142
4RUNNER (U)_(OM35A83U)
3-4. Adjusting the steering wheel and mirrors
Hold the steering wheel and
push the lever down.
Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
To sound the horn, press on or
close to the mark.
Steering wheel
The steering wheel can be adjusted to a comfortable position.
Adjustment procedure
1
2
Horn

1433-4. Adjusting the steering wheel and mirrors
3
Operation of each component
4RUNNER (U)_(OM35A83U)
CAUTION
■Caution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.
■ After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
accident, and resulting in death or serious injury. Also, the horn may not
sound if the steering wheel is not securely locked.

2294-5. Using the driving support systems
4
Driving
4RUNNER (U)_(OM35A83U)■
Sensor detection information
●The sensor’s detection areas are limited to the areas around the vehicle’s
front corner and rear bumpers.
● Certain vehicle conditions and the surrounding environment may affect the
ability of the sensor to correctly detect obstacles. Particular instances where
this may occur are listed below.
• There is dirt, snow or ice on the sensor. (Wiping the sensors will resolve
this problem.)
• The sensor is frozen. (Thawing the area will resolve this problem.)
In especially cold weather, if a sensor is frozen the screen may show an
abnormal display, or obstacles may not be detected.
• The sensor is covered in any way.
• The vehicle is leaning considerably to one side.
• On an extremely bumpy road, on an incline, on gravel, or on grass.
• The vicinity of the vehicle is noisy due to vehicle horns, motorcycleengines, air brakes of large vehicles, or other loud noises producing ultra-
sonic waves.
• There is another vehicle equipped with parking assist sensors in the
vicinity.
• The sensor is coated with a sheet of spray or heavy rain.
• The vehicle is equipped with a fender pole or wireless antenna.
• Towing eyelet is installed.
• The bumper or sensor receives a strong impact.
• The vehicle is approaching a tall or curved curb.
• In harsh sunlight or intense cold weather.
• The area directly under the bumpers is not detected.
• If obstacles draw too close to the sensor.
• A non-genuine Toyota suspension (lowered suspension etc.) is installed.
• People may not be detected if they are wearing certain types of clothing.
In addition to the examples above, there are instances in which, because of
their shape, signs and other objects may be judged by the sensor to be closer
than they are.
● The shape of the obstacle may prevent the sensor from detecting it. Pay
particular attention to the following obstacles:
• Wires, fences, ropes, etc.
• Cotton, snow and other materials that absorb sound waves
• Sharply-angled objects
• Low obstacles
• Tall obstacles with upper sections projecting outwards in the direction of
your vehicle

4467-2. Steps to take in an emergency
4RUNNER (U)_(OM35A83U)
One of the following may be the cause of the problem:
●There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle.
● The engine may be flooded.
Try to restart the engine again following correct starting procedures.
( P. 192, 195)
● There may be a malfunction in the engine immobilizer system.
( P. 70)
One of the following may be the cause of the problem:
● The battery may be discharged. ( P. 452)
● The battery terminal connections may be loose or corroded.
The engine starting system may be malfunctioning due to an electrical
problem such as an open circuit or a blown fuse. However, an interim
measure is available to start the engine.
(  P. 447)
If the engine will not start
If the engine will not start even though correct starting proce-
dures are being followed ( P. 192, 195), consider each of the fol-
lowing points:
The engine will not start even though the starter motor operates
normally.
The starter motor turns over slowly, the interior lights and head-
lights are dim, or the horn does not sound or sounds at a low
volume.
The starter motor does not turn over

4477-2. Steps to take in an emergency
7
When trouble arises
4RUNNER (U)_(OM35A83U)
One of the following may be the cause of the problem:
●One or both of the battery terminals may be disconnected.
● The battery may be discharged. ( P. 452)
● There may be a malfunction in the steering lock system (vehicles
with a smart key system).
Contact your Toyota dealer if the problem cannot be repaired, or if repair
procedures are unknown.
When the engine does not start, the following steps can be used as an
interim measure to start the engine if the engine switch is functioning
normally:
Set the parking brake.
Shift the shift lever to P.
Turn the engine switch to ACCESSORY mode.
Press and hold the engine switch for about 15 seconds while
depressing the brake pedal firmly.
Even if the engine can be started using the above steps, the system
may be malfunctioning. Have the v ehicle inspected by your Toyota
dealer.
The starter motor does not turn ov er, the interior lights and head-
lights do not turn on, or the horn does not sound.
Emergency start function (vehicles with a smart key system)
1
2
3
4

512What to do if... (Troubleshooting)
4RUNNER (U)_(OM35A83U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts?
( P. 421)
●
The brake system warning light is on
Is the parking brake released? ( P. 204)
●
The open door warning indicator is on
Are all the doors closed? ( P. 100, 117)
Depending on the situation, other types of warning buzzer may also
sound. ( P. 418,
426)

●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 72)
To stop the alarm, turn the engine switch to IGNITION ON mode
(vehicles with a smart key system) or start the engine.
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display.
●When a warning light turns on, refer to P. 418.
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 418, 426.
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message is dis-
played

519Alphabetical index
4RUNNER (U)_(OM35A83U)
Head restraints ........................ 139
Headlights ................................ 205Light switch ........................... 205
Replacing light bulbs ................... 393, 395, 405
Wattage ................................ 469
Heaters
Air conditioning system ....... ................. 280, 286
Seat heaters ......................... 293
Outside rear view
mirrors ....................... 282, 288
Hill-start assist control............ 261
Horn .......................................... 142
Hood ......................................... 356
Hooks
Cargo hooks ......................... 305
Cargo net hooks ................... 306
Grocery bag hooks ............... 308
Retaining hooks (floor mat)..... 26 I/M test ...................................... 352
Identification
Engine .................................. 461
Vehicle .................................. 461
Ignition switch (engine switch) .............. 192, 195
Illuminated entry system ........ 297
Immobilizer system ................... 70
Indicators ................................... 79
Initialization
Moon roof ............................. 157
Power back window .............. 153
Power windows..................... 149
Maintenance ......................... 348
Inside rear view mirror ............ 144
Instrument panel light control ...................................... 82
Interior lights ........................... 295
Intuitive parking assist ........... 226
Jack Vehicle-equipped jack .......... 433
Jack handle .............................. 437
Jam protection function
Moon roof ............................. 156
Power back window .............. 153
Power windows..................... 149
