Page 260 of 426

’05 4Runner_U (L/O 0504)
250
The compass indicates the direction
that the vehicle is heading. In the
above case, it shows that the vehicle is
heading north.
Displays
Directions
N
NE E
SE
S
SW W
NWNorth
Northeast East
Southeast
South
Southwest West
Northwest
The compass may not show the correct
direction in the following conditions:
The vehicle is stopped immediately af-
ter turning.
The compass does not adjust while the
vehicle is stopped.
The ignition switch is turned off imme-
diately after turning.
The vehicle is on an inclined surface.
The vehicle is in a place where the
earth’s magnetic field is subject to in-
terference by artificial magnetic fields
(underground parking, under a steel
tower, between buildings, roof parking,
near a crossing, near a large vehicle,
etc.).
The vehicle is magnetized. (There is a
magnet or a metal object on or near
the inside rear view mirror.)
The battery has been disconnected.
If your vehicle is out of the set zone,
refer to “CALIBRATING THE COMPASS”
below to set the zone number.
If the deviation is small, the compass
works to calibrate the direction automati-
cally while the vehicle is in motion.
For additional precision or for complete
calibrating, see “CALIBRATING THE
COMPASS” below.
Compass sensor
The compass sensor is on the wind-
shield.
NOTICE
Do not put magnets or a metal object
on or near the inside rear view mirror
of the vehicle. Doing this may cause
malfunction of the compass sensor.
Page 300 of 426

’05 4Runner_U (L/O 0504)
290
Depressing the brake pedal on slippery
road surfaces such as on a manhole cov-
er, a steel plate at a construction site,
joints in a bridge, etc. on a rainy day
tends to activate the anti −lock brake sys-
tem.
You may hear a click or motor sound in
the engine compartment for a few seconds
when the engine is started or just after
the vehicle begins to move. This means
that the anti −lock brake system is in the
self −check mode, and does not indicate a
malfunction.
When the anti lock brake system is ac-
tivated, the following conditions may
occur. They do not indicate a malfunc-
tion of the system:
You may hear the anti −lock brake sys-
tem operating and feel the brake pedal
pulsating and the vibrations of the ve-
hicle body and steering wheel. You
may also hear the motor sound in the
engine compartment even after the ve-
hicle is stopped.
At the end of the anti −lock brake sys-
tem activation, the brake pedal may
move a little forward.
CAUTION
Do not overestimate the anti lock
brake system: Although the anti lock
brake system assists in providing ve-
hicle control, it is still important to
drive with all due care and maintain
a moderate speed and safe distance
from the vehicle in front of you, be-
cause there are limits to the vehicle
stability and effectiveness of steering
wheel operation even with the anti
lock brake system on.
If tire grip performance exceeds its
capability, or if hydroplaning occurs
during high speed driving in the rain,
the anti lock brake system does not
provide vehicle control.
Anti lock brake system is not de-
signed to shorten the stopping dis-
tance: Always drive at a moderate
speed and maintain a safe distance
from the vehicle in front of you.
Compared with vehicles without an
anti lock brake system, your vehicle
may require a longer stopping dis-
tance in the following cases:
Driving on rough, gravel or snow
covered roads.
Driving with tire chains installed.
Driving over the steps such as the
joints on the road.
Driving on roads where the road
surface is pitted or has other differ-
ences in surface height.
Install all 4 tires of specified size at
appropriate pressure: The anti lock
brake system detects vehicle speeds
using the speed sensors for respec-
tive wheels’ turning speeds. The use
of tires other than specified may fail
to detect the accurate turning speed
resulting in a longer stopping dis-
tance.
Page 417 of 426

’05 4Runner_U (L/O 0504)
407
Instrument panel
4. AC115V INV 15 A: AC inverter
5. FR FOG 15 A: Front fog lights
6. OBD 7.5 A: On−board diagnosis sys-
tem
7. HEAD (LO RH) 10 A: Right −hand
headlight (low beam)
8. HEAD (LO LH) 10 A: Left−hand head-
light (low beam)
9. HEAD (HI RH) 10 A: Right −hand head-
light (high beam)
10. HEAD (HI LH) 10 A: Left −hand head-
light (high beam) 11. EFI NO.2 10 A:
Multiport fuel injection
system/se quential multiport fuel injec-
tion system
12. HEATER NO.2 7.5 A: Air conditioning
system
13. AIRSUS NO.2 10 A: Rear height con-
trol air suspension
14. SEAT HEATER 25 A: Seat heaters
15. DEFOG 30 A: Back window defogger,
multiport fuel injection system/sequen-
tial multiport fuel injection system
16. MIR HEATER 10 A: Outside rear view
mirror heater
17. DOME 10 A: Interior light, personal
lights, wireless remote control system,
door courtesy lights, rear seat audio
system, g auge and meter, vanity lights,
instrument panel lights, running board
lights, multiplex communication system
18. RADIO NO.1 20 A: Audio system, nav-
igation system
19. ECU B 10 A: Anti−lock brake system,
traction control system (two −wheel
drive models), active traction control
system (four −wheel drive models), ve-
hicle stability control system, air condi-
tioning system, multiplex communica-
tion system, theft deterrent system 20. ALT S 7.5 A:
Charging system
21. HORN 10 A: Horns
22. A/F HEATER 15 A: A/F sensor
23. TRN HAZ 15 A: Turn signal lights,
emergency flashers
24. ETCS 10 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
25. EFI 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
26. DR/LCK 20 A: Power door lock system
27. TOWING 30 A: Towing converter
28. RADIO NO.2 20 A: Audio system
29. IGN 10 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, anti −lo
ck brake system, trac-
tion control system (two −wheel drive
models), active traction control system
(four −wheel drive models), vehicle sta-
bility control system, stop light, meter
and gauge, front passenger occupant
classification system
30. SRS 10 A: SRS airbag system
31. GAUGE 7.5 A: Meter and gauge
32. STA NO.2 7.5 A: Multiport fuel injec-
tion system/sequential multiport fuel in-
jection system
