TOYOTA 4RUNNER 2015 N280 / 5.G Owners Manual

501
9
For owners
4RUNNER (U)_(OM35B18U)
CAUTION
■Précautions avec le coussins gonflable SRS
● Si vous avez des difficultés à respirer après le déploiement des coussins
gonflables SRS, ouvrez une porte ou une vitre pour faire entrer de l’air
frais, ou bien descendez du véhicule si cela ne présente pas de danger.
Essuyez tout résidu dès que possible afin d’éviter d’éventuelles irritations
de la peau.
● Si les parties renfermant les coussins gonflables SRS, telles que la garni-
ture du volant et les garnitures de montants avant et arrière, sont abîmées
ou craquelées, faites-les remplacer par votre concessionnaire Toyota.
■ Modification et mise au rebut d es éléments du système de coussins
gonflables SRS
Consultez impérativement votre concessionnaire Toyota si vous avez
besoin d’intervenir sur votre véhicule ou de procéder à l’une des modifica-
tions suivantes. Les coussins gonflables SRS peuvent être défaillants ou se
déployer (se gonfler) accidentellement, provoquant la mort ou de graves
blessures.
● Installation, dépose, démontage et réparation des coussins gonflables
SRS
● Réparations, modifications, démontage ou remplacement du volant, du
tableau de bord, de la planche de bord, des sièges ou de leur garniture,
des montants avant, latéraux et arrière ou des rails latéraux de toit
● Réparations ou modifications des ailes avant, du pare-chocs avant ou des
flancs de l’habitacle
● Installation d’un protège-calandre (pare-buffle, pare-kangourou, etc.), de
chasse-neiges, de treuils ou d’une galerie de pavillon.
● Modifications du système de suspension du véhicule
● Installation d’appareils électroniques, tels qu’une radio émetteur/récepteur
ou un lecteur CD
● Aménagements du véhicule visant à permettre sa conduite par une per-
sonne atteinte d’un handicap physique

502
4RUNNER (U)_(OM35B18U)

503
Index
4RUNNER (U)_(OM35B18U)What to do if...
(Troubleshooting) .................... 504
Alphabetical index ..................... 510
For details of equipment rela ted to the audio/navigation
system, refer to the “NAVIGATION AND MULTIMEDIA
SYSTEM OWNER'S MANUAL”.

504
4RUNNER (U)_(OM35B18U)
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your keys or mechanical keys, new genuine mechanical keys
can be made by your Toyota dealer. (P. 93)
●If you lose your keys or electronic keys, the risk of vehicle theft increases
significantly. Contact your Toyota dealer immediately. ( P. 95)
●Is the key battery weak or depleted? (P. 377)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( P. 195)
●Vehicles with a smart key system:
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. ( P. 106)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked

505What to do if... (Troubleshooting)
4RUNNER (U)_(OM35B18U)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (P. 99)
The rear door cannot be opened

506What to do if... (Troubleshooting)
4RUNNER (U)_(OM35B18U)
●Is the shift lever in P? (P. 191)
●Is the steering wheel unlocked? ( P. 191)
●Is the battery discharged? (P. 447)
●Did you press the engine switch while firmly depressing the brake pedal?
(P. 194)
●Is the shift lever in P? ( P. 196)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 104)
●Is the steering wheel unlocked? ( P. 197)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. ( P. 446)
●Is the battery discharged? (P. 447)
●Vehicles without a smart key system:
Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in the “ON” position. ( P. 443)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode. ( P. 443)
If you think something is wrong
The engine does not start
(vehicles without a smart key system)
The engine does not start
(vehicles with a smart key system)
The shift lever cannot be shifted from P even if you
depress the brake pedal

507What to do if... (Troubleshooting)
4RUNNER (U)_(OM35B18U)
●Vehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is pulled from the engine
switch. (P. 192)
●Vehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( P. 197)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 145)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. ( P. 196)
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or cl ose by operating the power
window switches
The engine switch is tu rned off automatically
(vehicles with a smart key system)

508What to do if... (Troubleshooting)
4RUNNER (U)_(OM35B18U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts?
( P. 415)
●
The brake system warning light is on
Is the parking brake released? ( P. 203)
●
The open door warning indicator is on
Are all the doors closed? ( P. 96, 114)
Depending on the situation, other types of warning buzzer may also
sound. ( P. 412,
421)

●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 72)
To stop the alarm, turn the engine switch to IGNITION ON mode
(vehicles with a smart key system) or start the engine.
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display.
●When a warning light turns on, refer to P. 412.
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 412, 421.
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message is dis-
played

509What to do if... (Troubleshooting)
4RUNNER (U)_(OM35B18U)
●Stop the vehicle in a safe place and replace the flat tire with the spare
tire. (P. 428)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( P. 453)
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

510
4RUNNER (U)_(OM35B18U)
Alphabetical index
Alphabetical index
A/C .................................... 278, 284Air conditioning filter ............. 375
ABS (Anti-lock Brake System)...... 259
Function ................................ 259
Warning light ......................... 413
Active head restraints ............. 120
Active traction control ............ 239
Air conditioning filter .............. 375
Air conditioning
system ............................ 278, 284 Air conditioning filter ............. 375
Airbags ....................................... 35
Airbag operating conditions .... 42
Airbag precautions for your child ......................... 37
Airbag warning light .............. 413
Correct driving posture ........... 28
Curtain shield airbag operating conditions ............. 42
Curtain shield airbag precautions ........................... 39
Front passenger occupant classification syst em............. 46
General airbag precautions .... 37
Locations of airbags................ 35
Modification and disposal of airbags.............................. 41
Side airbag operating
conditions ............................. 42
Side airbag precautions .......... 37
Side and curtain shield airbags operating conditions ............. 42
Side and curtain shield airbags precautions .............. 37
SRS airbags............................ 35 Alarm .......................................... 72
Alarm ...................................... 72
Warning buzzer .................... 412
Anchor brackets ........................ 57
Antennas (smart key system) ............... 103
Anti-lock Brake System (ABS) ...................................... 259
Function ................................ 259
Warning light......................... 413
Armrest..................................... 318
Assist grip ................................ 319
Audio system
*
AUTO LSD system................... 241
Automatic air conditioning
system.................................... 284
Automatic light control
system.................................... 204
Automatic running boards ..... 111
Automatic transmission ......... 199 If the shift lever cannot be shifted from P .... 443
S mode ................................. 200
AUX port*
Auxiliary boxes ........................ 300
A
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
