engine TOYOTA AVALON 2022 Owners Manual

5118-1. Specifications
8
Vehicle specifications
NOTICE
■Notice on fuel quality
● Do not use improper fuels. If improper fuels are used, the engi ne will be
damaged.
● Do not use leaded gasoline.
Leaded gasoline can cause damage to your vehicle’s three-way catalytic
converters causing the emission control system to malfunction.
● Do not use gasohol other than the type previously stated.
Other gasohol may cause fuel system damage or vehicle performance
problems.
● Using unleaded gasoline with an octane number or rating lower than the
level previously stated will cause persistent heavy knocking.
At worst, this will lead to engine damage.
■ Fuel-related poor driveability
If poor driveability (poor hot starting, vaporization, engine k nocking, etc.) is
encountered after using a different type of fuel, discontinue the use of that
type of fuel.
■ When refueling with gasohol
Take care not to spill gasohol. It can damage your vehicle’s paint.

5198-1. Specifications
8
Vehicle specifications
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure
Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressureThe maximum cold inflated pressure to which
a tire may be inflated, shown on the sidewall
of the tire
Recommended infla-
tion pressureCold tire inflation pressure recommended by a
manufacturer
Accessory weight
The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight
The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight
The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight
Normal occupant
weight150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
*
that follows
Occupant distributionDistribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below

5328-2. Customization
■Illumination (P. 352)
*: If equipped
FunctionDefault settingCustomized setting
Time elapsed before
lights turn off15 seconds
Off
OO7.5 seconds
30 seconds
Operation after the
engine switch turned offOnOff—O
Operation when the
doors are unlockedOnOff—O
Operation when you
approach the vehicle
with the electronic key
on your person
OnOff—O
Ambient lights*OnOff—O
12
WARNING
■During customization
As the engine needs to be running during customization, ensure that the
vehicle is parked in a place with adequate ventilation. In a closed area such
as a garage, exhaust gases including harmful carbon monoxide (CO) may
collect and enter the vehicle. This may lead to death or a serious health
hazard.
NOTICE
■During customization
To prevent battery discharge, ensure that the engine is running while cus-
tomizing features.

552What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your mechanical keys, new genuine mechanical keys can be
made by your Toyota dealer. ( P. 125)
●If you lose your electronic keys, the risk of vehicle theft inc reases signifi-
cantly. Contact your Toyota dealer immediately. ( P. 126)
●Is the key battery weak or depleted? (P. 435)
●Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( P. 187)
●Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of t he radio
wave. ( P. 125, 139)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. ( P. 130)
●The function to prevent the electronic key from being left insi de the trunk
will operate and you can open the trunk as usual. Take the key out from the
trunk. ( P. 134)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened
The trunk lid is closed with the electronic key left inside

553What to do if... (Troubleshooting)
●Did you press the engine switch while firmly depressing the brake pedal?
( P. 186)
●Is the shift lever in P? ( P. 188)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 137)
●Is the steering wheel unlocked? (P. 188)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. ( P. 485)
●Is the battery discharged? (P. 487)
●Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake p edal with the
engine switch in IGNITION ON mode. ( P. 195)
●It is locked automatically to prevent theft of the vehicle. ( P. 188)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( P. 162)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a peri od of
time. ( P. 188)
If you think something is wrong
The engine does not start
The shift lever cannot be shifted from P even if you depress
the brake pedal
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches
The engine switch is tur ned off automatically

554What to do if... (Troubleshooting)
●The seat belt reminder light is flashing
Are the driver and the passenger wearing the seat belts? (P. 459)
●The parking brake indicator is on
Is the parking brake released? (P. 198)
Depending on the situation, other types of warning buzzer may also sound.
( P. 455, 465)
●Did anyone inside the vehicle open a door during setting the al arm?
The sensor detects it and the alarm sounds. ( P. 80)
Do one of the following to stop the alarm: • Unlock the doors.
• Open the trunk using the entry function or wireless remote con trol.
• Turn the engine switch to ACCESSORY or IGNITION ON mode, or st art
the engine.
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. ( P. 465)
●When a warning light turns on or a warning message is displayed , refer to
P. 455, 465.
●Stop the vehicle in a safe place and replace the flat tire with the spare
tire. ( P. 470)
●Try the procedure for when the vehicle becomes stuck in mud, di rt, or
snow. ( P. 495)
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds w hen leaving the vehicle
A warning light turns on or a warning message is displayed
When a problem has occurred If you have a flat tire
The vehicle becomes stuck

557Alphabetical index
Child safety ................................ 55Airbag precautions .................. 39
Battery precautions ....... 412, 491
Child restraint system ............. 56
How your child should wear the seat belt .......................... 32
Installing child restraints ......... 60
Moon roof precautions .......... 169
Power window lock switch .... 162
Power window precautions ... 165
Rear door child-protectors .... 130
Removed electronic key battery precautions ............. 436
Seat belt extender precautions ........................... 35
Seat belt precautions .............. 34
Seat heater precautions........ 349
Trunk precautions ................. 135
Child-protectors....................... 130
Cleaning ........................... 386, 389
Exterior ................................. 386
Interior................................... 389
Seat belts .............................. 390
Wheels and wheel ornaments .......................... 387 Coat hooks ............................... 376
Condenser................................ 409
Connected Services
*
Console box ............................. 356
Consumption
screen .............................. 97, 118
Coolant
Capacity................................ 503
Checking............................... 408
Preparing and checking before winter ...................... 336
Cooling system........................ 408 Engine overheating............... 492
Cornering lights....................... 205
Cruise control Dynamic radar cruise control
with full-speed range .......... 263
Cup holders ............................. 358
Curtain shield airbags............... 37
Customizable features ............ 525
Customized mode ................... 324
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

559Alphabetical index
Eco drive mode ........................ 324
Eco Driving Indicator .............. 109
EDR (Event data recorder) .............. 11
Electric Power Steering (EPS)....................................... 329 Warning light ......................... 457
Electronic key .......................... 124 Battery-saving function ......... 139
If the electronic key does not operate properly ........... 484
Replacing the battery ............ 435
Emergency flashers ................ 444
Emergency, in case of
If a warning buzzer sounds ................................ 455
If a warning light turns on...... 455
If a warning message is displayed ............................ 465
If the battery is discharged.... 487
If the electronic key does not operate properly ................. 484
If the engine will not start ...... 482
If the vehicle is submerged or water on the road is
rising ................................... 446
If you have a flat tire ............. 470
If you lose your keys ..... 125, 126
If you think something is wrong.................................. 453
If your vehicle becomes
stuck ................................... 495
If your vehicle has to be stopped in an emergency ... 445
If your vehicle needs to be towed .................................. 448
If your vehicle overheats ....... 492 Engine
ACCESSORY mode ............. 187
Compartment ........................ 403
Engine switch ....................... 186
Hood ..................................... 401
How to start the engine......... 186
Identification number ............ 500
If your vehicle has to be stopped in an
emergency ......................... 445
Ignition switch (engine switch) ................... 186
Overheating .......................... 492
Engine coolant Capacity................................ 503
Checking............................... 408
Preparing and checking before winter ...................... 336
Engine coolant temperature
gauge ....................................... 90
Engine immobilizer system ...... 77
Engine oil Capacity................................ 501
Checking............................... 405
Preparing and checking before winter ...................... 336
Engine switch .......................... 186
Enhanced VSC ......................... 328
EPS (Electric Power Steering) ..... 329 Warning light......................... 457
Event data recorder (EDR) ........................................ 11
E

561Alphabetical index
Head restraints ........................ 153
Head-up display ....................... 111
Headlights ................................ 204Automatic High Beam ........... 208
Light switch ........................... 204
Replacing light bulbs............. 441
Windshield wiper linked
headlight illumination .......... 207
Heated steering wheel............. 349
Heaters Automatic air conditioning system ............ 342
Outside rear view mirrors...... 344
Seat heaters ......................... 349
High mounted stoplight Replacing .............................. 441
Hill-start assist control............ 328
Hood ......................................... 401
Hooks Coat hooks............................ 376
Grocery bag hooks ............... 361
Retaining hooks (floor mat)..... 26
Horn .......................................... 156
HUD (Head-up display)............ 111 I/M test ...................................... 398
ICS (Intelligent Clearance
Sonar)..................................... 303 Warning light......................... 458
Warning messages ............... 314
Identification Engine .................................. 500
Vehicle .................................. 499
Ignition switch (engine switch) ...................... 186
Illuminated entry system ........ 354
Immobilizer system ................... 77
Indicators ................................... 87
Initialization Intelligent Clearance Sonar.................................. 314
Items to initialize ................... 533
Tire pressure warning system .... .............. 416
Inside rear view mirror ............ 157
Instrument panel light control ...................................... 91
Intelligent Clearance Sonar (ICS) ............................ 303 Warning light......................... 458
Warning messages ............... 314
Interior lights ........................... 352 Switch ................................... 353
Intuitive parking assist ........... 295
HI

562Alphabetical index
JackPositioning the jack ............... 402
Vehicle-equipped jack........... 471
Jack handle .............................. 471
Jam protection function
Moon roof.............................. 167
Power window....................... 162
Keyless entry Smart key system ......... 127, 133
Wireless remote control......................... 127, 133
Keys .......................................... 124 Battery-saving function ......... 139
Electronic key ....................... 124
Engine switch........................ 186
If the electronic key does not operate properly ........... 484
If you lose your keys ..... 125, 126
Key number plate.................. 124
Keyless entry ........................ 124
Mechanical key ..................... 124
Replacing the battery ............ 435
Warning buzzer..................... 138
Wireless remote control ........ 124
Knee airbags .............................. 36 Lane Tracing Assist (LTA) ...... 243
Language
(multi-information display)... 107
LATCH anchors ......................... 61
Lever
Auxiliary catch lever.............. 401
Hood lock release lever ........ 401
Internal trunk release lever ... 134
Shift lever.............................. 191
Tilt and telescopic steering lock release lever ............... 155
Turn signal lever ................... 197
Wiper lever ........................... 212
License plate lights Light switch ........................... 204
Replacing light bulbs ............ 441
Light bulbs Replacing.............................. 441
Lights
Automatic High Beam ........... 208
Cornering lights .................... 205
Daytime running light system .......... ...................... 206
Door courtesy lights .............. 352
Headlight switch ................... 204
Illuminated entry system ....... 354
Interior lights ......................... 353
Interior lights list.................... 352
Personal lights ...................... 353
Replacing light bulbs ............ 441
Trunk light ............................. 134
Turn signal lever ................... 197
Vanity lights .......................... 362
Wattage ................................ 508
Welcome lighting .................. 207
Load capacity .......................... 183
Lock steering column ............. 188
LTA (Lane Tracing Assist) ...... 243
J
K
L
