Page 301 of 516
3015-2. Using the interior lights
5
Interior features
C-HR_OM_USA_OM10526U■
Front
Turns the door position on/off
■Rear
On
Door position
Off
Interior lights
Page 302 of 516

3025-2. Using the interior lights
C-HR_OM_USA_OM10526U
Turns the lights on/off
When the lights are on due to the
door link switch, a light will not turn
off even if its switch is pressed.
■Illuminated entry system
Vehicles without a smart key system
When the interior light switch is in the door position, the interior lights auto-
matically turn on/off according to the engine switch position, whether the
doors are locked/unlocked and whether the doors are open/closed.
Vehicles with a smart key system
When the interior light switch is in the door position, the interior lights and
engine switch light automatically turn on/off according to engine switch mode,
the presence of the electronic key, whether the doors are locked/unlocked
and whether the doors are open/closed.
■ Outer mirror illumination (if equipped)
The illumination automatically turns on according to the presence of the elec-
tronic key (vehicles with a smart key system), or the doors are unlocked.
■ To prevent battery discharge
The following lights will turn off automatically after 20 minutes:
●Front interior light/front personal lights
● Rear interior light
● Luggage compartment light
● Vanity lights (if equipped)
■ Customization
Settings (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: →P. 474)
Personal lights
Page 303 of 516
3035-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10526U
List of storage features
Glove box (→P. 304)
Bottle holders ( →P. 305) Cup holders (
→P. 306)
Console box ( →P. 304)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spaces, as t\
his
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other stored items, the lighter may catch fire or the spray can may release
gas, causing a fire hazard.
● When driving or when the storage com partments are not in use, keep the
lids closed and trays clear.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
Page 304 of 516
3045-3. Using the storage features
C-HR_OM_USA_OM10526U
Press the button to open the glove
box.
The glove box light turns on when the tail lights are on.
Lift the lid while pulling up the
knob.
Glove box
Console box
Page 305 of 516
3055-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10526U
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
Bottle holders
FrontRear
WARNING
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glass or paper cups containing liquid. The contents may spill
and glass cups may break.
Page 306 of 516
3065-3. Using the storage features
C-HR_OM_USA_OM10526U
Cup holders
The depth of the rear side cup holder can
be changed as shown in the illustration.
WARNING
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.
Page 307 of 516
3075-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10526U
Luggage compartment features
Cargo hooks are provided for
securing loose items.
Cargo hooks
WARNING
To avoid injury, always return the cargo hooks to their positions when they
are not in use.
Grocery bag hooks
NOTICE
Do not hang any object heavier than 4.4 lb. (2 kg) on the grocery bag hook.\
Page 308 of 516
3085-3. Using the storage features
C-HR_OM_USA_OM10526U
Lift the deck mat tab and pull it
toward you to remove it.
Auxiliary boxes
Side auxiliary boxes
Page 309 of 516
3095-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10526U
Ty p e A
Unhook the cords and return
the luggage cover to horizontal
position.
Pull it toward you and then lift
the luggage cover to remove it.Installation position
Confirm that the cover has been
securely installed to the original
position when installing.
Removal position
Luggage cover
1
2
Page 310 of 516
3105-3. Using the storage features
C-HR_OM_USA_OM10526U
Ty p e B
■Removing the luggage cover
Unhook the cords.
Unhook the hook to the hook
brackets.
■Stowing the luggage cover
Hold the luggage cover with
both hands. Point your
thumbs in opposite direc-
tions.
1
2
1
