Page 281 of 492
2815-3. Using the storage features
5
Interior features
AVALON (U)_(01999-07001)
Trunk features
Grocery bag hooks
Cargo net (if equipped)
Page 282 of 492
2825-3. Using the storage features
AVALON (U)_(01999-07001)
NOTICE
To prevent damage to the hooks, do not apply too much load to the hooks.
Page 283 of 492
283
5
Interior features
AVALON (U)_(01999-07001)
5-4. Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Open the cover to use.
The light turns on when the cover
is opened.
Other interior features
Sun visors
1
2
3
Vanity mirrors
NOTICE
To prevent battery discharge, do not leave the vanity lights on for extended
periods while the engine is off.
Page 284 of 492
2845-4. Other interior features
AVALON (U)_(01999-07001)
The clock can be adjusted by pressing the buttons.
■The clock is displayed when
The engine switch is in ACCESSORY or IGNITION ON mode.
■ When disconnecting and reco nnecting battery terminals
Type A
The time display will automatically be set to 12:00 AM.
Type B
The time display will automatically be set to 12:00.
■ Time display (Type B)
After pressing “H” or “M” to show the setting screen, press “H” and “M” at the
same time to change between the analog and digital displays.
Clock
Ty p e AType B
Adjusts the hours
Pressing and holding the button adjusts the hours forward quickly 1 hour at
a time.
Adjusts the minutes
Pressing and holding the button adjusts the minutes forward quickly by 1
minute at a time. If the button is pressed and held for 5 seconds or more,
the minutes move forward by 5 minutes at a time.
1
2
Page 285 of 492
2855-4. Other interior features
5
Interior features
AVALON (U)_(01999-07001)
The temperature display shows temperatures within the range of -40F
(-40 C) to 122 F (50 C).
■The outside temperature is displayed when
The engine switch is in IGNITION ON mode.
■ Display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
●When the vehicle is stopped, or moving at low speeds (less than 16 mph [25
km/h]).
● When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)
■ When “--- F” is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
Outside temperature display
Ty p e AType B
9ò
Page 286 of 492
2865-4. Other interior features
AVALON (U)_(01999-07001)
The power outlets can be used for 12 V accessories that run on less
than 10 A.
■Console box
■Instrument panel
Power outlets
Ty p e AType B
Page 287 of 492
2875-4. Other interior features
5
Interior features
AVALON (U)_(01999-07001)■
Rear armrest (if equipped)
■
The power outlets can be used when
The engine switch is in ACCESSORY or IGNITION ON mode.
NOTICE
●To avoid damaging the power outlets, close the power outlet lids when the
power outlets are not in use.
Foreign objects or liquids that enter the power outlets may cause a short
circuit.
● To prevent blown fuse, do not use an accessory that uses more than 12 V
10 A.
● To prevent battery discharge, do not use the power outlets longer than
necessary when the engine is off.
Page 288 of 492
2885-4. Other interior features
AVALON (U)_(01999-07001)
Fold down the armrest for use.
Armrest
NOTICE
To prevent damage to the armrest, do not apply too much load on the arm-
rest.
Page 289 of 492

2895-4. Other interior features
5
Interior features
AVALON (U)_(01999-07001)
The rear sunshade can be raised and lowered by pressing the switch
shown below.
Extends/retracts the rear sun-
shade
■The rear sunshade can be used when
The engine switch is in IGNITION ON mode.
■ Reverse operation feature
To ensure adequate rear visibility, the rear sunshade automatically lowers
when the shift lever is shifted to R.
However, the rear sunshade is raised again if either of the following occurs:
●The button is pressed again.
● The shift lever is shifted out of R, and the vehicle reaches a speed of 9 mph
(15 km/h).
If the engine is turned off when the rear sunshade has been lowered due to
the reverse operation feature, it will not be raised even when the engine is
turned on again and the vehicle reaches a speed of 9 mph (15 km/h). To raise
the sunshade again, press the button.
■ Customization
Settings (e.g. time elapsed before the reverse operation feature activates)
can be changed.
(Customizable features: P. 449)
Rear sunshade (if equipped)
WARNING
When the rear sunshade is being raised or lowered, do not place fingers \
or
other objects in the fastener section or in the opening. They may get caught,
causing injury.
Page 290 of 492

2905-4. Other interior features
AVALON (U)_(01999-07001)
Long objects can be loaded into the vehicle by utilizing the trunk
space and rear seat area.
Fold down the armrest.
Push down the handle and
open the armrest door.
The armrest door can be locked
and unlocked using the
mechanical key.Lock
Unlock
NOTICE
To prevent battery discharge, do not operate the rear sunshade when the
engine is not running.
To ensure normal operation of the sunshade, observe the following precau-
tions.
●Do not place excessive load on the motor or other components.
● Do not place objects where they may hinder opening and closing opera-
tions.
● Do not attach items to the rear sunshade.
● Keep the opening clean and clear of obstructions.
● Do not operate the rear sunshade continuously for long periods of time.
Trunk storage extension
1
2
1
2
WARNING
■When not in use
Ensure that the armrest door is closed.
In the event of sudden braking, items stored in the trunk may be thrown for-
ward into the cabin, resulting in injury.
