TOYOTA AVALON 2001 Service Workshop Manual
Manufacturer: TOYOTA, Model Year: 2001, Model line: AVALON, Model: TOYOTA AVALON 2001Pages: 1897, PDF Size: 26.61 MB
Page 51 of 1897
AC2G4-01
I12297
12
I12298
3 AC-42
- AIR CONDITIONINGCOMPRESSOR AND MAGNETIC CLUTCH
1964 Author: Date:
2001 AVALON (RM808U)
COMPRESSOR AND MAGNETIC
CLUTCH
ON-VEHICLE INSPECTION
1. INSPECT COMPRESSOR FOR METALLIC SOUND
Check there is abnormal metallic sound from the compressor
when the A/C switch is ON.
If abnormal metallic sound is heard, replace the compressor as-
sembly.
2. INSPECT REFRIGERANT PRESSURE
(See page AC-3)
3. INSPECT VISUALLY FOR LEAKAGE OF REFRIGER-
ANT
Using a gas leak detector, check for leakage of refrigerant.
If there is any leakage, replace the compressor assembly.
4. INSPECT COMPRESSOR LOCK SENSOR RESIS-
TANCE
(a) Disconnect the connector.
(b) Measure resistance between terminals 1 and 2.
Standard resistance: 65 - 125 W at 20 °C (68 °F)
If resistance is not as specified, replace the sensor.
5. CHECK FOR LEAKAGE OF GREASE FROM CLUTCH
BEARING
6. CHECK FOR SIGNS OF OIL ON PRESSURE PLATE OR
ROTOR
7. INSPECT MAGNETIC CLUTCH BEARING FOR NOISE
(a) Start engine.
(b) Check for abnormal noise from the compressor when the
A/C switch is OFF.
If abnormal noise is being emitted, replace the magnetic clutch.
8. INSPECT MAGNETIC CLUTCH OPERATION
(a) Disconnect the connector.
(b) Connect the positive (+) lead from the battery to terminal
4 and the negative (-) lead to the body ground.
(c) Check that the magnetic clutch energized.
If operation is not as specified, replace the magnetic clutch.
Page 52 of 1897
AC1N3-02
N04963
Dial Indicator
- AIR CONDITIONINGCOMPRESSOR AND MAGNETIC CLUTCH
AC-49
1971 Author: Date:
2001 AVALON (RM808U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See
page AC-46).
AFTER REASSEMBLY, CHECK MAGNETIC CLUTCH
CLEARANCE
(a) Set the dial indicator to the pressure plate of the magnetic
clutch.
(b) Connect the magnetic clutch lead wire to the positive (+)
terminal of the battery.
(c) Check the clearance between the pressure plate and ro-
tor when connecting the negative (-) terminal to the bat-
tery.
Standard clearance:
0.5 ± 0.15 mm (0.020 ± 0.0059 in.)
If the clearance is not within the standard, adjust the clearance
using shims to obtain the standard.
Shim thickness:
0.1 mm (0.004 in.)
0.3 mm (0.012 in.)
0.5 mm (0.020 in.)
Page 53 of 1897
AC1N1-02
I12935
P19978
N20259
AC-44
- AIR CONDITIONINGCOMPRESSOR AND MAGNETIC CLUTCH
1966 Author: Date:
2001 AVALON (RM808U)
REMOVAL
1. RUN ENGINE AT IDLE SPEED WITH A/C ON FOR
APPROX. 10 MINUTES
2. STOP ENGINE
3. DISCONNECT NEGATIVE (- ) TERMINAL CABLE
FROM BATTERY
4. DISCHARGE REFRIGERANT FROM REFRIGERATION
SYSTEM
5. REMOVE DRIVE BELT
(See page AC-18)
6. DISCONNECT DISCHARGE AND SUCTION HOSES
Remove the 2 nuts and disconnect the both hoses.
NOTICE:
Cap the open fittings immediately to keep moisture or dirt
out of the system.
7. REMOVE GENERATOR
(a) Disconnect the generator connector.
(b) Remove the nut, and disconnect the generator wire.
(c) Disconnect the wire harness from the clamp.
(d) Remove the pivot bolt, adjusting lock bolt and generator.
8. REMOVE COMPRESSOR
(a) Disconnect the connector.
(b) Disconnect the wire harness clamp.
(c) Remove the 2 bolts, nut and drive belt adjusting bar
bracket.
Page 54 of 1897
I12947
- AIR CONDITIONINGCOMPRESSOR AND MAGNETIC CLUTCH
AC-45
1967 Author: Date:
2001 AVALON (RM808U)
(d) Remove the 3 bolts and compressor.
Page 55 of 1897
I12944
No. 2 Cooling
Fan Relay
AC20V-02
I12945
No. 3 Cooling
Fan Relay
N23635
35
4 1 2
I05027
5
12
3
1 3
2 5
AC-70
- AIR CONDITIONINGCOOLING FAN RELAY
1992 Author: Date:
2001 AVALON (RM808U)
COOLING FAN RELAY
INSPECTION
1. REMOVE NO. 2 COOLING FAN RELAY FROM RELAY
BLOCK NO. 8
2. REMOVE NO. 3 COOLING FAN RELAY FROM RELAY
BLOCK NO. 8
3. INSPECT NO. 2 COOLING FAN RELAY
(Marking: A.C FAN NO. 2) CONTINUITY
ConditionTester connectionSpecified condition
Constant1 - 2
3 - 4Continuity
Apply B+ between
terminals 1 and 2.3 - 5Continuity
If continuity is not as specified, replace the relay.
4. INSPECT NO. 3 COOLING FAN RELAY
(Marking: A.C FAN NO. 3) CONTINUITY
ConditionTester connectionSpecified condition
Constant1 - 2Continuity
Apply B+ between
terminals 1 and 2.3 - 5Continuity
If continuity is not as specified, replace the relay.
Page 56 of 1897
AC28I-02
I12949I12950
I12965
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
Compressor oil ND-OIL 8 or equivalent
5.4 (55, 48 in.´lbf)
5.4 (55, 48 in.´lbf)
Discharge Hose
Liquid Tube O-ringRadiator Upper SupportCondenser
Radiator Upper Support
Condenser
Dryer
Filter
Cap
12.3 (125, 9)
O-ring
AC-52
- AIR CONDITIONINGCONDENSER
1974 Author: Date:
2001 AVALON (RM808U)
COMPONENTS
Page 57 of 1897
AC2G7-01
- AIR CONDITIONINGCONDENSER
AC-55
1977 Author: Date:
2001 AVALON (RM808U)
INSTALLATION
Installation is in the reverse order of removal (See page AC-53).
Page 58 of 1897
AC2G5-01
- AIR CONDITIONINGCONDENSER
AC-51
1973 Author: Date:
2001 AVALON (RM808U)
CONDENSER
ON-VEHICLE INSPECTION
1. INSPECT CONDENSER FINS FOR BLOCKAGE OR DAMAGE
If the fins are clogged, wash them with water and dry with compressed air.
NOTICE:
Be careful not to damage the fins.
If the fins are bent, straighten them with a screwdriver or pliers.
2. INSPECT CONDENSER AND FITTING FOR LEAKAGE
Using a gas leak detector, check for leakage.
If there is leakage, check the tightening torque at the joints.
Page 59 of 1897
AC2G6-01
I12299
I12300
- AIR CONDITIONINGCONDENSER
AC-53
1975 Author: Date:
2001 AVALON (RM808U)
REMOVAL
1. DISCHARGE REFRIGERANT FROM REFRIGERATION
SYSTEM
HINT:
At the time of installation, please refer to the following item.
Evacuate air from refrigeration system.
Charge system with refrigerant and inspect for leakage of refrig-
erant.
Specified amount: 600 ± 50 g (21.16 ± 1.76 oz.)
2. REMOVE RADIATOR AND CONDENSER FANS
(See page AC-46)
3. REMOVE 2 RADIATOR UPPER SUPPORTS
4. DISCONNECT DISCHARGE HOSE AND LIQUID TUBE
Remove the 2 bolts and disconnect the hose and tube.
Torque: 10 N´m (100 kgf´cm, 7 ft´lbf)
NOTICE:
Cap the open fittings immediately to keep moisture or dirt
out of the system.
HINT:
At the time of installation, please refer to the following item.
Lubricate 2 new O-rings with compressor oil and install them
to the hose.
5. REMOVE CONDENSER
(a) Remove the 2 condenser set bolts.
(b) Push the radiator toward the engine.
(c) Push the condenser toward the radiator and pull it up-
ward.
HINT:
At the time of installation, please refer to the following item.
If condenser is replaced, add compressor oil to the condenser.
Add 40 cc (1.4 fl.oz.)
Compressor oil: ND-OIL 8 or equivalent
Page 60 of 1897
AC28K-02
I10090
10 mm (0.39 in.)
Hexagon
Wrench
Modulator
I10092
I10093
2 Layered
Part
I10091
Protrusion
I10094
AC-54
- AIR CONDITIONINGCONDENSER
1976 Author: Date:
2001 AVALON (RM808U)
REPLACEMENT
REPLACE DRIER FROM MODULATOR
(a) Using a hexagon wrench (10 mm, 0.39 in.), remove the
cap from the modulator.
(b) Remove the filter from the modulator.
(c) Using pliers, remove the drier.
(d) Insert a new drier into the modulator.
NOTICE:
Do not remove the drier from a vinyl bag until insert-
ing it into the modulator.
Install the drier with its 2 layered part faced upward to
the modulator.
(e) Insert the filter into the modulator.
NOTICE:
Install the filter with its protrusion faced downward to the
modulator.
(f) Install the cap to the modulator.
(1) Apply compressor oil to the O-rings and screw part
of the cap.
Compressor oil: ND-OIL 8 or equivalent
(2) Using a hexagon wrench (10 mm, 0.39 in.), install
the caps.
Torque: 12.3 N´m (125 kgf´cm, 9 ft´lbf)
