mirror TOYOTA AVALON 1996 Owners Manual

3
1. Instrument panel light control dial
2. Headlight and turn signal switch
3. Wiper and washer switches
4. Driving pattern selector button
5. Thermometer
6. Clock
7. Emergency flasher switch
8. Car audio
9. Miscellany box
10.Air conditioning controls
11. Ashtray and cigarette lighter
12.Rear window defogger switch
13.Ignition switch
14.Cruise control switch
15.Power rear view mirror control switch
16. Headlight cleaner switch
ProCarManuals.com

Part 1
21
OPERATION OF
INSTRUMENTS AND
AND CONTROLSÐ
Chapter 1-3
Seats, Seat belts, Steering
wheel and Mirrors

Seats

Front seats

Head restraints

Seat heaters

Seat belts

SRS airbags

Child restraint

Tilt steering wheel

Outside rear view mirrors

Anti-glare inside rear view
mirror

Vanity mirrors
While the vehicle is being driven, all ve-
hicle occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belts provided.
CAUTION

Do not drive with the occupants
not properly seated, such as sit-
ting on top of a folded-down seat-
back, or in the luggage compart-
ment. Persons not properly
seated and not properly re-
strained by seat belts can be se-
verely injured in the event of emer-
gency braking or a collision.

During driving, do not allow pas-
sengers to stand up or move
around between seats. Balance
can be unsteady and severe inju-
ries can occur in the event of
emergency braking or a collision.!
Adjust the driver's seat so that the foot
pedals, steering wheel and instrument
panel controls are within easy reach of the
driver.
CAUTION

Adjustments should not be made
while the vehicle is moving, as the
seat may unexpectedly move and
cause the driver to lose control of
the vehicle.

When adjusting the seat, be careful
not to hit the seat against a passen-
ger or luggage.

After adjusting the seat position,
try sliding it forward and backward
to make sure it is locked in posi-
tion.

After adjusting the seatback, exert
body pressure to make sure it is
locked in position.

Do not put objects under the seats
as they may interfere with the seat-
lock mechanism or unexpectedly
push up the seat position adjusting
lever; the seat may suddenly move,
causing the driver to lose control of
the vehicle.

While adjusting the seat, do not put
your hands under the seat or near
the moving parts. You may jam
your hands or fingers.!
Seats
Front seatsÐ
ÐSeat adjustment precautions
ProCarManuals.com

46
To change the steering wheel angle,
hold the steering wheel, pull up the
lock release lever, tilt the steering
wheel to the desired angle and release
the lever.
When the steering wheel is in a low posi-
tion, it will spring up as you release the
lock release lever.
CAUTION!

Do not adjust the steering wheel
while the vehicle is moving.

After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.
Adjust the mirror so you can see the
side of your vehicle in the mirror.
Be careful when judging the size or dis-
tance of any object seen in the outside
rear view mirror on the passenger's side.
It is a convex
mirror with a curved surface.
Any object seen in a convex mirror will
look smaller and farther away than when
seen in a flat mirror.
Type A
Type B
ÐPower rear view mirror
control
Outside rear view mirrorsÐ
Tilt steering wheel
ProCarManuals.com

47
To adjust a mirror, use the switches.
1. Master switchÐTo select the mirror to
be adjusted
Place the switch at Lº (left) or Rº (right).
2. Control switchÐTo move the mirror
Push the switch in the desired direction.
If the engine is not running, the key must
be in the ACCº position.
NOTICE
If ice should jam the mirror, do not operate the control or scrape the
mirror face. Use a spray de-icer tofree the mirror.
To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror.
Daylight drivingÐLever at position 1
The reflection in the mirror has greater
clarity at this position.
Night drivingÐLever at position 2
Remember that by reducing glare you
also lose some rear view clarity.To use the vanity mirrors, swing down
the sun visor and open the cover.
The vanity light comes on when you open
the cover.
Anti- glare inside rear view
mirror Vanity mirrors
ProCarManuals.com

Part 3
125
STARTING AND
DRIVING

Before starting the engine

How to start the engine

Tips for driving in various
conditions

Winter driving tips

Trailer towing

How to save fuel and make your
vehicle last longer, too
1. Check the area around the vehicle be-
fore entering it.
2. Adjust seat position, seatback angle,
head restraint height and steering wheel
angle.
3. Adjust inside and outside rear view
mirrors.
4. Lock all the doors.
5. Fasten seat belts. 1. Apply the parking brake firmly.
2. Turn off unnecessary lights and acces-
sories.
3. Put the selector lever in Pº. If you
need to restart the engine while the ve-
hicle is moving, put the selector lever in
Nº. A starter safety device will prevent
the starter from operating if the selector
lever is in any drive position.
4. Depress the brake pedal and hold it to
the floor until driving off.
Before starting the engine
How to start the engineÐ
(a) Before cranking
ProCarManuals.com

130BRAKES AND SAFETY CHAINS


Toyota recommends trailers with
brakes that conform to any appli-
cable federal and state/provincial
regulations.

A safety chain must always be used
between the towing vehicle and the
trailer. Leave sufficient slack in the
chain for turns. The chain should
cross under the trailer tongue to
prevent the tongue from dropping
to the ground in case it becomes
damaged or separated. For correct
safety chain procedures, follow the
hitch or trailer manufacturer's rec-
ommendations.
CAUTION

If the total trailer weight exceeds
453 kg (1000 lb.), trailer brakes are
required.

Never tap into your vehicle's hy-
draulic system as it would lower its
braking effectiveness.

Never tow a trailer without using a
safety chain securely attached to
both the trailer and the vehicle. If
damage occurs to the coupling
unit or hitch ball, there is danger of
the trailer wandering over into
another lane.!
TIRES

Ensure that your vehicle's tires are
properly inflated. See Chapter 7-2 for
instructions.

The trailer tires should be inflated to
the pressure recommended by the
trailer manufacturer in respect to the
total trailer weight.
TRAILER LIGHTS

Trailer lights must comply with federal,
state/provincial and local regulations.
See your local recreational vehicle
dealer or rental agency for the correct
type of wiring and relays for your trail-
er. Check for correct operation of the
turn signals and stop lights each time
you hitch up. Direct splicing may dam-
age your vehicle's electrical system
and cause a malfunction of your lights.
BREAK-IN SCHEDULE

Toyota recommends that you do not
tow a trailer with a new vehicle or a ve-
hicle with any new power train compo-
nent (engine, transmission, differen-
tial, wheel bearing, etc.) for the first
800 km (500 miles) of driving. MAINTENANCE


If you tow a trailer, your vehicle will re-
quire more frequent maintenance due
to the additional load. For this informa-
tion, please refer to the scheduled
maintenance information in the Own-
er 's Manual Supplement/Maintenance
Scheduleº.

Retighten all fixing bolts of the towing
ball and bracket after approximately
1000 km (600 miles) of trailer driving.
PRE-T OWING SAFETY CHECK

Check that your vehicle remains level
when a loaded or unloaded trailer is
hitched. Do not drive if the vehicle has
an abnormal nose-up or nose-down
condition, and check for improper
tongue load, overload, worn suspen-
sion or other possible causes.

Make sure the trailer cargo is securely
loaded so that it can not shift.

Check that your rear view mirrors con-
form to any applicable federal, state/
provincial or local regulation. If not,
install the rear view mirrors required
for towing purpose.
ProCarManuals.com

192Tire size:
P205/65R 15 92H
Tire pressure, kPa (kgf/cm
2 or bar, psi):
Front 220 (2.2, 32)
Rear 220 (2.2, 32)
Wheel size:
15 x 6JJ
Wheel nut torque, NV m (kgfVm, ftVlbf):
103 (10.5, 76)
Engine compartment (U.S.A.)
Fuses (type A)
1. 7.5 A: Spare fuse
2. EFI 15 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, air conditioning control system,
electrical idle-up system, electronically
controlled automatic transmission system
3. HORN 10 A: Horn
4. OBD. TRAC 7.5 A: On-board diagno-
sis system
5. OBD 7.5 A: On-board diagnosis
system
6. HAZ 10 A: Turn signal lights, emer-
gency flasherEngine compartment (Canada)
7. DOME 7.5 A: Interior light, personal
light, vanity mirror light, door courtesy
light, ignition switch light, trunk light, pow-
er door lock control, locking with wireless
remote control system, theft deterrent
system, automatic light control system,
daytime running light system, service re-
minder indicators and warning buzzer,
clock
8. HEAD (LH) 15 A: Left-hand headlight
9. HEAD (RH) 15 A: Right-hand head-
light
10. HEAD HI (LH) 15 A: Left-hand head-
light (high beam)
11. HEAD HI (RH) 15 A: Right-hand
headlight (high beam)
12. ALT-S 5 A: Charging system
Tires Fuses
ProCarManuals.com

194
Passenger 's side kick panel
32. PANEL 5 A: Gauge and meter, Audio
system, cigarette lighter, glovebox light,
clock, electronically controlled automatic
transmission system, air conditioning
control system, service reminder indica-
tors, turn signal lights, emergency flasher,
headlight cleaner, seat heater
33. DEF I/UP 5 A: No circuit
34. CIG/RADIO 15 A: Cigarette lighter,
interior lights, clock, SRS airbag system,
shift lock system, power antenna, elec-
tronically controlled automatic transmis-
sion system, air conditioning control sys-
tem, ignition system, theft deterrent
system, outside rear view mirror control
system, Audio system, service reminder
indicators 35. HEATER 10 A:
Air conditioning con-
trol system, rear window defogger, starter
system
36. STARTER 5 A: Starter system
37. A.C 10 A: Air conditioning control
system
Fuses (type B)
38. MAIN 40 A: HEAD (LH)º, HEAD HI
(LH)º, HEAD (RH)º and HEAD HI (RH)º
fuses
39. RDI 30 A: Electric cooling fan
40. CDS 30 A: Electric cooling fan
41. DOOR 30 A: Power door lock sys-
tem, power seat
42. RR DEF 40 A: Rear window defogger
43. POWER 30 A: Power window, elec-
tric moon roof
Fuses (type C)
44. ALT 120 A: Charging system
45. AM1 80 A: RR DEFº, DOORº,
POWERº, TAILº, PANELº, DEF I/UPº,
SEAT HEATERº, SRSº and STOPº
fuses
46. ABS 60 A: Anti-lock brake system
47. IG SW 40 A: CIG/RADIOº and
GAUGEº fuses
48. HTR 50 A: A.C.º fuse
