3806-3. Do-it-yourself maintenance
AVALON_HV_U (OM41457U)34 PANEL 10 A
Switch illumination, air conditioning sys-
tem, rear sunshade, seat heater, Blind
Spot Monitor, driving mode select switch,
steering wheel switch, ambient light, seat
ventilators, trunk opener switch, vehicle
stability control off switch, emergency
flashers, outside rear view mirrors, audio
system, navigation system
35 ECU-IG1 NO.1 10 A Electric cooling fans, steering sensor,
windshield wipers and washer, rear sun-
shade, seat heater, multiport fuel injec-
tion system/sequential multiport fuel
injection system, daytime running lights,
Blind Spot Monitor, charging system,
headlight (high beam), rear window
defogger, back up lights, outside rear
view mirror defoggers, fog lights, elec-
tronically controlled brake system, Vehi-
cle Proximity Notification System,
dynamic radar cruise control, pre-colli-
sion system
36 ECU-IG1 NO.2 10 A Shift lock control system, seat heaters,
seat ventilators, smart key system, tire
pressure warning system, wireless
remote control, multiplex communication
system, audio system, navigation sys-
tem, moon roof, auto anti-glare inside
rear view mirror, outside rear view mir-
rors, pre-collision system, dynamic radar
cruise control, air conditioning controls,
rain-sensing windshield wipers, starting
system
FuseAmpereCircuit
