tow TOYOTA AVALON 2010 XX30 / 3.G Quick Reference Guide

17
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Distance control mode will cruise at a set speed, decelerate to maintain
selected distance from a slower vehicle traveling in front of you, and
accelerate back up to the selected speed if the vehicle in front of you
changes lanes or speeds up.
(1)To select distance control modePush the ON-OFF button. The
“READY” and “CRUISE” indicator will come on.
(2)To set, cancel and resume a speedRefer to instructions forCruise
Controlon the previous page.
NOTE:Once vehicle speed is set, pushing lever up toward “+ RES” will
increase speed to the nearest 5 mph, and then in 5 mph increments.
Pushing lever down toward “- SET” will reduce speed in the same way.
(3)To change the vehicle-to-vehicle distance
Push the distance button to cycle through the settings, which will
change progressively from LONG to MIDDLE to SHORT.
Dynamic Laser Cruise Control (if equipped)
(1)To select conventional/fixed speed controlPush the ON-OFF button.
Push the lever forward and hold until the “NORM.” indicator appears.
(2)To set, cancel and resume a speedRefer to instructions forCruise
Controlon the previous page.
Fixed speed mode
Refer to theOwner’s Manualfor more details and complete safety
precautions before attempting to use “Dynamic Laser Cruise Control.”
Distance control mode
LONG
MIDDLE
SHORT
