TOYOTA AVALON 2000 Service Manual

'00 AVALON U (L/O 9908)
40
2. To remove the fuel tank cap, turnthe cap slowly counterclockwise,
then pause slightly before removing
it. After removing the cap, hang it
on the cap hanger.
It is not unusual to hear a slight swoosh
when the cap is opened. When insta lling,
turn the cap clockwise till you hear a
click.
If the cap is not tightened securely, the
malfunction indicator lamp comes on.
Make sure the cap is tightened securely.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.
CAUTION

Make sure the cap is tightened se-
curely to prevent fuel sp illage in
case of an accident.

Use only a genuine Toyota fuel tank
cap for replacement. It has a built-
in check valve to reduce fuel tank
vacuum.
Electric moon roof
Sliding operation
Tilting operation
ProCarManuals.com

'00 AVALON U (L/O9908)
41
To operate the moon roof, use the
switches beside the interior light.
The moon roof works when the ignition
switch is in the ONº position. However,
if all the front doors are closed, it works
for about 43 seconds even after the igni-
tion switch is turned off. It stops working
when either of the front doors is opened.
Sun shade operationÐ
The sun shade can be opened or closed
by hand.
Sliding operationÐ
To open: Push the switch on the SLIDE
OPENº side.
The roof will open and stop partway 10
mm (0.4 in.) from the fully opened posi-
tion. When you push SLIDE OPENº side
again, the moon roof will open fully. To
stop the roof partway, push the same side
or TILT UPº side while the roof is mov-
ing.
As driving with the moon roof opened fully
will cause wind throbs, we recommend
you to drive with the moon roof partway
10 mm (0.4 in.) from the fully opened
position.
The sun shade will be opened together
with the roof.To close: Push the switch on the TILT
UPº side.
The roof will fully close. To stop the roof
partway, push the switch on either the
SLIDE OPENº or TILT UPº side briefly.
Tilting operationÐ
To tilt up: Push the switch on the TILT
UPº side.
To lower: Push the switch on the SLIDE
OPENº side.
You may stop the moon roof at any de-
sired position. The roof will move while
the switch is being pushed and stop when
released.
Jam protection function (closing opera-
tion only):
During closing operation, the
moon roof stops and opens half way if
something gets caught between the moon
roof and frame.
If the moon roof receives a strong impact,
this function may work even if nothing is
caught.CAUTION
To avoid serious personal injury, you
must do the following.

While the vehicle is moving, always
keep the head, hands and other
parts of the body of all occupants
away from the roof opening. Other-
wise, you could be seriously injured
if the vehicle stops suddenly or if
the vehicle is involved in an acci-
dent.

Always make sure nobody places
his/her head, hands and other parts
of the body in the roof opening be-
fore you close the roof. If some-
one's neck, head or hands gets
caught in the closing roof, it could
result in a serious injury. When
anyone closes the roof, first make
sure it is safe to do so.

Never leave small children alone in
the vehicle, especially with the igni-
tion key still inserted. They could
use the moon roof switches and get
trapped in the roof opening. Unat-
tended children can become in-
volved in serious accidents.
ProCarManuals.com

'00 AVALON U (L/O 9908)
42

Never sit on top of the vehicle
around the roof opening.

Never try jamming any part of your
body to make the jam protection
function work intentionally.

The jam protection function may
not work if something gets caught
just before the moon roof is fully
closed.
ProCarManuals.com

'00 AVALON U (L/O9908)
43
ProCarManuals.com

'00 AVALON U (L/O 9908)
44
OPERATION OF INSTRUMENTS AND
CONTROLS
Seats, Seat belts, Steering wheel and Mirrors
