Page 8 of 2234
NEW MODEL OUTLINE
\b
\b
Taillight
Stop
Light Turn Signal Light Back Up or
Rear Fog Light
\b
\b
Turn Signal Light
Stop
Light Taillight Back Up or
Rear Fog Light
\b
\b
Tail and Stop Light
Turn Signal Light Back Up or Rear Fog Light
MO-8
Rear View
The rear combination lens features an elegant, innovative shape.
The luggage compartment door and back door were given a greater sense of\
volume for a
high-quality feel.
4-Door Sedan
5-Door Liftback
5-Door Wagon
http://vnx.su
Page 31 of 2234
MO
NEW MODEL OUTLINEMO-29
: Standard OP: Option
EuropeGeneral
ENTRYMID
TECHNICALMID
ELEGANTGeneralCountries
Body Electrical
HeadlightProjectorHeadlightHID (High lntensity Discharge)ÐOPOPÐ
Headlight BeamManualÐ
Level Control SystemAutomaticÐOPOPÐ
Headlight Cleaner SystemOP*5OPOPÐ
FrontExcept for 1AZ-FEOPÐ
Fog LightFront1AZ-FEÐOPOPOP*4
RearÐ
Illuminated Entry System
Navigation SystemÐOPOPÐ
Multi information DisplayOPÐ
8-speaker OnlyOPOPOPOP
Audio SystemRadio / CD / Cassette / 8-speaker
Steering SwitchÐ
ManualÐÐ
Air ConditionerAutomaticÐÐ
WithoutOPÐÐOP
Conventional TypeExcept for 1CD-FTV
HeaterPTC Type1CD-FTVOPÐÐÐHeaterHot Gas Type1CD-FTVÐ
Combustion TypeLHD of 1CD-FTVÐOPOPÐ
WiperFrontAdjustment Interval INT FunctionÐÐWiper
SystemFrontRaindrop Sensing FunctionÐÐSystemRearIntermittent FunctionLiftback & WagonÐ
Power Window
Front Door One-Motion Auto Up-and-Down,
Jam Protection FunctionÐÐ
SystemAll-Door One-Motion Auto Up-and-Down,
Jam Protection FunctionOPOP
Door Lock ControlPower Door Look Control SystemDoor Lock Control
SystemWireless Door Look Remote Control SystemÐSystemDouble Locking SystemExcept for 1AZ-FE & LHDÐ
Engine ImmobiliserExcept for 1AZ-FE
System1AZ-FEÐOPOPÐ
Theft Deterrent SystemExcept for 1AZ-FE & 1CD-FTVÐ
5
Driver & Front Passenger & SideExcept for 1AZ-FEOPÐÐÐ
SRS*5 Airbag& Knee Airbags1AZ-FEÐ
SystemDriver & Front Passenger & SideExcept for 1AZ-FE
& Knee & Curtain Shield Airbags1AZ-FEÐOPOPÐ
Cruise Control System1AZ-FSE & 1CD-FTVÐOPOPÐ
Outside RearElectrical Retractable with HeaterÐÐ
View MirrorElectrical RetractableÐÐÐ
Inside RearAutomatic Glare-Resistant EC (Electrical) TypeÐÐ
View MirrorManual Glare-Resistant TypeÐÐ
Power Tilt Up-and-Sliding Moon RoofExcept for 1AZ-FSEOPOPOPÐ
(with Jam Protection Function)1AZ-FSEÐOP*6OP*6Ð
*4: LHD Models
*5: Supplemental Restraint System
*6: Except for Automatic Transaxle of Wagon Models
http://vnx.su
Page 63 of 2234
D25085
B02389
ON
01±28
±
INTRODUCTION HOW TO TROUBLESHOOT ECU CONTROLLED
SYSTEMS
AVENSIS REPAIR MANUAL (RM1018E)
Do not apply heat directly to the parts in the ECU.
3. WATER SPRINKLING METHOD: When the malfunc- tion seems to occur on a rainy day or in high±humid-
ity.
(a) Sprinkle water onto the vehicle and check if the malfunc- tion occurs.
NOTICE:
Never sprinkle water directly onto the engine
compartment, but indirectly change the temperature
and humidity by spraying a mist of water onto the ra-
diator front surface.
Never apply water directly onto the electronic compo-
nents.
HINT:
If a vehicle is subject to water leakage, the leaking water may
contaminate the ECU. When testing a vehicle with a water leak-
age problem, this factor must also be considered.
4. OTHERS: If the malfunction seems to occur when electrical load is excessive.
(a) Turn on all the electrical equipment including the heater blower, headlights, rear window defogger, etc., and check
if the malfunction occurs.
http://vnx.su
Page 958 of 2234
190NW±01
A81052
\bA82936
Type A
Type B BlueWhite
Red
Green Dark
Clear or
light yellow
B00543
±
STARTING & CHARGING CHARGING SYSTEM (1AZ±FE)
19±15
AVENSIS REPAIR MANUAL (RM1018E)
ON±VEHICLE INSPECTION
1. CHECK BATTERY ELECTROLYTE LEVEL
(a) Check the electrolyte quantity of each cell.
(1) If the electrolyte is under the low level, replace the battery (or add di\
stilled water if possible) andcheck the charging system.
2. CHECK BATTERY VOLTAGE
(a) If it has not been 20 minutes since you drove the vehicleor since the engine was stopped, turn the ignition switch
and the electrical system (headlight, blower motor, rear
defogger etc.) to the on position for 60 seconds. This will
remove the surface charge on the battery.
(b) Turn off the ignition switch and the electrical systems.
(c) Measure the battery voltage between the negative (±) and positive (+) terminals of the battery.
Standard voltage: 12.5 to 12.9 V at 20 C (68 F)
HINT:
If the voltage is less than specification, charge the battery.
(d) Check the indicator as shown in the illustration.
HINT:
Indicator colorConditionType AType BCondition
GreenBlueOK
DarkWhiteCharging necessary
Clear or light yellowRedReplace
3. CHECK BATTERY TERMINALS, FUSIBLE LINK AND FUSES
(a) Check that the battery terminals are not loosened or corroded.
(b) Check the fusible links, high±current fuses and regular fuses.
4. INSPECT DRIVE BELT
(a) Visually check the belt for excessive wear, frayed cordsetc.
HINT:
If any defect found, replace the drive belt.
Cracks on the rib side of a belt are considered acceptable.
If the belt has chunks missing from the ribs, it should be
replaced.
http://vnx.su
Page 961 of 2234
190NT±01
A81052
\bA82936
Type A
Type B BlueWhite
Red
Green Dark
Clear or
light yellow
B00543
19±18
±
STARTING & CHARGING CHARGING SYSTEM (1AZ±FSE)
AVENSIS REPAIR MANUAL (RM1018E)
ON±VEHICLE INSPECTION
1. CHECK BATTERY ELECTROLYTE LEVEL
(a) Check the electrolyte quantity of each cell. (1) If the electrolyte is under the low level, replace the battery (or add di\
stilled water if possible) andcheck the charging system.
2. CHECK BATTERY VOLTAGE
(a) If it has not been 20 minutes since you drove the vehicleor since the engine was stopped, turn the ignition switch
and the electrical system (headlight, blower motor, rear
defogger etc.) to the on position for 60 seconds. This will
remove the surface charge on the battery.
(b) Turn off the ignition switch and the electrical systems.
(c) Measure the battery voltage between the negative (±) and positive (+) terminals of the battery.
Standard voltage: 12.5 to 12.9 V at 20 C (68 F)
HINT:
If the voltage is less than specification, charge the battery.
(d) Check the indicator as shown in the illustration.
HINT:
Indicator colorConditionType AType BCondition
GreenBlueOK
DarkWhiteCharging necessary
Clear or light yellowRedReplace
3. CHECK BATTERY TERMINALS, FUSIBLE LINK AND FUSES
(a) Check that the battery terminals are not loosened or corroded.
(b) Check the fusible links, high±current fuses and regular fuses.
4. INSPECT DRIVE BELT
(a) Visually check the belt for excessive wear, frayed cordsetc.
HINT:
If any defect found, replace the drive belt.
Cracks on the rib side of a belt are considered acceptable.
If the belt has chunks missing from the ribs, it should be
replaced.
http://vnx.su
Page 964 of 2234
190NN±01
A81051
A81052
\bA82936
Type A
Type B BlueWhite
Red
Green Dark
Clear or
light yellow
19±26
±
STARTING & CHARGING CHARGING SYSTEM (1CD±FTV)
AVENSIS REPAIR MANUAL (RM1018E)
ON±VEHICLE INSPECTION
1. CHECK BATTERY ELECTROLYTE LEVEL
(a) Check the electrolyte quantity of each cell. (1) If the electrolyte is under the low level, replace the battery (or add di\
stilled water if possible) andcheck the charging system.
2. CHECK BATTERY SPECIFIC GRAVITY (MAINTENANCE TYPE BATTERY)
(a) Check the specific gravity of each cell. Standard specific gravity: 1.25 to 1.29 at 20 C (68 F)
HINT:
If the specific gravity is less than specification, charge the bat-
tery.
3. CHECK BATTERY VOLTAGE
(a) If it has not been 20 minutes since you drove the vehicle or since the engine was stopped, turn the ignition switch
and the electrical system (headlight, blower motor, rear
defogger etc.) to the on position for 60 seconds. This will
remove the surface charge on the battery.
(b) Turn off the ignition switch and the electrical systems.
(c) Measure the battery voltage between the negative (±) and positive (+) terminals of the battery.
Standard voltage: 12.5 to 12.9 V at 20 C (68 F)
HINT:
If the voltage is less than specification, charge the battery.
(d) Check the indicator as shown in the illustration. (Non maintenance type battery)
HINT:
Indicator colorConditionType AType BCondition
GreenBlueGood
DarkWhiteCharging necessary
Clear or light yellowRedReplace
4. CHECK BATTERY TERMINALS, FUSIBLE LINK AND FUSES
(a) Check that the battery terminals are not loosened or corroded.
(b) Check the fusible links, high±current fuses and regular fuses.
http://vnx.su
Page 968 of 2234
190NQ±01
A81052
\bA82936
Type A
Type B BlueWhite
Red
Green Dark
Clear or
light yellow
B00543
±
STARTING & CHARGING CHARGING SYSTEM (1ZZ±FE/3ZZ±FE)
19±5
AVENSIS REPAIR MANUAL (RM1018E)
ON±VEHICLE INSPECTION
1. CHECK BATTERY ELECTROLYTE LEVEL
(a) Check the electrolyte quantity of each cell.
(1) If the electrolyte is under the low level, replace the battery (or add di\
stilled water if possible) andcheck the charging system.
2. CHECK BATTERY VOLTAGE
(a) If it has not been 20 minutes since you drove the vehicleor since the engine was stopped, turn the ignition switch
and the electrical system (headlight, blower motor, rear
defogger etc.) to the on position for 60 seconds. This will
remove the surface charge on the battery.
(b) Turn off the ignition switch and the electrical systems.
(c) Measure the battery voltage between the negative (±) and positive (+) terminals of the battery.
Standard voltage: 12.5 to 12.9 V at 20 C (68 F)
HINT:
If the voltage is less than specification, charge the battery.
(d) Check the indicator as shown in the illustration.
HINT:
Indicator colorConditionType AType BCondition
GreenBlueOK
DarkWhiteCharging necessary
Clear or light yellowRedReplace
3. CHECK BATTERY TERMINALS, FUSIBLE LINK AND FUSES
(a) Check that the battery terminals are not loosened or corroded.
(b) Check the fusible links, high±current fuses and regular fuses.
4. INSPECT DRIVE BELT
(a) Visually check the belt for excessive wear, frayed cordsetc.
HINT:
If any defect found, replace the drive belt.
Cracks on the rib side of a belt are considered acceptable.
If the belt has chunks missing from the ribs, it should be
replaced.
http://vnx.su
Page 1487 of 2234
650SX±01
I35237Clamp
I35228
65±22
±
LIGHTINGFOG LAMP ASSY LH
AVENSIS REPAIR MANUAL (RM1018E)
FOG LAMP ASSY LH
REPLACEMENT
1.REMOVE FRONT BUMPER COVER (See page 76±3) 2.REMOVE FOG LAMP ASSY LH
(a)Disconnect the connector.
(b)Remove the 2 screws.
(c)Release the claw fitting, then remove the fog lamp assyLH.
(d)Remove the fog lamp bulb as shown in the illustration.
3.ADJUST FOG LIGHT AIM (See page 65±23)
4. CHECK FOG LIGHT AIM
http://vnx.su
Page 1488 of 2234
650SY±01
I35230
±
LIGHTINGFOG LAMP ASSY LH
65±23
AVENSIS REPAIR MANUAL (RM1018E)
ADJUSTMENT
1.PUT VEHICLE THESE CONDITIONS
(a)Tire inflation pressure is within the specified value. (See page 28±1)
(b) Start the engine.
2. ADJUST FOG LIGHT AIM
(a) The fog light aim can be adjusted by turning the aimingscrew in the vertical direction.
HINT:
The optical aim moves upward when turning the screwdriver
clockwise and moves downward when turning the screwdriver
center clockwise.
3. CHECK FOG LIGHT AIM
http://vnx.su
Page 1500 of 2234
650NC±02
±
LIGHTING LIGHTING SYSTEM
65±1
AVENSIS REPAIR MANUAL (RM1018E)
LIGHTING SYSTEM
PRECAUTION
1. PRECAUTION OF HEADLIGHT BULB REPLACEMENT
(a) When any defects such as deformation, crack, dent, chipping, etc. are identi\
fied on the discharge
headlight (especially, on the light control ECU), replace it with a new one.
(b) Even if the operation seems to be normal, the fail±safe function may \
be defective.
(c) Be careful not to scratch on drop bulbs of the discharge headlamp and halo\
gen bulbs (for headlamp and fog lamp), as they have pressurized gas inside and can be easily broke\
n.
(d) Touching the HV socket of the discharge headlight with the headlight dimmer swit\
ch ON could gener- ate momentary high voltage of 20,000 V and lead to a serious injury.
(e) Never connect a tester to the high voltage socket of the discharge headlight \
for measurement, as this
leads to a serious injury because of high voltage.
(f) When performing operation related to the discharge headlight, keep it away from water including rain, turn off the light control switch, and disconnect the battery terminal and the \
connector of the light control
ECU in advance to avoid electric shock.
(g) When performing operation related to the discharge headlight, start it after\
assembling is completed
and never turn the lights on without a bulb installed.
(h) Do not turn the discharge headlight on using another power source except\
vehicle's.
http://vnx.su
