Page 241 of 307

TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Repair Manual 241
RADIATOR FAN AND CONDENSER FAN (5S±FE)
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
A 130E 530 (5S±FE)
A 230 (5S±FE)R 130 (5S±FE)
: RELAY BLOCKS
CODESEE PAGERELAY BLOCKS (RELAY BLOCK

Page 245 of 307

TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Repair Manual 245
THE COOLING FAN ECU RECEIVES VARIOUS SIGNAL, I.E., THE ENGINE RPM SIGNAL FROM THE IGNITER, COOLANT TEMPERATURE
SIGNAL FROM THE ENGINE COOLANT TEMP. SENSOR (WATER TEMP. SENSOR), A/C REFRIGERANT PRE

245
THE COOLING FAN ECU RECEIVES VARIOUS SIGNAL, I.E., THE ENGINE RPM SIGNAL FROM THE IGNITER, COOLANT TEMPERATURE
SIGNAL FROM THE ENGINE COOLANT TEMP. SENSOR (WATER TEMP. SENSOR), A/C REFRIGERANT PRESSURE SIGNAL FROM A/C
SINGLE PRESSURE SW.
THE COOLING FAN ECU JUDGES THE ENGINE BASED ON SIGNALS FROM ABOVE MENTION, DRIVES THE SOLENOID VALVE AND
CONTROLS THE SPEED OF THE COOLING FAN STEPLESSLY
FAIL±SAFE FUNCTION
WHEN THE MALFANCTION IS DETECTED BY THE ENGINE COOLANT TEMP. SENSOR (WATER TEMP. SENSOR) OR SOLENOID VALVE,
THE FAIL±SAFE FUNCTION OF THE COOLING FAN ECU JUDGES THE SITUATION TO ALLOWS THE COOLING SYSTEM TO CONTINUE
OPERATION.
A 2 A/C SINGLE PRESSURE SW
2±3 : OPEN ABOVE APPROX. 15.58KG/CM2 (221.2PSI, 1527KPA)
CLOSED BELOW APPROX. 12.56 KG/CM2
(178.4PSI, 1231KPA)
C14 COOLING FAN ECU
1±GROUND : APPROX. 12 VOLTS WITH THE IGNITION SW ON
9±10 :2.5 VOLTS AT 20°C (68°F) AND IGNITION SW ON
1.2 VOLTS AT 80°C (176°F) AND IGNITION SW ON
8± 4 :10±14 VOLTS AT A/C PRESSURE SW ON (OPEN)
0±3 VOLTS AT A/C PRESSURE SW OFF (CLOSE)
4±GROUND : ALWAYS CONTINUITY
E 5 ENGINE COOLANT TEMP. SENSOR (WATER TEMP. SENSOR) (FOR COOLING FAN)
1±2 :1.5K AT 80°C (176°F)
0.7K AT 11 0°C (230°F)
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
A 228D 128S 129
C1432E 530
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1A20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
3A24COWL WIRE AND J/B NO 3 (BEHIND COMBINATION METER)3C24COWL WIRE AND J/B NO. 3 (BEHIND COMBINATION METER)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
EC138 (1MZ±FE)ENGINE WIRE AND ENGINE ROOM MAIN WIRE
IP244ENGINE WIRE AND COWL WIRE
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
EB38 (1MZ±FE)FRONT LEFT FENDER
EC38 (1MZ±FE)INTAKE MANIFOLD RH
: SPLICE POINTS
CODESEE PAGEWIRE HARNESS WITH SPLICE POINTSCODESEE PAGEWIRE HARNESS WITH SPLICE POINTS
I1844ENGINE WIRE
2312
534
6X8 91012
12 A2 C14S1 E5BROWN GRAY BLACKD1BLACK
6
XX X
XX X XX
X
SYSTEM OUTLINE
SERVICE HINTS

Page 250 of 307

TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Repair Manual 250
AIR CONDITIONING (PUSH CONTROL SW TYPE)
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
A 228 (1MZ±FE), 30 (5S±FE)A1732H 833
A 328 (1MZ±FE), 30 (5S±FE)B 432I 230 (5S±FE)
A1032B 532J 133

Page 254 of 307

TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Repair Manual 254
AIR CONDITIONING (LEVER CONTROL SW TYPE)
CURRENT ALWAYS FLOWS FROM THE HEATER FUSE TO TERMINAL 5 OF THE HEATER RELAY. WHEN THE IGNITION SW IS TURNED
ON, CURRENT FLOWS FROM GAUGE FUSE TO TERMINAL 2

254
AIR CONDITIONING (LEVER CONTROL SW TYPE)
CURRENT ALWAYS FLOWS FROM THE HEATER FUSE TO TERMINAL 5 OF THE HEATER RELAY. WHEN THE IGNITION SW IS TURNED
ON, CURRENT FLOWS FROM GAUGE FUSE TO TERMINAL 2 OF THE AIR VENT MODE CONTROL SERVO MOTOR AND A/C MAGNETIC
CLUTCH RELAY (COIL SIDE) " TERMINAL 12 OF THE A/C AMPLIFIER, TERMINAL 1 OF THE A/C DUAL PRESSURE SW " TERMINAL 4
" TERMINAL 2 OF THE A/C AMPLIFIER, HEATER RELAY (COIL SIDE) " TERMINAL 3 OF THE BLOWER SW.
1. OPERATION OF AIR VENT MODE CONTROL SERVO MOTOR
WHEN THE DAMPER IS IN FACE POSITION AND THE BI±LEVEL OF THE AIR VENT MODE CONTROL SW IS THEN TURNED ON,
CURRENT FLOWS FROM TERMINAL 7 OF THE AIR VENT MODE CONTROL SW " TERMINAL 5 OF THE AIR VENT MODE CONTROL
SERVO MOTOR SO THAT A SIGNAL THAT THE GROUND CIRCUIT IS ACTIVATED IS INPUT TO TERMINAL ªBº OF THE CONTROL
CIRCUIT INSIDE THE AIR VENT MODE CONTROL SERVO MOTOR. SIMULTANEOUSLY, A SIGNAL THAT THE GROUND CIRCUIT IS NOT
ACTIVATED IS INPUT TO TERMINAL ªAº OF THE CONTROL CIRCUIT INSIDE THE SERVO MOTOR. THESE TWO SIGNALS ACTIVATE
THE CONTROL CIRCUIT SO THAT CURRENT FROM THE GAUGE FUSE TO THE SERVO MOTOR, CAUSING THE SERVO MOTOR TO
OPERATE AND THE DAMPER TO MOVE TO BI±LEVEL POSITION. WHEN THE DAMPER REACHES BI±LEVEL POSITION. A GROUND
CUT SIGNAL IS INPUT TO TERMINAL ªBº OF THE CONTROL CIRCUIT, THE CONTROL CIRCUIT OPERATES, THE SERVO MOTOR
STOPS ROTATING AND THE DAMPER STOPS AT BI±LEVEL.
WHEN ANOTHER MODE POSITION IS SWITCHED TO, INPUT OF SIGNALS TO TERMINAL ªAº AND TERMINAL ªBº OF THE CONTROL
CIRCUIT THAT GROUND IS NOT MADE (AS EXPLAINED ABOVE) ACTIVATES THE CONTROL CIRCUIT AND MOVES THE SERVO
MOTOR TO THE DESIRED POSITION.
2. AIR CONDITIONING OPERATION
WHEN THE BLOWER SW IS ON, CURRENT FLOWS THE GAUGE FUSE " HEATER RELAY (COIL SIDE) " TERMINAL 3 OF THE
BLOWER SW " TERMINAL 1 " GROUND, ACTIVATING THE HEATER RELAY. THIS CAUSES CURRENT TO FLOW FROM THE HEATER
FUSE TO THE HEATER RELAY (POINT SIDE) " A/C FUSE " TERMINAL 2 OF THE A/C SW. IF THE A/C SW IS THEN TURNED ON AT
THIS TIME. A SIGNAL IS INPUT TO THE A/C AMPLIFIER. THIS ACTIVATES THE A/C AMPLIFER AND A/C MAGNETIC CLUTCH RELAY SO
THAT CURRENT FLOWS FROM THE GAUGE FUSE TO THE A/C MAGNETIC CLUTCH RELAY (POINT SIDE) " A/C MAGNETIC CLUTCH.
CAUSING THE COMPRESSOR TO OPERATE. THE VSV (FOR A/C IDLE±UP) IS TURNED ON SIMULTANEOUSLY TO PREVENT A
DECREASE IN ENGINE SPEED DUE TO A/C OPERATION.
HEATER RELAY
(4)5± (4)4 : CLOSED WITH THE IGNITION SW ON AND BLOWER SW ON
A/C MAGNETIC CLUTCH RELAY
(5)5± (5)3 : CLOSED WITH THE IGNITION SW ON AND BLOWER SW ON AND A/C SW ON
A 2 A/C DUAL PRESSURE SW
1±4 : OPEN WITH PRESSURE 2.1 KG/CM (30 PSI, 206 KPA) OR ABOVE 27 KG/CM (384 PSI, 2646 KPA)
B 5 BLOWER RESISTOR
6±1 : APPROX. 3.17 W
6±3 : APPROX. 1.38 W
2±6 : APPROX. 0.38 W
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
A 228 (1MZ±FE), 30 (5S±FE)A1732H 833
A 328 (1MZ±FE), 30 (5S±FE)B 432I 230 (5S±FE)
A1032B 532J 133
A1132B 632
A1232C1432
: RELAY BLOCKS
CODESEE PAGERELAY BLOCKS (RELAY BLOCK LOCATION)
425R/B NO. 4 (RIGHT KICK PANEL)
526R/B NO. 5 (ENGINE COMPARTMENT LEFT)
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1B20COWL WIRE AND J/B NO 1 (INSTRUMENT PANEL LEFT)1D20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
SYSTEM OUTLINE
SERVICE HINTS

Page 255 of 307

TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Repair Manual 255
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
EC138 (1MZ±FE)ENGINE WIRE AND ENGINE ROOM MAIN WIREEC140 (5S±FE)ENGINE WI

Page 260 of 307

TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Repair Manual 260
GROUND POINT* 2 : TMM MADE *
1:TMCMADE
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
J 133J 536 (W/G)
J 233J 733
: RELAY BLOCKS
CODESEE PAGERELAY BLOCKS (RELAY BLOCK LOCATION)
125R/B NO. 1

260
GROUND POINT* 2 : TMM MADE *
1:TMCMADE
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
J 133J 536 (W/G)
J 233J 733
: RELAY BLOCKS
CODESEE PAGERELAY BLOCKS (RELAY BLOCK LOCATION)
125R/B NO. 1 (LEFT KICK PANEL)
425R/B NO. 4 (RIGHT KICK PANEL)
526R/B NO. 5 (ENGINE COMPARTMENT LEFT)
626R/B NO. 6 (BEHIND GLOVE BOX)
727R/B NO. 7 (NEAR THE BATTERY)
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1C
1F20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
1G
20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
1I20 (*1)ROOF WIRE AND J/B NO. 1 (INSTRUMENT PANEL) TMC MADE1I20 (*2)COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL) TMM MADE
1M20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
2B22ENGINE ROOM MAIN WIRE AND J/B NO 2 (ENGINE COMPARTMENT LEFT)2E22ENGINE ROOM MAIN WIRE AND J/B NO. 2 (ENGINE COMPARTMENT LEFT)
2F22COWL WIRE AND J/B NO. 2 (ENGINE COMPARTMENT LEFT)
3A
3B24COWL WIRE AND J/B NO 3 (BEHIND COMBINATION METER)3C24COWL WIRE AND J/B NO. 3 (BEHIND COMBINATION METER)
3D
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODESEE PAGEJOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
EA138 (1MZ±FE)ENGINE ROOM MAIN WIRE AND ENGINE ROOM NO. 3 WIRE
EB138 (1MZ±FE)ENGINE ROOM MAIN WIRE AND RELAY WIREEB140 (5S±FE)ENGINE ROOM MAIN WIRE AND RELAY WIRE
IH242FRONT DOOR LH WIRE AND INSTRUMENT PANEL WIRE
IJ142FLOOR NO. 1 WIRE AND COWL WIRE
IK142COWL WIRE AND A/C SUB WIRE
IL142COWL WIRE AND SERVO MOTOR SUB WIRE
IM242INSTRUMENT PANEL WIRE AND CONSOLE BOX WIRE
IO142FLOOR NO. 1 WIRE AND SEAT WIRE
IP344ENGINE WIRE AND COWL WIRE
IQ144ENGINE WIRE AND INSTRUMENT PANEL WIRE
IT144FRONT DOOR RH WIRE AND INSTRUMENT PANEL WIRE
IV144ROOF WIRE AND COWL WIRE
IV244ROOF WIRE AND COWL WIRE MADE IN USA
46 (S/D)
BX148 (C/P)FUEL GAUGE WIRE AND FLOOR NO. 1 WIREBX1
50 (W/G)
FUEL GAUGE WIRE AND FLOOR NO. 1 WIRE
BZ146 (S/D)LUGGAGE ROOM NO 1 WIRE AND FLOOR NO 1 WIREBZ148 (C/P)LUGGAGE ROOM NO. 1 WIRE AND FLOOR NO. 1 WIRE
Ba146 (S/D)FLOOR NO 1 WIRE AND LUGGAGE ROOM NO 2 WIREBa148 (C/P)FLOOR NO. 1 WIRE AND LUGGAGE ROOM NO. 2 WIRE
Bb150 (W/G)LUGGAGE ROOM NO. 1 WIRE AND FLOOR NO. 1 WIRE
Bc150 (W/G)BACK DOOR NO. 1 WIRE AND FLOOR NO. 1 WIRE
Bd350 (W/G)BACK DOOR NO. 1 WIRE AND BACK DOOR NO. 2 WIRE

Page 261 of 307

TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Repair Manual 261
: GROUND POINTS
CODESEE PAGEGROUND POINTS LOCATION
EA38 (1MZ±FE)FRONT RIGHT FENDEREA40 (5S±FE)FRONT RIGHT FENDER
EB38 (1MZ±FE)FRONT LEFT FENDEREB40 (5S±FE)FRONT LEFT FENDER
EC38 (1MZ±FE)INTAK
