navigation TOYOTA AVALON 2010 XX30 / 3.G Navigation Manual

MORE ADVANCED FUNCTIONS
109
2. Select the “Setup” switch.
3. Select the “Change speed”switch on the “Setup” screen.
4. You can set the speed as your desire
by operating the select and scroll lever
of the navigation controller. Select the
item by moving the lever vertically, and
move the lever horizontally to set the
speed.
If you select the
“Default” switch, the
default speed is set at each item.
5. After you finish setting the desired
speeds, select the
“OK” switch on the
right side of the screen.
6. The “Setup” screen will be dis-
played. Select the
“On” switch of “Es-
timated travel time”.
Selected switch is highlighted in green.
INFORMATION
 The displayed time to the destina-
tion is the approximate driving
time calculated based on the
speeds you selected and your ac-
tual position along the guidance
route.
 The time shown may vary greatly
depending on your progress along
the route (which may be affected
by road conditions such as traffic
jams, construction work, etc.).
 Up to 99 hours 59 minutes can be
displayed.

MORE ADVANCED FUNCTIONS
11 0
1. Push the “MENU” button on the
navigation controller.
2. Select the “Setup” switch.
3. Select the “Adjust” switch. The
“Adjust time zone” screen appears on
the display.
4. Select your desired time zone.
Selected switch is highlighted in green.
“Daylight saving time”: Select the
“On” switch on the screen and then se-
lect
or to set the day light saving
time.
5. Select the
“OK” switch on the
screen and the “Setup” screen will be
displayed.
Adjust time zone

MORE ADVANCED FUNCTIONS
111
1. Push the “MENU” button on the
navigation controller.
2. Select the “Setup” switch on the
screen.
3. Choose the “km” or “miles”switch of “Distance” to select your de-
sired units.
Selected switch is highlighted in green.
4. Select the
“OK” switch.
1. Push the “MENU” button on the
navigation controller.
2. Select the “Setup” switch on the
screen.
DistanceNotify seasonal restrict

MORE ADVANCED FUNCTIONS
11 2
3. Select the “On” switch of “Notify
seasonal restrict.” and select the
“OK” switch.
The restricted road icon and the message
may appear on the screen.
1. Push the “MENU” button on the
navigation controller.
2. Select the “Setup” switch on the
screen.
3. Select the “On” switch of “Voice
guide in all modes” and select the
“OK” switch.
Voice guide in all modes

MORE ADVANCED FUNCTIONS
11 3
1. Push the “MENU” button on the
navigation controller.
2. Select the “Setup” switch on the
screen.
3. Select the “On” switch of “Current
street name” and select the “OK”switch.
The current street name appears on the
map screen.
Current street name

MORE ADVANCED FUNCTIONS
11 4
This system has a function which in-
forms you of the time to replace certain
parts or components as well as other
information shown on the screen. (See
“Information items” on page 116.)
When the system begins operating af-
ter reaching either the information
item’s date or driving distance, the “In-
formation” screen will be displayed.
The “Information” screen will not be dis-
played or start up by selecting the
“Do
not display this message again”
switch.
1. Push the “INFO” button on the
navigation controller.
2. Select the “Maintenance” switch
to display the “Maintenance” screen.
Maintenance information

MORE ADVANCED FUNCTIONS
11 7
1. Push the “INFO” button on the
navigation controller.
2. Select the “Maintenance” switch
to display the “Maintenance” screen. (a) Register dealer
You can register your dealer’s name,
staff, location and phone number.
1. Select
the “Set dealer” switch on
the “Maintenance” screen.
2. Enter your dealer’s location ad-
dress in the same way as you input any
destination. (See pages 22 through 38.)
After you enter your dealer, the screen
changes and displays the map location of
the dealer. If it is OK, select the
“Enter”switch at the right of the screen.
The current screen changes to the screen
when you can edit the data of your dealer.
(See “(b) Edit dealer” on page 118.)
Dealer setting

MORE ADVANCED FUNCTIONS
11 9
EDITING THE LOCATION
1. Move the cursor to the desired
point, and if you want to register that
point, push the
“ENTER” button on
the navigation controller.
2. Select the “Enter” switch. EDITING THE PHONE NUMBER
Select numeral keys.
After you finish your entry, select the
“OK” switch at the bottom right of the
screen. The previous screen will be dis-
played.

MORE ADVANCED FUNCTIONS
121
This system has a function which in-
forms you the memo you entered.
When the system begins operating af-
ter reaching the memo’s date, the “In-
formation” screen will be displayed.
The “Information” screen will not be dis-
played again by selecting the
“Do not
display this message again”
switch.
1. Push the “INFO” button on the
navigation controller.
2. Select the “Calendar” switch to
display the “Calendar” screen.
Today’s date is highlighted. If today’s date
is not displayed on the screen, select
“Today” switch to display a calendar of
this month.
Calendar with memo

OTHER FUNCTIONS
128
The clock can be corrected manually or
by using signals from the GPS. Daylight
Saving Time setting or your desired
time setting is available.
1. Push the “INFO” button on the
navigation controller.
2. Select the “Adjust Clock”
switch.
“Auto Adjust”: Before you use the auto
adjust function, select the time zone (see
“Time Zone” described below). When you
select the
“ON” switch, the time is auto-
matically adjusted by the GPS clock.
When you select the
“OFF” switch, you
can adjust the clock manually with
“H”,
“M” and “:00” switches.
“H”: To set the hour with “Auto Adjust
OFF”, select this switch.
“M”: To set the minute with “Auto Adjust
OFF”, select this switch.
“:00”: To adjust the time to the nearest
hour, select this switch.
“Daylight Saving Time”: Daylight saving
time can be set or canceled.
“Time Zone”: You can select the time
zone. When you select this switch, the dis-
play will be change to the time zone selec-
tion screen. The initial setting is “Eastern
Standard Time”.
Clock adjustment
