window TOYOTA 4RUNNER 2007 N210 / 4.G Quick Reference Guide

1
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
INDEX
ItemPage no.
OVERVIEWEngine maintenance 7Fuel tank door release and cap 6Hood release 7
Indicator symbols 4-5Instrument cluster 4Instrument panel 2-3
Keyless entry26
FEATURES/OPERATIONSAir Conditioning/Heating17Audio18-19Auto lock functions1, 28Auto LSD(Limited Slip Differential)21Automatic Transmission8Bottle holders 23Clock13Cruise control16Cup holders 22
Door locks 20Four-wheel drive9Garage door opener (HomeLink®)321Light control-Instrument panel13Lights2&turn signals14Moonroof222Parking brake11Power outlets 23Rear seat entertainment system 20Seat adjustments-Front10Seat adjustments-Rear12Seat heaters16Seats-Head restraints11Tilt and telescopic steering wheel10Windows215Window-Rear hatch215
Windshield wiper & washer13
SAFETY AND EMERGENCY FEATURESDoors-Child safety locks 24Seat belts 24Seat belts-Shoulder belt anchor 24Spare tire & tools 25
Tire Pressure Wa r n i n g System 24
1Programmable by customer.Refer to the Owner’s
Manual for instructions and more information.
2Visit your Toyota dealer for information on
customizing this feature.
3HomeLink®is a registered trademark of Johnson Controls, Inc.

3
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Hood release
Fuel tank door opener
“RSCA OFF”(Roll Sensing of Curtain shield Airbags
“OFF”) switch
1
“AUTO LSD” switch1
Center differential lock switch1
115V AC Power outlet ON/OFF switch1
Instrument panel light control
Steering wheel audio controls1,2
Te l e p h o n e switches1,2
Navigation voice command button1,2
12V DC Power outlet/Cigarette lighter
115V AC Power outlet1
AUX adapter
A/V input adapter1
1
If equipped2For details, refer to the “Navigation System
Owner’s Manual.”
2
OVERVIEW
Driving position memory switches1
Headlight, turn signal and front fog light1control
Wiper and washer controls
Power back window switch
Audio system or navigation system
1,2
Front passenger seat belt reminder light
Engine immobilizer/Theft deterrent system
indicator
1
Front passenger occupant classification indicator
Multi-information display
Emergency flasher switch
Air Conditioning controls
Auxiliary boxes
Back window and outside rear view mirror defogger
1
switch
Four-wheel drive selector1(full-time 4WD models)
or two wheel/four-wheel drive selector1(part-time
4WD models)
Ignition switch
Cruise control
Instrument panel
Steering wheel switches (if equipped)
Rear console box

NOTE:Tighten until one click is heard. If the cap is
not tightened enough, Check Engine “ ” indicator
may illuminate.
7
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Windshield and back window washer fluid tank
Power steering fluid reservoir
Engine oil level dipstick
Engine coolant reservoir
Engine oil filler cap
Note: Regularly scheduled maintenance, including
oil changes, will help extend the life of
your vehicle and maintain performance.
Please refer to the
“Owner’s Warranty
Information Booklet,” “Scheduled
Maintenance Guide” or “Owner’s Manual
Supplement.”
Engine maintenance
6cylinder (1GR-FE) engine
8 cylinder (2UZ-FE) engine
6
OVERVIEW
Fuel tank door release and capHood release
Pull upTu r n
StorePull Pull up latch
and raise
hood
NOTE:After unlocking, if a door is not opened within
30 seconds, all doors will relock for safety.
Alarm operation
Keyless entry (if equipped)
Locking operationUnlocking operation
Back window operation
Beep sound can be switched “ON” or “OFF.” Refer to
the Owner’s Manualfor more details.
Push
Push Push ONCE: Driver door
TWICE: All doors
Push and hold

13
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
12
FEATURES/OPERATIONS
Windshield wiper & washer
Rear
Front
Second row seats
Third row seats
Interval wipe
Slow
Fast
Pull to wash and wipe Adjust interval
Seatback angle
Seatback angle
Seatback
angle Seatback angle
Wa s h and wipe
Wipe
Interval wipe
Wa s h and wipe
Seat adjustments-Rear
(vehicles with third row seats)
Seat adjustments-Rear
(vehicles without third row seats)
(1) Push
(2) Lower(3) Pull up
(5) Fold-down(4) Push down
NOTE: Rear wiper and washer operate only when rear
window is fully closed. If battery is disconnected, rear
washer will not function until rear window is reinitialized
by being fully opened and then closed.
Light control-Instrument panel
Brightness
control
+
-
Clock
H-Hour set
M-Minute set
:00-Round off
minutes

15
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
14
FEATURES/OPERATIONS
Operating from inside
Windows
Driver side
Automatic operation (driver side only) Push the
switch completely down or pull it completely up and
release to fully open or close. To stop window
midway, lightly push the switch in the opposite
direction.
Window lock switch Deactivates all passenger
windows. Driver’s window remains operable.
NOTE: If the battery is disconnected, the window
will need to be reinitialized. Refer to the
Owner’s
Manualfor more details.
Window-Rear hatch
Operating from outside
Up
Down
Window
lock switch
Window lock
switch
Tu r n left
and hold
Up
Down
Open
Open
Tu r n right
and hold
Close
Close
Lights & turn signals
Turn signals
Headlights
AUTO*
High beam flasher
*If equippedLow beam
Front fog lights (if equipped)
Headlights
-Daytime Running Light system (if equipped)
Automatically turns on the headlights at a reduced
intensity.
-Automatic light cut off system Will automatically
turn lights off after a delay of 30 seconds, or the
lock switch on remote may be pushed.
Front fog lights come on only when the headlights
are on low beam.
Parking lights
High beam
Right turn
Tu r n Lane change
Lane change
Left turn
NOTE: If the battery is disconnected, the rear hatch
window will need to be reinitialized. Refer to the
Owner’s Manualfor more details.

17
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
16
FEATURES/OPERATIONS
Air Conditioning/Heating
With “DUAL” button (if equipped)
Fan speed
Temperature
Automatic climate control ON/OFF
“DUAL” button
Indicator ON:Separate temperature settings
for driver and passenger.
Indicator OFF:Synchronize temperature
settings for driver and passenger.
Air flow vent
Fresh or recirculate cabin air
Air Conditioning ON/OFF
Rear defogger
Climate control OFF
Cruise control
1The set speed may also be cancelled by depressing
the brake pedal.
2The set speed may be resumed once vehicle speed
exceeds 25 mph.
Refer to the Owner’s Manualfor more details.
Turning system ON/OFF
Functions
System ON/OFF
Resume
2/Increase speed
Set/Decrease speed
Cancel1
Without “DUAL” button
In “ ” or “ ” mode, use fresh air(“ ”
indicator “OFF”) to reduce window fogging.
Seat heaters
Left front seatRight front seat
