed.
Adjusting time zone

4Runner_Navi_U (L/O 0208)
1022003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
3. Touch the “Adjust” switch. The “Adjust time zone” screen appears on the display.
L00163
4. Select your desired time zone. The se lected switch is highlighted in green.
Touch the
“On” switch and then touch
or to set daylight saving time.
5. Touch the
“OK” switch on the screen. Th e “Setup” screen returns.

4Runner_Navi_U (L/O 0208)
1082003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
The current street name appears on the
map screen.
L00148L00136
This system has a function which in-
forms you of the time to replace cer-
tain parts or components as well as
other information shown on the
screen. (See “INFORMATION ITEMS”
on page 110.) When the system begins
operating after reaching either the In-
formation Item’s date or driving dis-
tance, the “Information” screen will be
displayed.
To avoid seeing the “Information” screen
again, touch the
“Do not display
this message again”
switch.
NZN044
Maintenance information

4Runner_Navi_U (L/O 0208)
1092003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
1. Push the “INFO” button to display the “Information Menu” screen, and then touch the “Maintenance” switch.
L00137
2. Touch your desired icon and input the conditions.
