Page 111 of 315
’03 AVALON U (L/O 0206)
1072003 AVALON (OM41401U)
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the “ON” position.
Lever position
Operation
Position 1Intermittent
operation
Position 2Low speed
operation
Position 3High speed
operation
Position 4Washer on
The “INT TIME” band lets you adjust the
wiping time interval when the wiper lever
is in the intermittent position (position 1).
Twist the band upward to increase the
time between sweeps, and downward to
decrease it.
To squirt washer fluid, pull the lever
toward you (position 4).
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
For instructions on adding washer fluid,
see “Adding washer fluid” in Section 7 3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the glass
or may damage wiper blades.
Automatic control adjuster
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the “ON” position.
Lever position
Operation
Position 1Automatic
operation
Position 2Low speed
operation
Position 3High speed
operation
Position 4Washer on
Windshield wipers and washer
(intermittent operation type)Windshield wipers and washer
(raindrop detection type)
Page 113 of 315
’03 AVALON U (L/O 0206)
1092003 AVALON (OM41401U)
To squirt washer fluid, pull the lever
toward you (position 4).
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
For instructions on adding washer fluid,
see “Adding washer fluid” in Section 7 3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch the glass
or may damage wiper blades.
The wiper blades retract under the hood
when the wipers are turned off.
In the following cases, the wipers should
be shifted from the retracted position
(position 2) to the rest position (position
1) above the hood level.
When cleaning the windshield
When inspecting or replacing the wip-
ers
When the retraction may be obstructed
by snow, etc., at the bottom of the
windshield
Other than the above cases, keep the
wipers in the retracted position.
SHIFTING TO THE REST POSITION
Hold the connection of the wiper arm
and wiper blade and pull it upward for
more than 10 cm (3.9 in.) along the
windshield glass with the force of
about 98 N (10 kgf, 22 lbf).
NOTICE
To prevent the wiper blades from be-
ing deformed, be sure to hold the
connection of the wiper arm and wip-
er blade securely.
Shifting the windshield wiper
position
Page 275 of 315
’03 AVALON U (L/O 0206)
2712003 AVALON (OM41401U)
Be extremely cautious when work-
ing on the battery. It contains poi-
sonous and corrosive sulfuric acid.
Warning: Battery posts, terminals
and related accessories contain lead
and lead compounds, chemicals
known to the State of California to
cause cancer and reproductive
harm. Wash hands after handling.
NOTICE
Remember that battery and ignition
cables carry high currents or volt-
ages. Be careful of accidentally
causing a short circuit.
Add only demineralized or distilled
water to fill the radiator. And if you
spill some of the coolant, be sure
to wash off with water to prevent it
from damaging the parts or paint.
Do not allow dirt or anything else
to fall through the spark plug holes.
Do not pry the outer electrode of a
spark plug against the center elec-
trode.
Use only spark plugs of the speci-
fied type. Using other types will
cause engine damage, loss of per-
formance or radio noise.
Do not reuse iridium tipped spark
plugs by cleaning or regapping.
Do not overfill automatic transmis-
sion fluid, or the transmission
could be damaged.
Do not drive with the air cleaner
filter removed, or excessive engine
wear could result. Also backfiring
could cause a fire in the engine
compartment.Be careful not to scratch the glass
surface with the wiper frame.
When closing the engine hood,
check to see that you have not for-
gotten any tools, rags, etc.
