TOYOTA CAMRY 1999 Service Repair Manual

SEAT COVER LOOSENESS ± BO020±99 December 17, 1999
Page 2 of 3
1. For easier repair remove the complete
seat assembly.
2. If necessary, remove the manual seat
adjuster handle.
3. Bend the locking tabs down.
4. Completely disengage the J±clip from
the seat adjuster frame (front area
only).
5. Using a screwdriver, bend the frame
J±clip retention clips to the front.
(Approximately 1.5 mm)
NOTE:
Original Condition: Retention clips are
bent to the rear.
NOTE:
With a screwdriver, bend all 5 retention
clips 1.5 mm forward.
Repair
Procedure
Seat CoverJ±Clip/Rail
Seat Bottom Locking Tabs
Up
Front
1.5 mm Seat Adjuster Frame
J±clip

SEAT COVER LOOSENESS ± BO020±99 December 17, 1999
Page 3 of 3
6. Reassemble the seat cushion.
7. Bend the locking tabs over the
cushion.
8. After reinstallation of the seat and
manual seat adjuster handle
(if removed), check the seat cushion
retention and seat operation
(sit on seat and push cushion down).
9. Tighten the seat mounting screws to
the torque specifications in the Repair
Manual.Repair
Procedure
(Continued)
Locking Tabs

Toyota Supports ASE CertificationPage 1 of 2
BO021±99
Title:
SUNROOF OPERATION
Models:
'97 ± '99 TMMK Camry
Technical Service
BULLETIN
December 17, 1999

Some 1997 ± 1999 TMMK Camry vehicles may experience an interruption in sunroof
operation (not opening or closing). Changes have been made to the roof drip channel
guides to improve operation. The guides were modified to increase the clearance
between the sun shade and opening flange by 2 mm. A radius was added to eliminate
the sharp corners of the guides.
1997 ± 1999 TMMK Camry vehicles built before the production change.
MODELPLANTSTARTING VIN
Camry (TMMK)Plant 14T1BG*XU543595/BF*XU083791Camry (TMMK)Plant 24T1BG*XU901534/BF*XU932010
PREVIOUS PART NUMBERCURRENT PART NUMBERPART NAME
63222±AA010SameRoof Drip Channel Guide ± LH
63221±AA010SameRoof Drip Channel Guide ± RH
OPCODEDESCRIPTIONTIMEOPNT1T2
614141R & R Drip Channel Guide, Both RH and LH2.063222±AA0105383
Applicable Warranty*:
This repair is covered under the Toyota Basic Warranty. This warranty is in effect for
36 months or 36,000 miles, whichever occurs first, from the vehicle's in±service date.
* Warranty application is limited to correction of a problem based upon a customer's specific complaint.
BODY
Introduction
Applicable
Vehicles
Production
Change
Information
Parts
Information
Warranty
Information

SUNROOF OPERATION ± BO021±99 December 17, 1999
Page 2 of 2
Remove the Roof Drip Channel Guides (left & right) and replace with the current parts.
RH Lift Arm and Cable Assembly
RH Roof Drip Channel GuideRoof Drip Channell
LH Lift Arm and Cable Assembly
Drive Rail Assembly
LH Roof Drip Channel Guide
Repair
Procedure

Toyota Supports ASE CertificationPage 1 of 1
BO025-01Title:
SUNVISOR VANITY MIRROR
IMPROVEMENT
Models:
'97 ± '01 NAP Camry
Technical Service
BULLETIN
October 12, 2001

Production changes have been implemented on the 1997 ± 2001 model year NAP Camry
vanity mirror assembly to improve strength and durability of the mirror cover hinge.
Mirror Cover Hinge
1997 ± 2001 model year NAP Camry vehicles.
MODELSTARTING VIN
2001 Camry4T1B#2#K#1U045764 (Line 1)
4T1B#2#K#1U798163 (Line 2)
PREVIOUS PART NUMBERCURRENT PART NUMBERPART NAME
74310±AA095±A0/B0/G074310±AA096±A0/B0/G0Right Sunvisor Assembly
74320±AA055±A0/B0/G074320±AA056±A0/B0/G0Left Sunvisor Assembly
Replace damaged sunvisor with a service part.
OP CODEDESCRIPTIONTIMEOPNT1T2
752101R & R RH and/or LH Sunvisor Assembly0.2
74310±AA095±##
or
74320±AA055±##
6216
Applicable Warranty*:
This repair is covered under the Toyota Comprehensive Warranty. This warranty is in
effect for 36 months or 36,000 miles, whichever occurs first, from the vehicle's
in-service date.
* Warranty application is limited to correction of a problem based upon a customer's specific complaint.
BODY
Introduction
Applicable
Vehicles
Production
Change
Information
Parts
Information
Repair
Procedure
Warranty
Information

Toyota Supports ASE CertificationPage 1 of 4
BO026-01Title:
SHOULDER BELT ANCHOR TAPE SET
Models:
All Applicable Avalon, Camry, Corolla,
Previa & Sienna
Technical Service
BULLETIN
October 19, 2001

To assist customers in preventing particle buildup and preserve the appearance of the
shoulder belt anchor, the following procedure has been developed.
1996 ± 1999 model year Avalon vehicles.
1996 ± 2001 model year Camry vehicles.
1993 ± 2001 model year Corolla vehicles.
1996 ± 1997 model year Previa vehicles.
1998 ± 2001 model year Sienna
*1 vehicles.
*1Except rear seat belt.
CURRENT PART NUMBERPART NAME
73205±48011Tape Set, Shoulder Belt Anchor
NOTE:
The above tape set contains the fluorocarbon resin tape (2 pieces) and Velcro tape (1 piece).
OP CODEDESCRIPTIONTIMEOPNT1T2
BD1011Clean the Shoulder Belt Anchor0.373210±#####±##*1
73220±#####±##*16199
*1
OPN should be part number of whichever belt assembly that the procedure is performed on.
Applicable Warranty*:
This repair is covered under the Toyota Comprehensive Warranty. This warranty is in
effect for 36 months or 36,000 miles, whichever occurs first, from the vehicle's
in-service date.
* Warranty application is limited to correction of a problem based upon a customer's specific complaint.
BODY
Introduction
Applicable
Vehicles
Parts
Information
Warranty
Information

October 19, 2001SHOULDER BELT ANCHOR TAPE SET ± BO026-01
Page 2 of 4
1. CLEAN SHOULDER BELT ANCHOR
NOTE:
Do not install the tape when the
vehicle temperature is below the
freezing point.
Do not re±use removed fluorocarbon
resin tape.
A. Pull out the seat belt about 300
mm and attach a clip as shown in
the illustration.
HINT:
Preventing the seat belt from retraction
with a clip will make the following
work easier.
B. Put the Velcro tape (in the parts
kit) through the hole of the
shoulder belt anchor,
brush±shaped side to the anchor.
C. Pull both ends of the Velcro tape
with your hand and shave off the
dirt on the shoulder belt anchor by
moving the Velcro tape several
times as shown in the illustration.
NOTE:
Remove the dirt completely. Otherwise,
the fluorocarbon resin tape may not
adhere properly. Installation
Procedure

October 19, 2001SHOULDER BELT ANCHOR TAPE SET ± BO026-01
Page 3 of 4
2. INSTALL FLUOROCARBON RESIN
TAPE
A. Place the fluorocarbon resin tape
onto the seat belt as shown in the
illustration.
NOTE:
Before installation of the fluorocarbon
resin tape, it is necessary to pre±release
the colored film about 5 mm for each
side. (Not fully released.)
B. By pulling up the seat belt, put the
fluorocarbon resin tape through
the hole of the shoulder belt
anchor. Match the shoulder belt
anchor to the center of the tape.
C. Remove the upper side colored
film from the fluorocarbon resin
tape, and securely affix the tape
to the outside of the shoulder belt
anchor.
D. Remove the lower side colored
film from the fluorocarbon resin
tape, and securely affix the tape
to the outside of the shoulder belt
anchor.
NOTE:
Be sure to affix the fluorocarbon
tape securely along all edges.
Pay attention not to make any
wrinkles or slack in the fluorocarbon
resin tape.
E. Remove the clip.
Installation
Procedure
(Continued)

October 19, 2001SHOULDER BELT ANCHOR TAPE SET ± BO026-01
Page 4 of 4
F. By pulling the seat belt up and
down several times, as shown in
the illustration, securely affix the
fluorocarbon resin tape and
confirm the smoothness of the
belt movement.
NOTE:
Affix the fluorocarbon resin tape on
the shoulder belt anchor to the other
side following the same procedure.
NOTE:
If the seat belt requires cleaning to
remove dirt, only use a neutral
detergent or lukewarm water to clean.
Use the seat belt after it is completely
dried, to confirm proper operation.
Installation
Procedure
(Continued)

Toyota Supports ASE CertificationPage 1 of 1
BO028-00Title:
LEAKS INTO TRUNK
Models:
'97 - '01 Camry (U.S.), '98 - '01 Sienna,
'99 - '01 Solara & '01 Avalon
Technical Service
BULLETIN
November 3, 2000

A field fix is available for incidents of moisture and odors permeating into the vehicle.
The Quarter Panel Air Duct flaps may have become loose or missing. Replacing the
Quarter Panel Air Duct will remedy the condition.
1997 ± 2001 model year Camry (U.S. produced)
1998 ± 2001 model year Sienna
1999 ± 2001 model year Solara
2001 model year Avalon
MODELSTARTING VIN
2001 MY Camry, 4 cylinder4T1BG22K81U019710
4T1BG22KB1U768622
2001 MY Camry, 6 cylinder4T1BF28K11U116208
4T1BF22K51U958204
2001 MY Sienna4T3ZF13C#1U335575
2001 MY Solara2T1CF22P#1C435983
2001 MY Solara Convertible2T1FF28P#1C435448
2001 MY Avalon4T1BF28B11U123532
PREVIOUS PART NUMBERCURRENT PART NUMBERPART NAME
62940-AA01062940-AA011Quarter Panel Air Duct
Replace the Quarter Panel Air Duct.
OP CODEDESCRIPTIONTIMEOPNT1T2
BD0036R & R Quarter Panel Air Duct1.062940-AA0106257
Applicable Warranty*:
This repair is covered under the Toyota Basic Warranty. This warranty is in effect for
36 months or 36,000 miles, whichever occurs first, from the vehicle's in-service date.
* Warranty application is limited to correction of a problem based upon a customer's specific complaint.
BODY
Introduction
Applicable
Vehicles
Production
Change
Information
Parts
Information
Repair
Procedure
Warranty
Information
