Page 252 of 412
’04 4Runner_U (L/O 0308)
244
2004 4RUNNER from Aug. ’03 Prod. (OM35811U)
CAUTION
When doing the circling calibration,
be sure to secure a wide space,
and watch out for people and ve-
hicles in the neighborhood. Do not
violate any local traffic rules while
performing circling calibration.
Do not adjust the display while the
vehicle is moving. Be sure to adjust
the display only when the vehicle is
stopped.
The rear view monitor system assists
the driver by displaying images of the
rear of the vehicle during backing up.
The displayed image on the screen is
a horizontally reversed mirror image of
the inside rear view mirror.
To display the rear view on the screen,
place the selector lever in the “R” posi-
tion when the ignition switch in the
“ON” position.
If you move the selector lever out of the
“R” position, the screen returns to the
previous screen. Operating another func-
tion of the navigation system will display
another screen.
The rear view monitor system is an auxil-
iary device intended to back up. When
backing up, be sure to check behind and
all around the vehicle visually.
CAUTION
Do not rely entirely on the rear
view monitor system.
Use caution just as you would when
backing up any vehicle.
Never back up while looking only at
the screen. The image on the
screen may differ from actual con-
ditions. If you back up while look-
ing only at the screen, you may hit
a vehicle or have an unexpected
accident. When backing up, be sure
to check behind and all around the
vehicle visually and with mirrors
before proceeding.
NOTICE
Do not use the system when the
back door is not completely closed.
If the back of the vehicle is hit, the
position and mounting angle of the
camera may slip. Be sure to have
the camera’s position and mounting
angle checked at your Toyota deal-
er.
If the temperature changes rapidly,
such as when hot water is poured
on it in cold weather, the system
may not operate normally.
Rear view monitor system
Page 403 of 412
’04 4Runner_U (L/O 0308)
395
2004 4RUNNER from Aug. ’03 Prod. (OM35811U)
Engine compartment
Fuses (type A)
1. SPARE 10 A: Spare fuse
2. SPARE 15 A: Spare fuse
3. STOP 10 A: Stop/tail lights, high
mounted stoplight, shift lock control
system, anti −lock brake system, trac-
tion control system (two −wheel drive
models), active traction control system
(four −wheel drive models), vehicle sta-
bility control system, rear height control
air suspension, multiport fuel injection
system/s equential multiport fuel injec-
tion system, trailer brake controller,
trailer lights (tail lights)
Instrument panel
4. AC115V INV 15 A: AC inverter
5. FR FOG 15 A: Front fog lights
6. OBD 7.5 A: On−board diagnosis sys-
tem
7. HEAD (LO RH) 10 A: Right −hand
headlight (low beam)
8. HEAD (LO LH) 10 A: Left−hand head-
light (low beam)
9. HEAD (HI RH) 10 A: Right −hand head-
light (high beam)
10. HEAD (HI LH) 10 A: Left −hand head-
light (high beam) 11. EFI NO.2 10 A:
Multiport fuel injection
system/s equential multiport fuel injec-
tion system
12. HEATER NO.2 7.5 A: Air conditioning
system
13. AIRSUS NO.2 10 A: Rear height con-
trol air suspension
14. SEAT HEATER 25 A: Seat heaters
15. DEFOG 30 A: Back window defogger,
multiport fuel injection system/sequen-
tial multiport fuel injection system
16. MIR HEATER 10 A: Outside rear view
mirror heater
17. DOME 10 A: Interior light, personal
lights, wireless remote control system,
door courtesy lights, rear seat audio
system, gauge and meter, vanity lights,
instrument panel lights, running board
lights, multiplex communication system
18. RADIO NO.1 20 A: Audio system, nav-
igation system
19. ECU B 10 A: Anti−lock brake system,
navigation system, traction control sys-
tem (two −wheel drive models), active
traction control system (four −wheel
drive models), vehicle stability control
system, air c onditioning system, multi-
plex communication system, theft deter-
rent system
Fuses
