Page 212 of 233
’98 AVALON (USA/CANADA)−U
212
Battery recharging precautions
During recharging, the battery is pro-
ducing hydrogen gas.
Therefore, before recharging:
1. If recharging with the battery installed on the vehicle, be sure to disconnect
the ground cable.
2. Be sure the power switch on the re- charger is off when connecting the
charger cables to the battery and when
disconnecting them.
CAUTION
Always charge the battery in an un-
confined area. Do not charge the
battery in a garage or closed room
where there is not sufficient ventila-
tion.
Only do a slow charge (5A or less).
Charging at a quicker rate is dan-
gerous. The battery may explode,
causing personal injuries.
NOTICE
Never recharge the battery while the
engine is running. Also, be sure all
accessories are turned off.
Checking and replacing fuses
Ty p e A
Ty p e B
Ty p e C Good
Blown
Good Blown
Blown
Good
If the headlights or other electrical
components do not work, check the
fuses. If any of the fuses are blown,
they must be replaced.
See ”Fuse locations” in Chapter 7
−1 for
locations of the fuses.
Turn the ignition switch and inoperative
component off. Pull a suspected fuse
straight out and check it.
Determine which fuse may be causing the
problem. The lid of the fuse box shows
the name of the circuit for each fuse. See
Part 8 of this manual for the functions
controlled by each circuit.
ProCarManuals.com
Page 213 of 233
’98 AVALON (USA/CANADA)−U
213
Type A fuses can be pulled out by the
pull −out tool. The location of the pull −out
tool is shown in the illustration.
If you are not sure whether the fuse has
blown, try replacing the suspected fuse
with one that you know is good.
If the fuse has blown, push a new fuse
into the clip.
Only install a fuse with the amperage rat-
ing designated on the fuse box lid.
If you do not have a spare fuse, in an
emergency you can pull out the ”TEL”,
”RAD NO.1” or ”A.C” fuse, which may be
dispensable for normal driving, and use it
if its amperage rating is the same.
If you cannot use one of the same amper-
age, use one that is lower, but as close
as possible to the rating. If the amperage
is lower than that specified, the fuse
might blow out again but this does not
indicate anything wrong. Be sure to get
the correct fuse as soon as possible and
return the substitute to its original clip.
It is a good idea to purchase a set of
spare fuses and keep them in your ve-
hicle for emergencies. If the new fuse immediately blows out,
there is a problem with the electrical sys-
tem. Have your Toyota dealer correct it as
soon as possible.
CAUTION
Never use a fuse with a higher am-
perage rating, or any other object, in
place of a fuse. This may cause ex-
tensive damage and possibly a fire.
Adding washer fluid
If any washer does not work, the wash-
er tank may be empty. Add washer
fluid.
You may use plain water as washer fluid.
However, in cold areas where tempera-
tures range below freezing point, use
washer fluid containing antifreeze. This
product is available at your Toyota dealer
and most auto parts stores. Follow the
manufacturer ’s directions for how much to
mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle’s paint.
ProCarManuals.com
Page 229 of 233
’98 AVALON (USA/CANADA)−U
229
Instrument panel
30. GAUGE 7.5 A: Gauge and meter,
buck −up lights, interior lights, charging
system, electronically controlled auto-
matic transmission system, cruise con-
trol system, power door lock system,
service reminder indicators and warning
buzzer, automatic light control system,
daytime running light system
31. TAIL 15 A: Parking lights, license plate
lights, tail lights, front side marker
lights
Passenger’s side kick panel
32. STOP 15 A: Stop lights, cruise control
system, high m ounted stoplight, anti/
lock brake system, shift lock system,
multiport fuel injection system/sequen-
tial multiport fuel injection system
33. PANEL 5 A: Gauge and meter, car
audio system, cigarette lighter, glove-
box light, clock, electronically controlled
automatic transmission system, air
conditioning system, service reminder
indicators, turn signal lights, emergency
flasher, headlight cleaner, seat heater
34. MIRROR HEATER 10 A: Mirror heaters35. CIG/RADIO 15 A:
Cigarette lighter, in-
terior lights, clock, SRS airbag system,
seat belt pretensioners, shift lock sys-
tem, electronically controlled automatic
transmission system, air conditioning
system, ignition system, theft deterrent
system, outside rear view mirror control
system, car audio system, service re-
minder indicators
36. HEATER 10 A: Air conditioning system,
rear window defogger, starter system
37. STARTER 5 A: Starter system
38. A.C 10 A: Air conditioning system
Fuses (type B)
39. MAIN 40 A: ”HEAD (LH)”, ”HEAD HI
(LH)”, ”HEAD (RH)” and ”HEAD HI
(RH)” fuses
40. RDI 30 A: Electric cooling fans
41. CDS 30 A: Electric cooling fans
42. DOOR 30 A: Power door lock system,
power seat
43. RR DEF 40 A: Rear window defogger
44. POWER 30A: Power window, electric
moon roof
