5207-2. Steps to take in an emergency
4RUNNER (U)
Add engine coolant if neces-
sary. (P. 414)
Water can be used in an emer-
gency if engine coolant is unavail-
able.
Start the engine to check that the radiator cooling fan operate and
to check for coolant leaks from the radiator or hoses.
If the fan are not operating:
Stop the engine immediately and contact your Toyota dealer.
If the fan are operating:
Have the vehicle inspected at the neare st Toyota dealer.
5
WARNING
■When inspecting under the hood of your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
● If steam is seen coming from under the hood, do not open the ho od until
the steam has subsided. The engine compartment may be very hot.
● Keep hands and clothing (especially a tie, a scarf or a muffler) away from
the fans and belts.
6
7
●Do not loosen the radiator cap and the
coolant reservoir cap while the engine
and radiator are hot.
High temperature steam or coolant
could spray out.

5278-1. Specifications
8
Vehicle specifications
4RUNNER (U)
*: The engine oil capacity is a reference quantity to be used when changing
the engine oil. Warm up and turn off the engine, wait more than 5 minutes,
and check the oil level on the dipstick.
■
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat -
isfy the following grade and viscosity.
Oil grade: ILSAC GF-6A multigrade engine oil
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice
for good fuel economy and
good starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced
with SAE 0W-20 at the next oil
change.
Oil viscosity (0W-20 is expl ained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils wi th a lower value before the W allow
for easier starting of the engine in cold weather.
• The 20 in 0W-20 indicates the vi scosity characteristic of the oil
when the oil is at high temperature. An oil with a higher visco sity
(one with a higher value) may be better suited if the vehicle i s
operated at high speeds, or un der extreme load conditions.
Lubrication system
Oil capacity
(Drain and refill  reference
*)
With filter
Without filter6.6 qt. (6.2 L, 5.5 Imp. qt.)
6.0 qt. (5.7 L, 5.0 Imp. qt.)
Outside temperature

5298-1. Specifications
8
Vehicle specifications
4RUNNER (U)
*: Voltage checked 20 minutes after the engine and all the lights are turned
off.
*: Your Toyota vehicle is filled with “Toyota Genuine Transfer Ge ar oil LF” at
the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or
an equivalent of matching quality to satisfy the above specific ation. Please
contact your Toyota dealer for further details.
Electrical system
Battery
Open voltage* at
68 F (20 C):12.3 V or higher
If the voltage is lower than the standard
value, charge the battery.
Charging rates5 A max.
Transfer (4WD models)
Oil capacity
Part-time 4WD models
1.1 qt. (1.0 L, 0.9 Imp. qt.)
Full-time 4WD models
1.5 qt. (1.4 L, 1.2 Imp. qt.)
Oil type*Toyota Genuine Transfer gear oil LF or
equivalent
Recommended oil viscositySAE 75W

578
4RUNNER (U)
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your keys or mechanical keys, new genuine mechanical keys
can be made by your Toyota dealer. ( P. 103)
●If you lose your keys or electronic keys, the risk of vehicle t heft increases
significantly. Contact your Toyota dealer immediately. ( P. 105)
●Is the key battery weak or depleted? (P. 447)
●Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( P. 200)
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of t he radio
wave. ( P. 117)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. ( P. 109)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

580What to do if... (Troubleshooting)
4RUNNER (U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts?
(P. 480)
●The brake system warning light is on
Is the parking brake released? ( P. 2 1 1 )
●The open door warning indicator is on
Are all the doors closed? (P. 106, 124)
Depending on the situation, other types of warning buzzer may a lso sound.
( P. 477, 488)

●Did anyone inside the vehicle open a door during setting the al arm?
The sensor detects it and the alarm sounds. ( P. 79)
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine.
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display.
●When a warning light turns on, refer to P. 477.
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 477, 488.
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds w hen leaving the vehicle
A warning light turns on or a warning message is displayed

585Alphabetical index
4RUNNER (U)
Driving ...................................... 166Break-in tips .......................... 168
Correct driving posture ........... 30
Driving assist systems .......... 322
Off-road precautions ............. 335
Procedures ........................... 166
Winter drive tips .................... 331
Dynamic radar cruise
control .................................... 257
Eco Driving Indicator ................ 98
EDR (Event data recorder) ........ 10
Electronic key .......................... 102 Battery-saving function ......... 116
If the electronic key does not operate properly ................. 512
Replacing the battery ............ 447
Emergency, in case of
If the electronic key does not operate
properly .............................. 512
If the engine will not start ...... 509
If the vehicle battery is discharged .......................... 515
If the warning buzzer sounds ................................ 477
If the warning light turns on ....................................... 477
If a warning message is displayed......................... 488
If the vehicle is submerged
or water on the road is
rising ................................... 468
If you cannot operate
back door opener ............... 511 If you have a flat tire ............. 493
If you think something
is wrong .............................. 475
If your vehicle becomes stuck ................................... 522
If your vehicle has to be stopped in an emergency ... 467
If your vehicle needs
to be towed......................... 469
If your vehicle overheats....... 519
Emergency flashers ................ 466
Engine
ACCESSORY mode ............. 200
Compartment ........................ 413
Engine switch ....................... 199
Hood ..................................... 412
How to start the engine......... 199
Identification number ............ 525
If the engine will not start ...... 509
Ignition switch (engine switch) ................... 199
Overheating .......................... 519
Engine coolant......................... 417
Capacity................................ 528
Checking............................... 417
Preparing and checking before winter ...................... 331
Engine coolant temperature gauge ....................................... 88
Engine immobilizer system ...... 78
Engine oil ................................. 415
Capacity................................ 527
Checking............................... 415
Preparing and checking before winter ...................... 331
Engine switch .......................... 199
Event data recorder (EDR)........ 10
E

593Alphabetical index
4RUNNER (U)
Tachometer ................................ 88
Tail lights .................................. 212Light switch ........................... 212
Telephone switches
*
Theft deterrent system
Alarm ...................................... 79
Engine immobilizer system ..... 78
Tire inflation pressure ............. 440 Maintenance data ................. 532
Warning light ......................... 481
Tire information ....................... 537 Glossary................................ 543
Size ....................................... 539
Tire identification number ..... 538
Uniform Tire Quality Grading............................... 541
Tire pressure warning system .................................... 429 Function ................................ 429
Installing tire pressure warning
valves and transmitters ...... 430
Registering ID codes ............ 431
Warning light ......................... 481 Tires .......................................... 427
Chains .................................. 333
Checking............................... 427
If you have a flat tire ............. 493
Inflation pressure .................. 532
Information............................ 537
Replacing.............................. 493
Rotating tires ........................ 428
Size....................................... 532
Snow tires ............................. 334
Spare tire .............................. 493
Tire pressure warning
system .......... ...................... 429
Warning light......................... 481
Tools ......................................... 494
Top tether strap ......................... 68
Total load capacity .................. 181
Towing Dinghy towing ....................... 198
Emergency towing ................ 472
Trailer towing ........................ 182
Toyota Safety Sense P ............ 232 Automatic High Beam ........... 217
Dynamic radar cruise
control ................................ 257
LDA (Lane Departure Alert) ....... 249
PCS (Pre-Collision System) ....... 239
T
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
