Page 91 of 237
’99 AVALON (USA/CANADA)−U
91
(k) Take vehicle to
Toyota dealer.
If the indicator or Do this.
buzzer comes on...
(m) Remove key.
Key reminder
buzzer
(l) Add washer fluid.
(a) Brake System Warning Light
This light has the following functions:
Parking brake reminder
If this light is on, make sure the parking
brake is fully released. The light should
go off.
Low brake fluid level warning
If this light comes on and stays on while
you are driving, slow down and pull off the
road. Then stop the vehicle carefully. Re-
member that stopping distance and pedal
effort may be increased. There may be a
problem somewhere in the brake system.
Check the fluid level of the see −through res-
ervoir.
To make sure the parking brake has not
caused the warning light to come on, check
to see that the parking brake is fully re-
leased.
If the brake fluid level is low...
At a safe place, test your brakes by starting
and stopping.
If you judge that the brakes still work
adequately, drive cautiously to your
nearest dealer or shop for repairs.
If the brakes are not working, have the
vehicle towed in for repairs. (For tow-
ing information, see Part 4.)
CAUTION
It is dangerous to continue driving
normally when the brake fluid level is
low.
If the brake fluid level is correct...
Have the warning system checked by your
Toyota dealer.
(b) Seat Belt Reminder Light and Buzz-
er
Once the ignition key is turned to ”ON” or
”START”, the reminder light flashes and
buzzer sounds if the driver ’s seat belt is
not fastened. Unless the driver fastens the
belt, the light keep flashing and the buzz-
er sounds for about 4 to 8 seconds.
(c) Discharge Warning Light
This light warns that the battery is being
discharged.
If it comes on while you are driving, there
is a problem somewhere in the charging
system.
The engine ignition will continue to oper-
ate, however, until the battery is dis-
charged. Turn off the air conditioning,
blower, radio, etc., and drive directly to
the nearest Toyota dealer or repair shop.
ProCarManuals.com
Page 92 of 237
’99 AVALON (USA/CANADA)−U
92
NOTICE
Do not continue driving if the engine
drive belt is broken or loose.
(d) Low Oil Pressure Warning Light
This light warns that the engine oil pres-
sure is too low.
If it flickers or stays on while you are
driving, pull off the road to a safe place
and stop the engine immediately. Call a
Toyota dealer or qualified repair shop for
assistance.
The light may occasionally flicker when
the engine is idling or it may come on
briefly after a hard stop. There is no
cause for concern if it then goes out when
the engine is accelerated slightly.
The light may come on when the oil level
is extremely low. It is not designed to
indicate low oil level, and the oil level
must be checked using the level dipstick.
NOTICE
Do not drive the vehicle with the
warning light on—even for one block.
It may ruin the engine.
(e) Malfunction indicator lamp
This lamp comes on in the following
cases.
a. The fuel tank is completely empty. (See
”Fuel gauge” in Chapter 1 −5 for instruc-
tions.)
b. The fuel tank cap is not tightened se-
curely. (See ”Fuel tank cap” in Chapter
1 −2 for instructions.)
c. There is a problem somewhere in your
engine or automatic transmission electrical
system.
If it comes on while you are driving in
case c, have your vehicle checked/re-
paired by your Toyota dealer as soon as
possible.
(f) Low Fuel Level Warning Light
This light comes on when the fuel level
in the tank becomes nearly empty. Fill up
the tank as soon as possible.
On inclines or curves, due to the move-
ment of fuel in the tank, the low fuel level
warning light may come on earlier than
usual. (g) ”ABS” Warning Light
This light warns that there is a problem
somewhere in your anti
−lock brake sys-
tem.
If the light comes on while you are driv-
ing, have your vehicle checked by your
Toyota dealer as soon as possible.
The light will come on when the ignition
key is turned to the ”ON” position. After
a few seconds, the light will go off.
When the ”ABS” warning light is on (and
the brake system warning light is off), the
brake system operates conventionally but
the anti −lock brake system is not assisting
brake performance so that the wheels can
lock −up during sudden braking or braking
on slippery road surfaces.
(h) Open Door Warning Light
This light remains on until all the doors
are completely closed.
ProCarManuals.com
Page 93 of 237
’99 AVALON (USA/CANADA)−U
93
(i) Rear Light Failure Warning Light
If this light comes on when the headlight
switch is turned on (at the position 1 or
position 2), it indicates that one or more
of the tail lights are burned out.
If it comes on when the brake pedal is
depressed, one or more stop lights are
burned out.
Have defective bulbs replaced as soon as
possible.
(j) SRS Airbag Warning Light
This light will come on when the igni-
tion key is turned to the ”ACC” or
”ON” position. After about 6 seconds,
the light will go off. This means the
system of the airbag and front seat belt
pretensioners are operating properly.
The warning light system monitors the air-
bag sensor assembly, seat belt pretension-
er assembly, inflators, warning light, inter-
connecting wiring and power sources.
If either of the following conditions occurs,
this indicates a malfunction somewhere in
the parts monitored by the warning light
system. Contact your Toyota dealer as
soon as possible to service the vehicle.The light does not come on when the
ignition key is turned to the ”ACC” or
”ON” position or remains on.
The light comes on or flashes while
driving.
(k) ”TRAC OFF” Indicator/Warning light
This light comes on when the ignition key
is turned to ”ON”, and will go off after a
few seconds. This means that the system
is operating properly.
If one of the following conditions occurs,
this indicates a malfunction somewhere in
the parts monitored by the warning light
system. Contact your Toyota dealer as
soon as possible to service the vehicle.
The light remains on more than a few
seconds after the ignition switch is
turned on.
The light comes on while driving even
if the ”TRAC OFF” switch is not
pushed.
The light flashes. (l) Low Windshield Washer and Head-
light Cleaner Fluid Level Warning
Light (on some models)
The light warns that the windshield washer
and headlight cleaner fluid level is too
low. Add washer fluid at your earliest op-
portunity. (For instructions, see ”Adding
washer fluid” in Chapter 7 −3.)
(m) Key Reminder Buzzer
This buzzer reminds you to remove the key
when you open the driver’s door with the
ignition key in the ”ACC” or ”LOCK” position.
ProCarManuals.com
Page 94 of 237
’99 AVALON (USA/CANADA)−U
94
CHECKING SERVICE REMINDER INDICA-
TORS (except the low fuel level warning
light and, low windshield washer and
headlight cleaner fluid level warning
light)
1. Apply the parking brake.
2. Open one of the doors. The open door warning light should
come on.
3. Close the door. The open door warning light should go
off.
4. Turn the ignition key to ”ACC”. The SRS airbag warning light should
come on. It goes off after about 6 se-
conds.
5. Turn the ignition key to ”ON”, but do not start the engine.
All the service reminder indicators ex-
cept the open door warning light and
SRS airbag warning light should come
on. The ”ABS” warning light and ”TRAC
OFF” indicator/warning light go off after
a few seconds.
If any service reminder indicator or warn-
ing buzzer does not function as described
above, either the bulb is burned out or the
circuit is in need of repair. Have it
checked by your Toyota dealer as soon as
possible.
ProCarManuals.com
Page 95 of 237
’99 AVALON (USA/CANADA)−U
95
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLS—
Chapter 1 −6
Ignition switch,
Transmission and
Parking brake
Ignition switch with steering lock
Automatic transmission
P ar k ing br ak e
Cruise control”START”—Starter motor on. The key
will return to the ”ON” position when
released.
For starting tips, see Part 3.
”ON”—Engine on and all accessories
on.
This is the normal driving position.
”ACC”—Accessories such as the radio
operate, but the engine is off.
If you leave the key in the ”ACC” or
”LOCK” position and open the driver’s
door, a buzzer will remind you to remove
the key.
”LOCK”—Engine is off and the steering
wheel is locked. The key can be re-
moved only at this position. You must push in the key to turn the key
from ”ACC” to the ”LOCK” position. The
selector lever must be in the ”P” position
before pushing the key.
Vehicles with engine immobiliser system—
Once you remove the key, the engine im-
mobiliser system is automatically set. (See
”Engine immobiliser system” in Chapter
1
−2.)
When starting the engine, the key may
seem stuck at the ”LOCK” position. To
free it, first be sure the key is pushed all
the way in, and then rock the steering
wheel slightly while turning the key gently.
NOTICE
Do not leave the key in the ”ON”
position if the engine is not running.
The battery will discharge and the
ignition could be damaged.
Ignition switch with steering
lock
ProCarManuals.com
Page 96 of 237
’99 AVALON (USA/CANADA)−U
96
Lock release button
To prevent misshifting
Parking, engine starting
and key removal position
Reverse position
Neutral position Normal driving position
Position for engine
braking
Position for stronger
engine braking than that
in ”2” position
With the brake pedal depressed, shift
while holding the lock release button
in. (The ignition switch must be in
”ON” position.)
Shift while holding the lock
release button in
Shift normally Driving pattern selector button
For selecting a driving pattern suited to
existing driving conditions
”NORM” (Normal)
mode for general
driving conditions ”PWR”
(Power) mode
for powerful
acceleration”PWR” mode indicator
light on the instrument
panel shows the driving
pattern selector button
is in ”PWR” mode
Overdrive switch
For selecting either a three −speed or
four −speed transmission
ON position
(Shifting into
overdrive
possible)
OFF position
(Shifting into
overdrive not
possible) ”O/D OFF” indicator light
Shows the overdrive
switch is in OFF position
When the cruise control is being used, even if you downshift the transmission by turning off the overdrive switch, engine braki
ng will
not be applied because the cruise control is not cancelled. For ways to decrease the vehicle speed, see ”Cruise control” in thi s
chapter.
Automatic transmission
Floor shift type
ProCarManuals.com
Page 97 of 237
’99 AVALON (USA/CANADA)−U
97
Parking, engine starting
and key removal position
Reverse position
Neutral position
Normal driving position
Position for engine
braking
Position for stronger
engine braking than that
in ”2” position Driving pattern selector button
For selecting a driving pattern suited to
existing driving conditions
”NORM”
(Normal) mode
for general
driving conditions ”PWR”
(Power) mode
for powerful
acceleration”PWR” mode indicator
light on the instrument
panel shows the driving
pattern selector button
is in “PWR” mode
Overdrive switch
For selecting either a three −speed or
four −speed transmission
”ON” position
(Shifting into
overdrive
possible)
”OFF” position
(Shifting into
overdrive not
possible)
”O/D OFF” indicator light
Shows the overdrive switch
is in ”OFF” position
With the brake pedal depressed,
shift while pulling the selector
lever toward you (The ignition
0switch must be in ”ON” position.)
Shift while pulling the
selector lever toward you
Shift normally
When the cruise control is being used, even if you downshift the transmission by turning off the overdrive switch, engine braki ng will
not be applied because the cruise control is not cancelled. For ways to decrease the vehicle speed, see ”Cruise control” in thi s
chapter.
Column shift type
ProCarManuals.com
Page 98 of 237
’99 AVALON (USA/CANADA)−U
98
Your automatic transmission has a shift
lock system to minimize the possibility of
incorrect operation. This means you can
only shift out of ”P” position when the
brake pedal is depressed (with the ignition
switch in ”ON” position, and the lock re-
lease button on the floor shift type trans-
mission depressed or the selector lever on
the column shift type transmission pulled
toward you).
(a) Normal driving
1. Start the engine as instructed in ”How to start the engine” in Part 3. The
transmission must be in ”P” or ”N”.
2. With your foot holding down the brake pedal, shift the selector lever to ”D”.
In ”D” position, the automatic transmission
system will select the most suitable gear
for running conditions such as normal
cruising, hill climbing, hard towing, etc.
Always turn the overdrive switch on for
better fuel economy and quieter driving. If
the engine coolant temperature is low, the
transmission will not shift into the over-
drive gear even with the overdrive switch
on.CAUTION
Never put your foot on the accelera-
tor pedal while shifting.
3. Release the parking brake and brake pedal. Depress the accelerator pedal
slowly for smooth starting.
(b) Using engine braking
To use engine braking, you can downshift
the transmission as follows:
Turn off the overdrive switch. The ”O/D
OFF” indicator light will come on and
the transmission will downshift to the
third gear.
Shift into the ”2” position. The trans-
mission will downshift to the second
gear when the vehicle speed drops
down to or lower than 133 km/h (82
mph), and more powerful engine brak-
ing will be obtained.
Shift into the ”L” position. The trans-
mission will downshift to the first gear
When the vehicle speed drops down to
or lower than 59 km/h (36 mph), and
maximum engine braking will be ap-
plied.
Vehicles with cruise control—When the
cruise control is being used, even if you
downshift the transmission by turning off
the overdrive switch, engine braking is not
applied because the cruise control is not
cancelled. For ways to decrease the ve-
hicle speed, see ”Cruise control” in this
chapter.
CAUTION
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to spin or
skid.
ProCarManuals.com
Page 99 of 237
’99 AVALON (USA/CANADA)−U
99
(c) Using ”2” and ”L” positions
The ”2” and ”L” positions are used for
strong engine braking as described pre-
viously.
With the selector lever in ”2” or ”L”, you
can start the vehicle in motion as with the
lever in ”D”.
With the selector lever in ”2”, the vehicle
will start in the first gear and automatical-
ly shift to the second gear.
With the selector lever in ”L”, the trans-
mission is engaged in the first gear.
NOTICE
Be careful not to overrev the en-
gine. Watch the tachometer to keep
engine rpm from going into the red
zone. The approximate maximum al-
lowable speed for each position is
given below for your reference:
”2”.......... 126 km/h (77 mph)
”L”.......... 68 km/h (41 mph)
Do not continue hill climbing or
hard towing for a long time in the
”2” or ”L” position. This may cause
severe automatic transmission dam-
age from overheating. To prevent
such damage, ”D” position should
be used in hill climbing or hard
towing.
(d) Backing up
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with your foot, shift the selector lever to the
”R” position.
NOTICE
Never shift into reverse while the ve-
hicle is moving.
(e) Parking
1. Bring the vehicle to a complete stop.
2. With the brake pedal pressed down, fully depress the parking brake pedal
to apply the parking brake securely.
3. With the brake pedal pressed down, shift the selector lever to the ”P” posi-
tion.
CAUTION
While the vehicle is moving, never
attempt to move the selector lever
into ”P” position under any circum-
stances. Serious mechanical damage
and loss of vehicle control may re-
sult.
(f) Good driving practice
If the transmission is repeatedly up-
shifted and downshifted between third
gear and overdrive when climbing a
gentle slope, the overdrive switch
should be turned off. Be sure to turn
the switch on immediately afterward.
When towing a trailer, in order to main-
tain engine braking efficiency, do not
use overdrive.
ProCarManuals.com
Page 100 of 237
’99 AVALON (USA/CANADA)−U
100
CAUTION
Always keep your foot on the brake
pedal while stopped with the engine
running. This prevents the vehicle
from creeping.
NOTICE
Do not hold the vehicle on an up-
grade with the accelerator pedal. It
can cause the transmission to over-
heat. Always use the brake pedal or
parking brake.
(g) Rocking your vehicle if stuck
CAUTION
If your vehicle becomes stuck in
snow, mud, sand, etc., then you may
attempt to rock the vehicle free by
moving it forward and backward. Do
not attempt this procedure if people
or objects are anywhere near the ve-
hicle. During the rocking operation
the vehicle may suddenly move for-
ward or backward as it becomes un-
stuck, causing injury or damage to
nearby people or objects.
NOTICE
If you rock your vehicle, observe the
following precautions to prevent dam-
age to the transmission and other
parts.
Do not depress the accelerator ped-
al while shifting the selector lever
or before the transmission is com-
pletely shifted to forward or reverse
gear.
Do not race the engine and avoid
spinning the wheels.
If your vehicle remains stuck after
rocking the vehicle several times,
consider other ways such as tow-
ing.
(h) If you cannot shift the selector le-
ver out of ”P” position
If you cannot shift the selector lever from
the ”P” position even though the brake
pedal is depressed, use the shift lock
override button. For instructions, see ”If
you cannot shift automatic transmission
selector lever” in Part 4.
ProCarManuals.com
