Page 1 of 572

Pictorial indexSearch by illustration
1For safety
and securityMake sure to read through them
2Instrument
clusterHow to read the gauges and meters, the variety of
warning lights and indicators, etc.
3
Operation of
each
componentOpening and closing the doors and windows,
adjustment before driving, etc.
4DrivingOperations and advice which are necessary for
driving
5Interior featuresUsage of the interior features, etc.
6Maintenance
and careCaring for your vehicle and maintenance
procedures
7When trouble
arisesWhat to do in case of malfunction or emergency
8Vehicle
specificationsVehicle specifications, customizable features, etc.
9For ownersReporting safety defects for U.S. owners, and seat
belt and SRS airbag instructions for Canadian
owners
IndexSearch by symptom
Search alphabetically
Page 29 of 572

291-1. For safe use
1
For safety and security
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
● Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce
the effectiveness of the seat belt and head restraint.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the s eat
tracks and stop the seat from locking in place. This may lead t o an acci-
dent and the adjustment mechanism may also be damaged.
● Always observe the legal speed limit when driving on public roads.
● When driving over long distances, take regular breaks before you start to
feel tired.
Also, if you feel tired or sleepy while driving, do not force y ourself to con-
tinue driving and take a break immediately.
Page 144 of 572

1443-3. Adjusting the seats
Seat position adjustment switch
Seatback angle adjustment
switch
Seat cushion (front) angle
adjustment switch
Vertical height adjustment
switch
Lumbar support firmness
adjustment switch (if equipped)
Lumbar support height adjust-
ment switch (if equipped)
■ Power easy access system (vehicles with driving position memory )
The driver’s seat and steering wheel move in accordance with en gine switch
mode and the driver’s seat belt condition. ( P. 148)
Front seats
Adjustment procedure
1
2
3
4
5
6
Page 145 of 572

1453-3. Adjusting the seats
3
Operation of each component
WARNING
■When adjusting the seat position
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
● Make sure to leave enough space around the feet so they do not get stuck.
■ Seat adjustment
● Be careful that the seat does not hit passengers or luggage.
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may un expect-
edly move and cause the driver to lose control of the vehicle.
NOTICE
■ When adjusting a front seat
When adjusting a front seat, make sure that the head restraint does not
contact the headliner. Otherwise, the head restraint and headli ner may be
damaged.
Page 147 of 572

1473-3. Adjusting the seats
3
Operation of each component
WARNING
■When folding the seatbacks down
Observe the following precautions. Failure to do so may result in death or
serious injury.
● Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shi ft the shift
lever to P.
● Do not allow anyone to sit on a folded seatback or in the trunk while driv-
ing.
● Do not allow children to enter the trunk.
■ When returning the seat t o its original position
● Ensure that the seat belt does not get caught between or behind the seats.
● If the seat belt has been released from its guide, pass the sea t belt through
its guide. ( P. 32)
■ Seat adjustment
Be careful not to get hands or feet pinched between the rear co nsole box
and the rear seat when folding down the rear seatback.
■ After returning the seatback to the upright position
Observe the following precautions. Failure to do so may result in death or
serious injury.
● Make sure the seatback is securely locked by pressing it forwar d and rear-
ward on the top.
● Check that the seat belts are not twisted or caught in the seatback.
● Make sure that the seat belt is passed through its guide.
NOTICE
■When the right seatback is folded down
Make sure the luggage loaded in the enlarged trunk will not damage the
webbing of the rear center seat belt.
Page 150 of 572

1503-3. Adjusting the seats
■To stop the position recall operation part-way through
Perform any of the following operations:
●Press the “SET” button.
● Press button “1” or “2”.
● Operate any of the seat adjustment switches (only cancels seat position
recall).
● Operate the tilt and telescopic steering control switch (only cancels steering
wheel position recall).
■ Seat positions that can be memorized ( P. 144)
The adjusted positions other than the position adjusted by lumb ar support
switch can be recorded.
■ Operating the driving position m emory after turning the engine switch
off
Recorded seat positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again.
■ When the recorded seat pos ition cannot be recalled
The seat position may not be recalled in some situations when t he seat posi-
tion is recorded in a certain range. For details, contact your Toyota dealer.
■ In order to correctly use the dr iving position memory function
If a seat position is already in the furthest possible position and the seat is
operated in the same direction, the recorded position may be sl ightly different
when it is recalled.
Page 152 of 572

1523-3. Adjusting the seats
■Cancelation procedure
Carry only the key you want to cancel and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cann ot be
canceled properly.
Turn the engine switch to IGNITION ON mode.
While pressing the “SET” button, press and hold the door lock
switch (either lock or unlock) until the buzzer sounds twice.
If it button could not be canceled, the buzzer sounds continuously for
approximately 3 seconds.
■Recalling the driving position u sing the memory recall function
● Different driving positions can be registered for each electronic key. There-
fore, the driving position that is recalled may be different de pending on the
key being carried.
● If a door other than the driver’s door is unlocked with the smart key system,
the driving position cannot be recalled. In this case, press the driving posi-
tion button which has been set.
■ Customization
Some functions can be customized. ( P. 525)
WARNING
■ Seat adjustment caution
Take care during seat adjustment so that the seat does not stri ke the rear
passenger or squeeze your body against the steering wheel.
1
2
Page 156 of 572

1563-4. Adjusting the steering wheel and mirrors
To sound the horn, press on or
close to the mark.
■The steering wheel can be ad justed when (power type)
The engine switch is in ACCESSORY or IGNITION ON mode.
■ Automatic adjustment of the steering position (vehicles with dr iving
position memory)
A desired steering position can be entered to memory and recall ed automati-
cally by the driving position memory system. ( P. 148)
■ Power easy access system (vehicles with driving position memory )
The steering wheel and driver’s seat move in accordance with engine switch
mode and the driver’s seat belt condition. ( P. 525)
Horn
WARNING
■Caution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and caus e an acci-
dent, resulting in death or serious injury.
■ After adjusting the steering wheel (manual type)
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causi ng an
accident, and resulting in death or serious injury. Also, the horn may not
sound if the steering wheel is not securely locked.
Page 560 of 572

560Alphabetical index
Flat tire...................................... 470
Floor mats .................................. 26
FluidAutomatic transaxle .............. 504
Brake .................................... 506
Washer ................................. 413
Front interior light ................... 353
Front passenger occupant
classification system .............. 50
Front passenger’s seat belt
reminder light ........................ 459
Front personal lights ............... 353
Front seat heaters ................... 349
Front seats ............................... 144 Adjustment ............................ 144
Cleaning................................ 389
Correct driving posture ........... 28
Driving position memory ....... 148
Head restraints ..................... 153
Power easy access system ......... ....................... 148
Seat heaters ......................... 349
Seat ventilators ..................... 349
Front side marker lights Light switch ........................... 204
Replacing light bulbs............. 441 Front turn signal lights
Replacing light bulbs ............ 441
Turn signal lever ................... 197
Fuel Capacity................................ 500
Fuel gauge.............................. 90
Fuel pump shut off system ... 454
Information............................ 509
Refueling .............................. 216
Type.............................. 500, 509
Warning light......................... 458
Fuel consumption ................... 118
Fuel filler door ......................... 216 If the fuel filler door cannot be opened .............. 219
Refueling .............................. 216
Fuel pump shut off system..... 454
Fuses ........................................ 438
Garage door opener ................ 377
Gauges ....................................... 90
Glove box ................................. 356
Grocery bag hooks.................. 361
F
G
Page 566 of 572

566Alphabetical index
Seats ................................. 144, 146Adjustment .................... 144, 146
Adjustment precautions ................. 145, 147
Child seats/child restraint system installation . ............... 63
Cleaning................................ 389
Driving position memory ....... 148
Folding down the rear seatbacks ........................... 146
Front seat heaters................. 349
Head restraints ..................... 153
Power easy access system ......... ....................... 148
Properly sitting in the seat ...... 28
Rear seat heaters ................. 349
Seat ventilators ..................... 349
Secondary Collis ion Brake ..... 329
Sensor
Automatic headlight system ......... ....................... 206
Automatic High Beam
system ......... ....................... 208
Camera sensor ..................... 221
Inside rear view mirror .......... 158
Intuitive parking assist .......... 295
LTA (Lane Tracing Assist)................................. 243
Radar sensor ........................ 221 Service reminder
indicators ................................. 84
Shift lever ................................. 191
Automatic transmission ........ 191
If the shift lever cannot be shifted from P ................ 195
S mode ................................. 192
Shift lock system ..................... 194
Side airbags ............................... 37
Side marker lights ................... 204 Light switch ........................... 204
Replacing light bulbs ............ 441
Side mirrors ............................. 159
Adjusting and folding ............ 159
BSM (Blind Spot Monitor) ..... 279
Heaters ................................. 344
Side turn signal lights Replacing light bulbs ............ 441
Turn signal lever ................... 197
Smart key system .................... 137 Antenna location ................... 137
Entry functions .............. 127, 133
Starting the engine ............... 186
Snow tires ................................ 338
Spare tire .................................. 470 Inflation pressure .................. 506
Storage location.................... 471
