DI02E-08
FI0534
F07887DLC3
TOYOTA hand-held tester
DI-160
- DIAGNOSTICSAUTOMATIC TRANSAXLE
316 Author: Date:
2001 AVALON (RM808U)
PRE-CHECK
1. DIAGNOSIS SYSTEM
(a) Description
When troubleshooting OBD II vehicles, the only dif-
ference from the usual troubleshooting procedure
is that you connect to the vehicle an OBD II scan
tool complying with SAE J1987 or TOYOTA hand-
held tester, and read off various data output from
the vehicle's ECM.
OBD II regulations require that the vehicle's on-
board computer lights up the Malfunction Indicator
Lamp (MIL) on the instrument panel when the com-
puter detects a malfunction in the computer itself or
in drive system components which affect vehicle
emissions. In addition to the MIL lighting up when
a malfunction is detected, the applicable DTCs pre-
scribed by SAE J2012 are recorded in the ECM
memory (See page DI-14).
If the malfunction only occurs in 3-trip, the MIL goes
off but the DTCs remain recorded in the ECM
memory.
To check the DTCs, connect an OBD II scan tool or
TOYOTA hand-held tester to DLC3 on the vehicle.
The OBD II scan tool or TOYOTA hand-held tester
also enables you to erase the DTCs and check
freeze frame data and various forms of engine data
(For instruction book).
DTCs include SAE controlled codes and Manufac-
turer controlled codes.
SAE controlled codes must be set as prescribed by
the SAE, while Manufacturer controlled codes can
be set freely by the manufacturer within the pre-
scribed limits (See DTC chart on page ).
Page 772 of 1897
N09214
- DIAGNOSTICSAUTOMATIC TRANSAXLE
DI-161
317 Author: Date:
2001 AVALON (RM808U)
The diagnosis system operates in normal mode
during normal vehicle use, and also has a check
mode for technicians to simulate malfunction symp-
toms and perform troubleshooting. Most DTCs use
2-trip detection logic(*) to prevent erroneous detec-
tion. By switching the ECM to check mode when
troubleshooting, the technician can cause the MIL
to light up and for a malfunction that is only detected
once or momentarily (TOYOTA hand-held tester)
(See page DI-160).
*2-trip detection logic:
When a logic malfunction is first detected, the mal-
function is temporarily stored in the ECM memory.
If the same malfunction is detected again during the
2nd test drive, this 2nd detection causes the MIL to
light up.
(b) Inspect the DLC3.
The vehicle's ECM uses ISO 9141-2 for communication.
The terminal arrangement of DLC3 complies with SAE
J1962 and matches the ISO 9141-2 format.
Tester connectionConditionSpecified condition
7 (Bus Line) - 5 (Signal ground)During communicationPulse generation
4 (Chassis Ground) - BodyAlways1 W or less
5 (Signal Ground) - BodyAlways1 W or less
16 (B+) - BodyAlways9 - 14 V
HINT:
If your display shows ºUNABLE TO CONNECT TO VEHICLEº
when you have connected the cable of OBD II scan tool or TOY-
OTA hand-held tester to DLC3, turned the ignition switch ON
and operated the scan tool, there is a problem on the vehicle
side or tool side.
If communication is normal when the tool is connected to
another vehicle, inspect DLC3 on the original vehicle.
If communication is still not possible when the tool is con-
nected to another vehicle, the problem is probably in the
tool itself, so consult the Service Department listed in the
tool's instruction manual.
Page 773 of 1897
FI0534
F07887
TOYOTA hand-held tester
DLC3
DI-162
- DIAGNOSTICSAUTOMATIC TRANSAXLE
318 Author: Date:
2001 AVALON (RM808U)
2. INSPECT DIAGNOSIS (NORMAL MODE)
(a) Check the MIL.
(1) The MIL comes on when the ignition switch is turned
ON and the engine is not running.
HINT:
If the MIL does not light up, troubleshoot the combination meter
(See page BE-2).
(2) When the engine is started, the MIL should go off.
If the lamp remains on, the diagnosis system has
detected a malfunction or abnormality in the sys-
tem.
(b) Check the DTC.
NOTICE:
TOYOTA hand-held tester only:
When the diagnostic system is switched from normal mode
to check mode, it erases all DTCs and freeze frame data re-
corded in normal mode. So before switching modes, al-
ways check the DTCs and freeze frame data, and note them
down.
(1) Prepare an OBD II scan tool (complying with SAE
J1978) or TOYOTA hand-held tester.
(2) Connect the OBD II scan tool or TOYOTA hand-
held tester to DLC3 at the lower of the instrument
panel.
(3) Turn the ignition switch ON and turn the OBD II scan
tool or TOYOTA hand-held tester switch ON.
(4) Use the OBD II scan tool or TOYOTA hand-held
tester to check the DTCs and freeze frame data and
note them down (For operating instructions, see the
OBD II scan tool's instruction book).
(5) See page DI-172 to confirm the details of the DTCs.
NOTICE:
When simulating symptoms with an OBD II scan tool (ex-
cluding TOYOTA hand-held tester) to check the DTCs, use
normal mode. For codes on the DTCs chart subject to
º2-trip detection logicº, turn the ignition switch OFF after
the symptoms have been simulated the 1st time. Then re-
peat the simulation process again. When the program has
DTCs they are recorded in the ECM.
Page 774 of 1897
F07887
TOYOTA hand-held tester
DLC3
BR3904
0.13 sec. 0.13 sec.
ON
OFF
- DIAGNOSTICSAUTOMATIC TRANSAXLE
DI-163
319 Author: Date:
2001 AVALON (RM808U)
3. INSPECT DIAGNOSIS (CHECK MODE)
HINT:
TOYOTA hand- held tester only: Compared to the normal
mode, the check mode has high sensing ability to detect mal-
functions. Furthermore, the same diagnostic items which are
detected in Normal mode can also be detected in Check mode.
(a) Check the DTC.
(1) Check the initial conditions.
Battery positive voltage 11 V or more
Throttle valve fully closed
Transaxle in P position
Air conditioning switched OFF
(2) Turn the ignition switch OFF
(3) Prepare a TOYOTA hand-held tester
(4) Connect the TOYOTA hand-held tester to DLC3 at
the lower of the instrument panel.
(5) Turn the ignition switch ON and switch the TOYOTA
hand-held tester ON.
(6) Switch the TOYOTA hand-held tester from Normal
mode to Check mode (Check that the MIL flashes).
(7) Start the engine (MIL goes out after the engine
starts).
(8) Simulate the conditions of the malfunction de-
scribed by the customer.
NOTICE:
Leave the ignition switch ON until you have checked the
DTCs, etc..
(9) After simulating the malfunction conditions, use the
TOYOTA hand-held tester diagnosis selector to
check the DTCs and freeze frame data, etc.
HINT:
Take care not to turn the ignition switch OFF, as turning it off
switches the diagnosis system from Check mode to Normal
mode, so all DTCs, etc. are erased.
(10) After checking the DTC, inspect the applicable cir-
cuit.
Page 775 of 1897
DI-164
- DIAGNOSTICSAUTOMATIC TRANSAXLE
320 Author: Date:
2001 AVALON (RM808U)
(b) Clearance the DTC.
The following operation will erase the DTC and freeze
frame data. Operating an OBD II scan tool (complying
with SAE J1978) or TOYOTA hand-held tester to erase
the codes (See the OBD II scan tool's instruction book for
operating instructions.).
4. ROAD TEST
NOTICE:
Perform the test at normal operating ATF temperature 50 - 80 °C (122 - 176 °F).
(a) D position test
Shift into the D position and fully depress the accelerator pedal and check the following points:
(1) Check up-shift operation.
Check to see that 1 " 2, 2 " 3 and 3 " O/D up-shift takes place,and that the shift points conform
the automatic shift schedule (See page SS-24).
HINT:
O/D Gear Up-shift Prohibition Control (1. Coolant temp. is 60 °C (140 °F) or less. 2. If there is a 10
km/h (6 mph) difference between the set cruise control speed and vehicle speed.)
O/D Gear Lock-up Prohibition Control (1. Brake pedal is depressed. 2. Coolant temp. is 60 °C (140
°F) or less.)
(2) Check for shift shock and slip.
Check for shock and slip at the 1 " 2, 2 " 3 and 3 " O/D up-shifts.
(3) Check for abnormal noises and vibration.
Run at the D position lock-up or O/D gear and check for abnormal noises and vibration.
HINT:
The check for the cause of abnormal noises and vibration must be done very thoroughly as it could also be
due to loss of balance in the differential torque converter clutch, etc.
(4) Check kick-down operation.
While running in the D position, 2nd, 3rd and O/D gears, check to see that the possible kick-down
vehicle speed limits for 2 " 1, 3 " 2 and O/D " 3 kick-downs conform to those indicated in the
automatic shift schedule (See page SS-24).
(5) Check abnormal shock and slip at kick-down.
(6) Check the lock-up mechanism.
Drive in D position, O/D gear, at a steady speed (lock-up ON) of about 60 km/h (37 mph).
Lightly depress the accelerator pedal and check that the engine speed does not change
abruptly.
If there is a big jump in engine speed, there is no lock-up.
(b) 2 position test
Shift into the 2 position and fully depress the accelerator pedal and check the following points:
(1) Check up-shift operation.
Check to see that the 1 " 2 up-shift takes place and that the shift point conforms to the automatic
shift schedule (See page SS-24).
HINT:
There is no O/D up-shift and lock-up in the 2 position.
(2) Check engine braking.
While running in the 2 position and 2nd gear, release the accelerator pedal and check the engine
braking effect.
(3) Check for abnormal noises during acceleration and deceleration, and for shock at up-shift and
down-shift.
Page 776 of 1897
D07227D07228D07756
Column Shift:
Floor Shift:
- DIAGNOSTICSAUTOMATIC TRANSAXLE
DI-165
321 Author: Date:
2001 AVALON (RM808U)
(c) L position test
Shift into the 2 position and fully depress the accelerator pedal and check the following points:
(1) Check no up-shift.
While running in the L position, check that there is no up-shift to 2nd gear.
(2) Check engine braking.
While running in the L position, release the accelerator pedal and check the engine braking ef-
fect.
(3) Check for abnormal noises during acceleration and deceleration.
(d) R position test
Shift into the R position and fully depress the accelerator pedal and check for slipping.
CAUTION:
Before conducting this test ensure that the test area is free from people and obstruction.
(e) P position test
Stop the vehicle on a grade (more than 5°) and after shifting into the P position, release the parking
brake. Then, check to see that the parking lock pawl holds the vehicle in place.
5. BASIC INSPECTION
(a) Check the fluid level.
HINT:
Drive the vehicle so that the engine and transaxle are at
normal operating temperature.
Fluid temp.: 70 - 80 °C (158 - 176 °F)
Only use the COOL range on the dipstick as a rough refer-
ence when the fluid is replaced or the engine does not
run.
(1) Park the vehicle on a level surface and set the park-
ing brake.
(2) With the engine idling and the brake pedal de-
pressed, shift the shift lever into all positions from P
to L position and return to P position.
Page 777 of 1897
AT3417
OK if hot
Add if hot
AT4657
AT8562
AT3417
OK if hot
Add if hot DI-166
- DIAGNOSTICSAUTOMATIC TRANSAXLE
322 Author: Date:
2001 AVALON (RM808U)
(3) Pull out the dipstick and wipe it clean.
(4) Push it back fully into the pipe.
(5) Pull it out and check that the fluid level is in the HOT
range.
If the level is not within the range, add new fluid.
Fluid type: ATF D-II or DEXRON®III (DEXRON®II)
NOTICE:
Do not overfill.
After filling ATF, check the oil level securely then
drive a vehicle.
(b) Check the fluid condition.
If the fluid smells burnt or is black, replace it.
(c) Replace the ATF.
(1) Remove the drain plug and drain the fluid.
(2) Reinstall the drain plug securely.
(3) With the engine OFF add new fluid through the oil
filler pipe.
Fluid type: ATF D-II or DEXRON®III (DEXRON®II)
Capacity: 4.75 liters (5.0 US qts, 4.2 Imp. qts)
(4) Start the engine and shift the shift lever into all posi-
tions from P to L position and then shift into P posi-
tion.
(5) With the engine idling, check the fluid level. Add
fluid up to the COOL level on the dipstick.
(6) Check the fluid level at the normal operating tem-
perature, 70 - 80 °C (158 - 176 °F), and add as
necessary.
NOTICE:
Do not overfill.
Page 778 of 1897
AT4252
0 - 1 mm (0 - 0.04 in.)
Q00199
D02450P N
R
- DIAGNOSTICSAUTOMATIC TRANSAXLE
DI-167
323 Author: Date:
2001 AVALON (RM808U)
(d) Check the fluid leaks.
Check for leaks in the transaxle.
If there are leaks, it is necessary to repair or replace O-rings,
gasket, oil seals, plugs or other parts.
(e) Inspect and adjust the throttle cable.
(1) Check that the accelerator pedal is fully released.
(2) Check that the inner cable is not slack.
(3) Measure the distance between the outer cable end
and stopper on the cable.
Standard distance: 0 - 1 mm (0 - 0.04 in.)
If the distance is not the standard, adjust the cable by adjusting
nuts.
(f) Inspect and adjust the shift lever position.
When shifting the shift lever from the N position to other
positions, check that the lever can be shifted smoothly
and accurately to each position and that the position indi-
cator is aligned with the correct position.
If the indicator is not aligned with the correct position, carry out
the following adjustment procedures.
(1) Loosen the nut on the shift lever.
(2) Push the control shaft fully downward.
(3) Return the control shaft lever 2 notches to N posi-
tion.
(4) Set the shift lever to N position.
(5) While holding the shift lever lightly toward the R
position side, tighten the shift lever nut.
Torque: 13 N´m (130 kgf´cm, 9 ft´lbf)
(6) Start the engine and make sure that the vehicle
moves forward when shifting the lever from the N to
D position and reverses when shifting it to the R
position.
Page 779 of 1897
Q04700
Neutral Basic Line
BoltBolt
Groove DI-168
- DIAGNOSTICSAUTOMATIC TRANSAXLE
324 Author: Date:
2001 AVALON (RM808U)
(g) Inspect and adjust the park/neutral position.
Check that the engine can be started with the shift lever
only in the N or P position, but not in other positions.
If it is not as stated above, carry out the following adjustment
procedures.
(1) Loosen the park/neutral position switch bolt and set
the shift lever to the N position.
(2) Align the groove and neutral basic line.
(3) Hold in position and tighten the bolt.
Torque: 5.4 N´m (55 kgf´cm, 48 in´lbf)
For continuity inspection of the park/neutral position
switch, see page DI-199.
(h) Check the idle speed.
Idle speed: 700 ± 50 rpm
(In N position and air conditioner OFF)
6. MECHANICAL SYSTEM TESTS
(a) Measure the stall speed.
The object of this test is to check the overall performance of the transaxle and engine by measuring
the stall speeds in the D and R positions.
NOTICE:
Do the test at normal operating fluid temperature 50 - 80 °C (122 - 176 °F).
Do not continuously run this test longer than 5 seconds.
To ensure safety, conduct this test in a wide, clear level area which provides good traction.
The stall test should always be carried out in pairs. One technician should observe the condi-
tions of wheels or wheel stoppers outside the vehicle while the other is doing the test.
(1) Chock the 4 wheels.
(2) Connect an OBD II scan tool or TOYOTA hand-held tester to DLC3.
(3) Fully apply the parking brake.
(4) Keep your left foot pressing firmly on the brake pedal.
(5) Start the engine.
(6) Shift into the D position. Press all the way down on the accelerator pedal with your right foot.
Quickly read the stall speed at this time.
Stall speed: 2,325 - 2,775 rpm
(7) Do the same test in R position.
Stall speed: 2,325 - 2,775 rpm
Evaluation:
ProblemPossible cause
(a) Stall speed low in D and R positions
Engine output may be insufficient
Stator one-way clutch is operating properly
HINT: If more than 600 rpm below the specified value, the torque
converter clutch could be faulty.
(b) Stall speed high in D position
Line pressure too low
Forward clutch slipping
No.2 one-way clutch not operating properly
O/D clutch slipping
Page 780 of 1897
- DIAGNOSTICSAUTOMATIC TRANSAXLE
DI-169
325 Author: Date:
2001 AVALON (RM808U) (c) Stall speed high in R position
Line pressure too low
Direct clutch slipping
1st & reverse brake slipping
O/D clutch slipping
(d) Stall speed high in D and R positions
Line pressure too low
Improper fluid level
O/D one-way clutch not operating properly
(b) Measure the time lag.
When the shift lever is shifted while the engine is idling, there will be a certain time lapse or lag before
the shock can be felt. This is used for checking the conditions of the O/D direct clutch, forward clutch,
and 1st & reverse brake.
NOTICE:
Do the test at normal operating fluid temperature 50 - 80 °C (122 - 176 °F).
Be sure to allow 1 minute interval between tests.
Take 3 measurements and take the average value.
(1) Connect an OBD II scan tool or TOYOTA hand-held tester to DLC3.
(2) Fully apply the parking brake.
(3) Start the engine and check idle speed.
Idle speed: 700 ± 50 rpm (In N position and air conditioner OFF)
(4) Shift the shift lever from N to D position. Using a stop watch, measure the time from when the
lever is shifted until the shock is felt.
Time lag: N " D Less than 1.2 seconds
In the same manner, measure the time lag for N " R.
Time lag: N " R Less than 1.5 seconds
Evaluation (If N " D time or N " R time lag is longer than the specified):
ProblemPossible cause
N " D time lag is longer
Line pressure too low
Forward clutch worn
O/D one-way clutch not operating
N " R time lag is longer
Line pressure too low
Direct clutch worn
1st & reverse brake worn
O/D one-way clutch not operating properly
