Explanation of Maintenance Items
Scheduled Maintenance Logs38
Engine Valve Clearance
Inspect for excessive lifter noise and engine vibration and adjust if necessary.
A qualified technician should perform this operation.
Exhaust Pipes and Mountings
Visually inspect the exhaust pipes, muffler and hangers for cracks, deterioration
and damage. Start the engine and listen carefully for any exhaust gas leakage.
Tighten connections or replace parts as necessary.
Fuel Lines and Connections, Fuel Tank Band and
Fuel Tank Vapor Vent System Hoses
Visually inspect for corrosion, damage, cracks and loose or leaking connections.
Tighten connections or replace parts as necessary.
Fuel Tank Cap Gasket
Visually inspect for cracks, deterioration and damage and replace if necessary.
Nuts and Bolts on Chassis and Body
Re-tighten the seat-mounting bolts and front/rear suspension member retaining
bolts to specified torque.
Propeller Shaft
Lubricate the propeller shaft spiders and slide yokes with lithium-base chassis grease
and the double cardan joint with molybdenum-disulfide lithium-base chassis grease,
and re-torque the bolt. Only a qualified technician should re-torque the bolt.
Radiator Core and Condenser
Inspect for debris and signs of damage. Have any problem repaired immediately
by a qualified technician.
Spark Plugs
Replace at specified intervals. Install new plugs of the same type as originally
equipped. A qualified technician should perform this operation.
Steering Gear Box
Inspect for signs of leakage. If you discover any leakage, have it repaired imme-
diately by a qualified technician.
Page 42 of 58

Explanation of Maintenance Items
Scheduled Maintenance Logs39
Steering Linkage and Boots
With the vehicle stopped, check for excessive freeplay in the steering wheel.
Inspect the linkage for bending and damage and the dust boots for deterioration,
cracks and damage. Replace any damaged parts. A qualified technician should
perform these operations.
Timing Belt
Replace every 90,000 miles. A qualified technician should perform this operation.
Tire Rotation
Tires should be rotated at specified intervals according to the instructions in the
Owner’s Manual. When rotating tires, check for damage and uneven wear.
Replace if necessary.
Transfer Case Oil
Inspect or replace at specified intervals. When performing inspections, check for
signs of leakage. If you discover any leakage, have it repaired by a qualified tech-
nician immediately.
Wheel Bearing and Drive Shaft Bushing Grease
Repack the wheel bearings with wheel bearing grease and the drive shaft
bushing with molybdenum-disulfide lithium-base chassis grease. A qualified
technician should perform these operations.
Page 55 of 58

Service Agreements and Pre-Paid Maintenance
Toyota Maintenance and Repair Support52
Toyota Extra Care Vehicle Service Agreements
Toyota Extra Care Vehicle Service Agreements enhance the scope and/or length of
protection for your vehicle by providing coverage in addition to your vehicle’s
factory warranty, or providing protection if the original warranty has expired.
1
Toyota Extra Care provides for the repair or replacement of covered components
that have mechanical failures and protects you from rising repair costs in the
future. In addition, many plans include benefits such as towing, substitute trans-
portation and travel protection with lodging and meals.
Toyota Extra Care Vehicle Service Agreements are accepted at all participating Toyota
dealerships in the United States and Canada. That means repairs are made by
factory-trained service technicians using Genuine Toyota Parts.
Toyota Financial Services offers several Toyota Extra Care Vehicle Service Agreement
plans, each with a variety of time and mileage options.
2Your Toyota dealer can
help you select the plan that best meets your needs.
Toyota Auto Care Prepaid Maintenance Program
The Toyota Auto Care Prepaid Maintenance Program provides a convenient way to
prepay for your vehicle’s regularly scheduled maintenance and protects you from
the rising cost of service.
Toyota Auto Care Classic Prepaid Maintenance Plans are available for both new
and used vehicles. Benefits include oil-and-filter changes, lubrication of key
chassis parts, 19-point inspections at predetermined service intervals, timed
service reminders and a computerized history of each service visit. In addition,
24-hour roadside assistance is included with most plans.
3Premium Plans (avail-
able for new vehicles only) also include tire rotations and major maintenance
services at 15,000, 30,000 and 45,000 miles.
The Toyota Auto Care Program offers two coverage levels as well as several options
for service intervals, time and mileage. Your Toyota dealer can help you select the
prepaid maintenance plan that is best for you.
1Vehicle service agreements are offered by Toyota Motor Insurance Services, Inc., administered by Toyota
Motor Services Company in certain states. In Florida, offered by Toyota Motor Insurance Company.
2Toyota Financial Services is a service mark of Toyota Motor Insurance Services, Inc.3See individual plans for details on applicability.
