dimensions TOYOTA AVALON HYBRID 2022 Owners Manual

5248-1.Specifications
*1: Unladen vehicles
*2: Vehicles with 235/45R18 tires and 235/40R19 tires
*3: Vehicles with 215/55R17 tires
Maintenance data (fuel, oil level, etc.)
Dimensions and weights
Overall length195.9 in. (4975 mm)
Overall width 72.8 in. (1850 mm)
Overall height*156.5 in. (1435 mm)
Wheelbase113.0 in. (2870 mm)
Tread
Front62.6 in. (1590 mm)*2
63.0 in. (1600 mm)*3
Rear63.2 in. (1605 mm)*2
63.6 in. (1615 mm)*3
Vehicle capacity weight
(occupants + luggage)
940 lb. (425 kg)
Seating capacity
Seating capacity
5 occupants (Front 2, Rear 3)

5388-1. Specifications
■Typical tire size information
The illustration indicates typical
tire size.
Tire use
(P = Passenger car [some-
times omitted],
T = Temporary use)
Section widt h (millimeters)
Aspect ratio
(tire height to section width)
Tire construction code ( R = Radial, D = Diagonal)
Wheel diameter (inches)
Load index (2 digits or 3 digits)
Speed symbol (alphabet with one letter)
■Tire dimensions
Section width
Tire height
Wheel diameter
Tire size
1
2
3
4
5
6
7
1
2
3

569Alphabetical index
Daytime running light system .................................... 223
Defogger Outside rear view mirrors...... 365
Rear window ......................... 365
Windshield ............................ 365
Dimensions .............................. 524
Dinghy towing .......................... 199
Display Dynamic radar cruise control
with full-speed range .......... 281
LTA (Lane Tracing Assist) .... 270
Multi-information display ....... 102
Warning messages ............... 488
Do-it-yourself maintenance .... 421
Door courtesy lights Location ................................ 374
Wattage ................................ 531
Door lock
Doors .................................... 142
Smart key system ................. 142
Wireless remote control ........ 142
Doors ........................................ 142 Automatic door locking and unlocking systems ....... 145
Door lock............................... 144
Outside rear view mirrors...... 174
Rear door child-protector ...... 145
Side doors............................. 142
Side windows ........................ 177 Drive-Start Control .................. 187
Sudden start restraint control ................................ 187
Driver’s seat belt reminder light ........................ 481
Driver’s seat position memory .................................. 163
Driving Break-in tips.......................... 188
Correct posture ....................... 26
Driving mode select switches ............................. 342
Hybrid vehicle driving tips ..... 351
Procedures ........................... 186
Winter drive tips .................... 354
Driving information ................. 106
Driving position memory ........ 163
Memory recall function ......... 166
Power easy access system .......... ...................... 163
DSC (Drive-Start Control) ....... 187 Sudden start restraint
control ................................ 187
Dynamic radar cruise control with full-speed range ............ 281
D
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
