length TOYOTA 4RUNNER 2007 N210 / 4.G Quick Reference Guide

11
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
10
FEATURES/OPERATIONS
Position
Cushion angle(driver side only)
Height crank (driver side only)
Seatback angle
Lumbar support(driver side only)
Driver seat: position, cushion angle and height
Passenger seat: position
Seatback angle
Lumbar support(driver side only)
Seat adjustments-Front
Manual seatPower seat
Seats-Head restraints
Front
Second row seat
Third row
Lock release button
Lock release button
Lock release button
Lock release button
With third seatWithout third seat
To change the angleHold the steering wheel,
pull the lock release lever, tilt to the desired
angle, and release the lever.
To change the column lengthPush the lock
release lever down, set the desired length, and
return the lever to its locked position.
Note: Do not attempt to adjust while the vehicle
is in
motion.
Tilt and telescopic (if equipped) steering wheel
Parking brake
Set: Depress
Release: Depress again
(2)
(1)
(2)
(1) (2)
(2)
(1)
(2)
(1) (1)
