70RESUMING THE PRESET SPEED
If the preset speed is cancelled by pulling
the control lever or by depressing the
brake pedal or clutch pedal, pushing the
lever up in the RES/ACCº direction will
restore
the speed set prior to cancellation.
However, once the vehicle speed falls be-
low about 40 km/h (25 mph), the preset
speed will not be resumed.
CRUISE CONTROL FAILURE WARNING
If the CRUISEº indicator light in the in-
strument cluster flashes when using the
cruise control, press the CRUISE ON-
OFFº button to turn the system off and
then press it again to turn it on.
If any of the following conditions then oc-
curs, there is some trouble in the cruise
control system.
 The indicator light does not come on.
 The indicator light flashes again.
 The indicator light goes out after it
comes on.
If this is the case, contact your Toyota
dealer and have your vehicle inspected.ProCarManuals.com

Part 1
71
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1-7
Car audio system
and Air conditioning
system
Car audio system
Reference
 Using your audio system:
some basics
 Using your audio system:
controls and features
 CD (Compact Disc) Auto
changer
 Anti-theft system
 Car audio system operating
hints
Air conditioning system
 Controls
 Air flow selector settings
 Operating tips
 Instrumental panel vents
Type 1-1: AM.FM ETR radio/cassette
player
Type 1-2: AM.FM ETR radio/cassette
player
Type 1-3: AM.FM ETR radio/cassette
player
Type 2: AM.FM ETR radio/cassette
player/compact disc player
Car audio systemÐ
ÐReference
ProCarManuals.com

72This section describes some of the basic
features on Toyota audio systems. Some
information may not pertain to your sys-
tem.
Your audio system works when the igni-
tion key is in the ACCº or ONº position.
TURNING THE SYSTEM ON AND OFF
Push PWR/VOLº to turn the audio sys-
tem on and off.
Push AM
.FMº, T
APEº, or CDº to turn on
that function without pushing PWR/
VOLº.
You can turn on the cassette player by in-
serting a cassette tape.
You can turn off the cassette player by
ejecting the cassette tape. If the audio
system was previously off, then the entire
audio system will be turned off when you
eject the cassette tape. If another function
was previously playing, it will come on
again.
SWITCHING BETWEEN FUNCTIONS
Push AM
.FMº, TAPEº or CDº if the sys-
tem is already on but you want to switch
from one function to another. TONE AND BALANCE
For details about your system's tone and
balance controls, see the description of
your own system.
Tone
How good an audio program sounds to
you is largely determined by the mix of the
treble, mid-range, and bass levels. In
fact, different kinds of music and vocal
programs
usually sound better with differ-
ent mixes of treble, mid-range, and bass.
Balance
A good balance of the left and right stereo
channels and of the front and rear sound
levels is also important.
Keep in mind that if you are listening to a
stereo recording or broadcast, changing
the right/left balance will increase the vol-
ume of one group of sounds while de-
creasing the volume of another. YOUR RADIO ANTENNA
To lower a power antenna, turn off the au-
dio system by pushing PWR/VOLº, or
turn the ignition key to LOCKº.
On some models, the power antenna au-
tomatically retracts when the radio mode
is switched off to turn on the cassette tape
player or compact disc player.
To prevent damage to the antenna,
make sure it is retracted before
driving your Toyota through anautomatic car wash.
NOTICE
YOUR CASSETTE PLAYER
When you insert a cassette, the exposed
tape should be to the right.
Do not oil any part of the player anddo not insert anything other than
cassette tapes into the slot, or thetape player may be damaged.
NOTICE
ÐUsing your audio system:
some basics
ProCarManuals.com

73
YOUR COMPACT DISC PLAYER
Your compact disc player has an automat-
ic changer which stores up to 12 discs. To
insert discs in the automatic changer, see
CD (Compact Disc) Auto changerº. The
compact disc player will play from track 1
through to the end of the disc. Then it will
play from track 1 again.
Never try to disassemble or oil any
part of the player unit. Do not insert
anything except a compact disc into
the slot.
NOTICE
The player is intended for use with 12 cm
(4.7 in.) discs only.
ProCarManuals.com

74Details of specific buttons, controls, and
features are described in
the alphabetical
listing that follows.
ÐUsing your audio system:
controls and features

Type 1-1
ProCarManuals.com

75
Details of specific buttons, controls and
features are described in
the alphabetical
listing that follows.


Type 1-2ProCarManuals.com

76Details of specific buttons, controls and
features are described in
the alphabetical
listing that follows.


Type 1-3ProCarManuals.com

77
1 2 3 4 5 6 (Preset buttons)
These buttons are used to preset and
tune in radio stations.
To preset a station to a button: Tune in the
desired station (see TUNE/SEEKº or
TUNEº). Push and hold down the button
until
you hear a beepÐthis will set the sta-
tion to the button. The button number will
appear on the display.
To tune in to a preset station: Push the
button for the station you want. The button
number and station frequency will appear
on the display.
Types 1-1 and 1-2ÐThese systems can
store one AM and one FM station for each
button. The preset station memory will be
canceled out if the power source is inter-
rupted (battery disconnected or fuse
blown).
Type 1-3ÐThis system can store one AM
and two FM stations for each button. (The
display will show AMº, FM1º, or FM2º
when you push AM
.FMº.) To cancel out
the preset station memory, push 1º, 2º,
and 3º at the same time and hold them in
until you hear a beep.
(Eject button)
Types 1-2 and 1-3
Push this button to eject a cassette.
After you turn the ignition to LOCKº, you
will be able to eject a cassette but you will
not be able to reinsert it.
AM
.FM
Push AM
.FMº to switch between the AM
and FM bands.
Types 1-1 and 1-2кAMº or FMº will ap-
pear on the display.
Type 1-3ÐAMº or FM1º, or FM2º will
appear on the display. These systems al-
low you to set twelve FM stations, two for
each button.
If the audio system is off, you can turn on
the radio by pushing AM
.FMº. Also, push
AM.FMº to switch from cassette opera-
tion to radio operation. APS (Automatic program selection)
Type 1-3 only
The automatic program selection (APS)
feature allows you to program your cas-
sette player to skip forward or backward
to locate the song you want to hear. You
can skip up to nine tracks at a time.
Push
APSº. APSº AND 1º will appear on
the display.
Next, push APSº until the number on the
display reaches the number of tracks you
want to skip. If you push APSº ten times,
the APS feature will be turned off.
 If you choose the number 1º, the play-
er will rewind to the beginning of the
current track.
 When counting the number of tracks
you want to rewind, remember to
count the current track as well. For ex-
ample, if you want to rewind to a song
that is two before the song you are lis-
tening to, push APSº until 3º appears
on the display.
ProCarManuals.com

78Finally,
push REWº or FFº to choose the
direction you want to skip. The player will
rewind or fast forward the selected num-
ber of tracks and play.
The APS number you select can be higher
than the number of tracks remaining on
the current cassette side. After the begin-
ning or end of the tape is reached, the
player will automatically reverse sides
and rewind or fast forward the additional
number of tracks.
There must be at least 3 seconds of blank
space between tracks in order for APS to
work correctly.
In addition, APS feature may not work well
with some spoken word, live, or classical
recordings.
BAL (Balance)
This knob lets you adjust the balance be-
tween the right and left speakers.
Type 1-1ÐPush BAL/FADEº so that it
pops out of its retracted position. Turn the
knob to adjust the balance. Push the knob
back into its retracted position.
Types 1-2 and 1-3ÐPull out PWR/VOL/
BALº. Turn the knob to adjust the balance.
Push the knob back into its normal posi-
tion. BASS
This knob lets you adjust the bass level.
Push BASS/TREBº so that it pops out of
its retracted position. Turn the
knob to ad-
just the bass. Push the knob back into its
retracted position.
Dolby
)NR*
Type 1-1 only
If you are listening to a tape that was re-
corded with Dolby
) Noise Reduction,
push the button marked with the
double-D symbol. The double-D symbol
will appear on the display. Push the button
again to turn off Dolby
)NR.
The Dolby NR mode reduces tape noise
by about 10 dB. For best sound reproduc-
tion, play your tapes with this button on or
off according to the mode used for record-
ing the tape.
*: Dolby noise reduction manufactured under license from Dolby Lab-
oratories Licensing Corporation. DOLBYº and the double-D symbol
are trademarks of Dolby Laboratories Licensing Corporation.
Dolby [ B.C NR*
Types 1-2 and 1-3
If you are listening to a tape that was re-
corded with Dolby
[ B or C Noise Reduc-
tion, push the button marked with the
double-D symbol until the appropriate
symbol appears on the display. To turn off
Dolby
[ NR, push the button until the sym-
bol disappears from the display.
The Dolby B NR mode reduces tape noise
by about 10 dB. The Dolby C NR mode re-
duces tape noise by another 10 dB, or
about 20 dB total. For best sound repro-
duction, select the same NR mode that
was used to record the tape.
*: Dolby noise reduction manufactured under license from Dolby Lab-
oratories Licensing Corporation. DOLBYº and the double-D symbol
are trademarks of Dolby Laboratories Licensing Corporation.
EJECT
Type 1-1 only
Push EJECTº to eject a cassette.
After you turn the ignition to LOCKº, you
will be able to eject a cassette but you will
not be able to reinsert it.
ProCarManuals.com

79
FADE
This knob lets you adjust the balance be-
tween the front and rear speakers.
Type 1-1ÐPush BAL/FADEº so that it
pops out of its retracted position. Pull out
the knob. Turn the knob to adjust the front/
rear balance. Push the knob back into its
retracted position.
Types 1-2 and 1-3ÐMove the FADEº
ring around PWR/VOLº to adjust the
front/rear balance.
MTL (Metal) display
Types 1-2 and 1-3
If a metal or chrome equivalent cassette
tape is put in the cassette player, the play-
er will automatically adapt to it and MTLº
will appear on the display.
PROG (Program)
Push PROGº to select the other side of
a cassette tape. The display indicates
which side is currently selected (
~º indi-
cates top side, !º indicates bottom side).
Auto-reverse featureÐAfter the cassette
player reaches the end of a tape side, it
automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding. PWR
.VOL (Power.Volume)
Type 1-1 only
Push PWR
.VOLº to turn the audio sys-
tem on and off. T urn the PWR/VOLº knob
to adjust the volume.
PWR/VOL (Power/Volume)
Types 1-2 and 1-3
Push PWR/VOLº to turn the audio sys-
tem on and off. T urn the PWR/VOLº knob
to adjust the volume.
Pull out and then turn PWR/VOLº to ad-
just the balance between the right and left
speakers. Move FADEº around PWR/
VOLº to adjust the front/rear balance.
REW/FF (Rewind/Fast forward)
Push the FFº side of the button to fast for-
ward a cassette tape. FFº will appear on
the display. Push the REWº side to re-
wind a tape. REWº will appear on the dis-
play.
To stop the tape while it is fast forwarding,
push FFº or TAPEº; to stop the tape
while it is rewinding, push REWº or
TAPEº. The tape will immediately begin
to play.
If a tape side rewinds completely, the cas-
sette player will stop and then play that
same side. If a tape fast forwards com-
pletely, the cassette player will play the
other side of the tape, using the auto-re-
verse feature. R
.M (Radio monitor)
Type 1-3 only
The radio monitor feature allows you to
listen to the radio while a cassette is being
rewound or fast forwarded.
Push R
.Mº. R.Mº will appear on the dis-
play. Any time you are rewinding or fast
forwarding a cassette tape, the radio will
play the station that was set most recent-
ly. (You can not change the radio station
unless you switch out of the cassette play-
er function.)
Push R
.Mº again to turn off the R.M fea-
ture.
RPT (Repeat)
Type 1-3 only
The repeat feature automatically replays
the current cassette.
Push RPTº while the track is playing.
RPTº will appear on the display. When
the track ends, it will automatically be re-
wound and replayed. This process will be
continued until you push the button again
to turn off the repeat feature.
There must be at least 3 seconds of blank
space between tracks in order for the re-
peat feature to work correctly.
ProCarManuals.com
