1. Driving position memory switches
2. Headlight, turn signal and front fog
light switches
3. Wiper and washer switches
4. Power back window switch
5. Audio system/rear view monitor system and navigation system including audio
system (For the navigation system, see
the separate “Navigation System
Owner ’s Manual”.)
6. Front passenger ’s seat belt reminder light
7. Engine immobilizer/theft deterrent system indicator light
8. Front passenger occupant classification indicator light
9. Multi −information display
10. Emergency flasher switch
11. Air conditioning controls
12. Auxiliary box
13. Back window and outside rear view mirror defogger switch
14. Four −wheel drive control switch knob
(full −time four −wheel drive models) or
multi −mode control switch knob
(multi −mode four −wheel drive models)
Page 15 of 470
’06 4Runner_U (L/O 0508)
5
15. Ignition switch
16. Cruise control switch
17. Hood lock release lever
18. Fuel filler door opener
19. Roll sensing of curtain shield airbags off switch
20. “AUTO LSD” switch
21. Center differential lock switch
22. Power outlet main switch
23. Instrument panel light control dial
1. Volume control switches for audio system/hands −free system (For the
hands −free system, see the separate
“Navigation System Owner ’s Manual”.)
2. “ ” switch
3. “MODE” switch
4. Telephone switches (See the separate “Navigation System Owner ’s Manual”.)
5. Speech command switch (See the separate “Navigation System Owner ’s
Manual”.)
Steering switches
Page 209 of 470
’06 4Runner_U (L/O 0508)
199
OPERATION OF INSTRUMENTS AND
CONTROLS
Audio system
Reference 200
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Using your audio system 201
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Audio remote controls 229
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
AUX adapter 230
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Rear seat entertainment system 231
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video system operating hints 270
. . . . . . . . . . . . . . . . . . . . . . . . . . .
For vehicle equipped with Navigation system, please refer to the
separate “Navigation System Owner’s Manual”.
SECTION 1 8
Page 251 of 470
’06 4Runner_U (L/O 0508)
241
The rear DVD player can be operated
through the front audio system. The audio system controls in the instru-
ment panel allow the operation of the rear
seat entertainment system by rear seat
passengers to be disabled.
Turning on the rear system lock prevents
small children from using the remote con-
troller or operation panel of the DVD play-
er unit to operate the rear seat entertain-
ment system during driving.
Turn the audio system on. Push the
“AUDIO CONTROL” knob repeatedly until
“RSE” is displayed. Next, turn the “AUDIO
CONTROL” knob until “ON” is displayed,
and then push the “AUDIO CONTROL”
knob.
Push the “INFO” button to change the
screen to “Screen Setting”.
Push the “ON” switch on the “Screen
Setting” screen to turn on the “Rear
system lock”. Then push “OK”.
—Front audio system
operation
—Rear system lock
(with navigation system)
Page 312 of 470
’06 4Runner_U (L/O 0508)
302
CAUTION
When doing the circling calibration,
be sure to secure a wide space,
and watch out for people and ve-
hicles in the neighborhood. Do not
violate any local traffic rules while
performing circling calibration.
Do not adjust the display while the
vehicle is moving. Be sure to adjust
the display only when the vehicle is
stopped.
The rear view monitor system assists
the driver by displaying an image of
the view behind the vehicle while back-
ing up. The left and right displayed on
the screen are the same as those of the
inside rear view mirror.
To display the rear view image on the
screen, place the selector lever in the
“R” position when the ignition switch is
in the “ON” position.
If you move the selector lever out of the
“R” position, the screen returns to the
previous screen. Operating another func-
tion of the navigation system will display
another screen.
The rear view monitor system is a supple-
ment device intended to assist back up.
When backing up, be sure to check be-
hind and all around the vehicle visually.CAUTION
Never depend on the rear view
monitor system entirely when back-
ing up. Always make sure your in-
tended path is clear.
Use caution, just as you would
when backing up any vehicle.
Never back up while looking only at
the screen. The image on the
screen is different from actual con-
ditions. Depicted distances between
objects and flat surfaces will differ
from actual distance. If you back up
while looking only at the screen,
you may hit a vehicle, a person or
an object. When backing up, be
sure to check behind and all around
the vehicle visually and with mir-
rors before proceeding.
Rear view monitor system
Page 464 of 470
’06 4Runner_U (L/O 0508)
454
43. TAIL 10 A: Tail lights, license plate
lights, parking lights, instrument panel
light control, multiport fuel injection
system/s equential multiport fuel injec-
tion system, instrument panel lights,
meter and gauge, grove box light
44. ACC 7.5 A: Power outlets, outside rear
view mirrors, audio system, navigation
system, shift lock control system, in-
strument panel lights, rear seat enter-
tainment system
45. CIG 10 A: No circuit
Fuses (type B)
46. A/PUMP 50 A: Multiport fuel injection
system/s equential multiport fuel injec-
tion system
47. AIRSUS 50 A: Rear height control air
suspension
48. AM1 50 A: All components in “ACC”,
“CIG”, “IG1”, “ECU −IG”, “FR WIP −
WSH”, “RR −WSH”, “4WD”, and “STA”
fuses
49. TOWING BRK 30 A: Trailer brake con-
troller
50. J/B 50 A: All components in “PWR
OUTLET”, “D P/SEAT”, “P P/SEAT”,
“POWER”, “TAIL” and “SECU/HORN”
fuses
51. BATT CHG 30 A: Trailer sub battery52. TOWING 40 A:
Trailer lights (tail
lights)
53. ABS MTR 40 A: Anti−lock brake sys-
tem, traction control system (two −wheel
drive models), active traction control
system (four −wheel drive models), ve-
hicle stability control system
54. AM2 30 A: Starter system, “IGN”,
“GAUGE”, “STA NO.2” and “SRS” fuses
55. ABS SOL 30 A: Anti−lock brake sys-
tem, traction control system (two −wheel
drive models), active traction control
system (four −wheel drive models), ve-
hicle stability control system
56. POWER 30 A: Power windows, electric
moon roof
Fuses (type C)
57. ALT 140 A: All components in
“A/PUMP”, “AIRSUS”, “AM1”, “TOWING
BRK”, “J/B”, “BATT CHG”, “TOWING”,
“TAIL”, “STOP”, “AC 115V INV”, “FR
FOG”, “OBD”, “DEFOG” and “MIR
HEATER” fuses
58. HEATER 60 A: Air conditioning system
