sport mode TOYOTA CAMRY 2000 Service Repair Manual

CAMRY
CAMRY ± OUTLINE OF NEW FEATURES 26
OUTLINE OF NEW FEATURES
The CAMRY is a high-quality family sedan with advanced technology and sporty performance. The following
changes are made for the 2000 model year.
1. Model Line-Up
The 5S-FNE CNG (Compressed Natural Gas) engine model has been added.
2. Exterior
Four new exterior colors have been added, for a total of 10 colors.
The design of the front and rear bumpers has been changed.
The bumper and the radiator grille have been made separate, and the radiator grille is chrome-plated.
The side protection molding has been increased in size. On the XLE grade model, chrome stripes have been
adopted for the side protection molding.
The 4-light multi-reflector type headlights are adopted with new styling.
The design and styling of the rear combination light has been changed.
The 16º aluminum alloy wheel and wheel cap has been added.
The styling of the 15º full wheel cover has been changed.
3. Interior
Wood-grain panels have been adopted in the interior of the XLE grade model.
CRS tether anchor brackets have been provided on the package tray trim. (except 5S-FNE engine Model)
A clock with an outside temperature gauge has been provided on the models with manual air conditioning.
4. 5S-FE Engine
The intake system from the inlet duct to the throttle body has been improved to increase torque and reduce
noise.
The direction of the rotation of the radiator cooling fan has been reversed.
A 2-way exhaust control system has been adopted on the TMMK made model.
Along with the discontinuance of the air assist system, the fuel injectors and the IAC valve have been
changed for the California specification model, in order to meet ULEV (Ultra-Low Emission Vehicle) re-
quirement.
The system for detecting evaporative emission leaks has been changed. For details, see the General 2000
Features section.
5. 5S-FNE Engine
Based on the 5S-FE gasoline engine, the 5S-FNE engine uses compressed natural gas. The fuel lines have
been designed exclusively for compressed natural gas application.
6. 1MZ-FE Engine
The system for detecting evaporative emission leaks has been changed. For details, see the General 2000
Features section.
A diagnostic trouble code (DTC) has been added for indicating a thermostat malfunction.
7. Automatic Transaxle
The overdrive switch has been changed to the momentary type. For details, see the General 2000 Features
section.
The differential gear ratio of the A140E automatic transaxle has been changed for the 5S-FNE engine mod-
el to accommodate the performance of the 5S-FNE engine.

CAMRY - OUTLINE OF NEW FEATURES
CAMRY
172CM01
2
OUTLINE OF NEW FEATURES
The Camry is a high-quality family sedan with advanced technology and sporty performance. The following
changes are made for the 2001 model year.
1. 5S-FE Engine
The 5S-FE engine that are equipped on the '00 California specification models, which comply with the U-
LEV (Ultra-Low Emission Vehicle) requirements, have now been provided on the all models.
2. 1MZ-FE Engine
The 1MZ-FE engine that are equipped on the '00 California specification models, which comply with the
LEV (Low Emission Vehicle) requirements, have now been provided on the all models with the automatic
transaxle.
3. Brake
The size of front brake disc on 5S-FE engine model of CE grade has been changed from usual 255 mm (10.0
in.) for the 14-inch wheel to 275 mm (10.8 in.) for the 15-inch wheel.
4. Seat
A seat heater is established as an option to the driver seat and front passenger seat of the vehicle with leather
seats for Canada, thus improved the heating performance in the cold districts.
5. Internal Trunk Release Handle
An internal trunk release handle is included inside the trunk in case a person inadvertently locks oneself with-
in the trunk and needs to free oneself.
The handle is made of phosphorecent so that it is visible in the trunk for a while even after the trunk has been
closed.

12
EXTERIOR
STYLING
Based on the ªyouthful, elegant, and sporty sedanº design concept, the new Camry has realized a design taste that
features a sharp surface quality. In addition to this unique character, the new model keeps up with the trend with its
longer wheel base and a cab±forward configuration.

CAMRY ± OUTLINE OF NEW FEATURES
CAMRY
2
OUTLINE OF NEW FEATURES
The Camry is a high-quality family sedan with advanced technology and sporty performance. The following
changes are made for the 1998 model year.
1. Model Line-Up
The SXV20L-AEPNKK and MCV20L-A (C) EPGKK models have been added.
The MCV20L-CEPNKK model has been discontinued.
2. Interior Equipment
An extensible assist grip has been newly provided for the front passenger.
3. 5S-FE Engine
ORVR (On-Board Refueling Vapor Recovery) System has been adopted.
4. 1MZ-FE Engine
The 1MZ-FE engine with automatic transaxle on the California specification model uses the air-fuel ratio
sensor and the WU-TWC (Warm Up-Three-Way Catalytic Converters) to reduce exhaust emissions.
5. Body
The cross section shape of the outside windshield moulding has been changed to reduce the wind noise.
The front door window glass has been increased in thickness to reduce the amount of noise transmitted
from the outside of the vehicle.
Front seat belt with pretensioner and force limiter has been adopted.
6. Engine Immobiliser System
An engine immobiliser system has been newly provided to help improve the vehicle's theft prevention perfor-
mance.
7. Theft Deterrent System
The starter cutoff function has been discontinued along with the adoption of the engine immobiliser sys-
tem.
The illumination pattern of the indicator light which indicates the condition of the system has been
changed.

APPENDIX ± SUPRA
U.S.A.
Power Steering TypeItemArea
Body Type
Vehicle Grade
Model Code
OverallLength mm (in.)
Width mm (in.)
Height* mm (in.)
Wheel Base mm (in.)
TreadFront mm (in.)
Rear mm (in.)
Effective Head RoomFront mm (in.)
Rear mm (in.)
Front mm (in.)
Rear mm (in.)
Front mm (in.)
Rear mm (in.)
Front mm (in.)
Rear mm (in.) Effective Leg Room
Shoulder Room
Overhang
Min. Running Ground Clearance mm (in.)
Angle of Approach degrees
Angle of Departure degrees
Curb Weight
Gross Vehicle WeightFront kg (lb)
Rear kg (lb)
Total kg (lb)
Front kg (lb)
Rear kg (lb)
Total kg (lb)
Fuel Tank Capacity (US.gal, Imp.gal)
Luggage Compartment Capacity cu.ft. (m
3)
Max. Speed km / h (mph)
Max. Cruising Speed km / h (mph)
Acceleration
Max. Permissible
Speed
Turning Diameter
(Outside Front)0 to 100 km / h sec.
0 to 400 m sec.
1st Gear km / h (mph)
2nd Gear km / h (mph)
3rd Gear km / h (mph)
4th Gear km / h (mph)
Wall to Wall m (ft.)
Curb to Curb m (ft.)
Engine Type
Valve Mechanism
Bore x Stroke mm (in.)
Displacement cm
3 (cu.in.)
Compression Ratio
Carburetor Type
Research Octane No. RON
Max. Output (SAE-NET) kW / rpm (HP@rpm)
Max. Torque (SAE-NET) N
.m / rpm (lb-ft@rpm)
Battery Capacity (5HR) Voltage & Amp. hr.
Generator Output Watts
Starter Output kW
Clutch Type
Transmission Type
Transmission Gear
Ratio
Differential Gear Ratio
Differential Gear Size mm (in.)
Brake Type
Parking Brake Type
Brake Booster Type and Size in.
Proportioning Valve Type
Suspension Type
Stabilizer Bar
Steering Gear Type
Steering Gear Ratio (Overall)In First
In Second
In Third
In Fourth
In Fifth
In Reverse
Front
Rear
Front
Rear
Front
Rear
5
10
15
20
25
30
35
40
45
50
55
60
65
70
Major Dimensions & Vehicle Weights Performance Engine Engine
Chassis
Electrical
2-Door Liftback (Standard Roof) 2-Door Liftback (Sport Roof)
Ð
In Sixth
2-Door Liftback (Standard Roof) 2-Door Liftback (Sport Roof)
151

SUPRA
JZA80L-ALPVFA JZA80L-AJPVFA JZA80L-ALFVZA JZA80L-AJFVZA
4515 (177.8)



1810 (71.3)



1275 (50.2)



2550 (100.4)



1520 (59.8)



1525 (60.0)



953.2 (37.5) 946.8 (37.3) 953.2 (37.5) 946.8 (37.3)
834.5 (32.9)



1117.0 (44.0)



605.1 (23.8)



1376.3 (54.2)



1113.2 (43.8)



950 (37.4)



1015 (40.0)



120 (4.7)



13



17



778 (1715) 789 (1740) 855 (1885) 866 (1910)
703 (1550) 719 (1585) 708 (1560) 723 (1595)
1481 (3265) 1508 (3325) 1563 (3445) 1589 (3505)
937 (2065)



1002 (2210)



1939 (4275)



70 (18.5, 15.4)



ÐÐÐÐ
240 (149)
250 (155)

193 (120)
200 (125)

7.3
5.1 5.1
15.6
13.5 13.5
58 (36)
60 (37)

105 (65)
97 (60)

Ð Ð 136 (85)

Ð Ð 175 (109)

11.5 (38)



10.9 (36)



2JZ-GE
2JZ-GTE

24-Valve, DOHC



86.0 x 86.0 (3.39 x 3.39)



2997 (182.9)



10.5 : 1
8.5 : 1

SFI



96



168 / 6000 (225@6000)
239 / 5600 (320@5600)

298 / 4000 (220@4000)
427 / 4000 (315@4000)

12 ± 55
12 ± 52

960
1080

1.4



Ð Ð Dry, Single Plate

A340E
V160

2.804
3.827

1.531
2.360

1.000
1.685

0.705
1.312

Ð Ð 1.000

Ð Ð 0.793

2.393
3.280

4.083
3.133

205 (8.07)
222 (8.74)

Ventilated Disc



Ventilated Disc



Dual-Servo



Tandem 8º + 9º



P & B Valve



Double Wishbone



Double Wishbone



STD



STD



Rack & Pinion



17.5 : 1



Integral Type



*: Unladen Vehicle

CAMRY ± OUTLINE OF NEW FEATURES
CAMRY
26
OUTLINE OF NEW FEATURES
The Camry is a high-quality family sedan with advanced technology and sporty performance. The following
changes are made for the 1999 model year.
1. Model Line-Up
The following models have been added.
SXV20L-AEMDKK, SXV20L-AEPDKK
MCV20L-CEMNKA, MCV20L-AEPDKK
The following models have been discontinued.
SXV20L-CEMDKK, SXV20L-CEPDKK, SXV20L-CEMNKK, SXV20L-CEPNKK
MCV20L-CEMDKA, MCV20L-CEPDKK, MCV20L-CEPGKK
2. Engine
ORVR (On-board Refueling Vapor Recovery) system has been adopted on the 1MZ-FE engine models.
The basic construction and operation of this system are the same as in the '98 Camry with 5S-FE Engine.
The direction of the rotation of the radiator cooling fan of the 1MZ-FE engine models has been reversed.
A service port has been provided for inspecting the evaporative emission control system on all models.
For details, see the General 1999 Features section.
3. Axles
The rear axle bearing specifications have been partially changed.
4. Brakes
The brake specifications have been partially changed.
5. Body
The attachment method for the front bumper reinforcement has been changed.
The center pillar garnish extends into the vehicle's interior to provide its effectiveness in absorbing the
energy in case the occupant's head collides against the pillar.
A reinforcement has been added to the rocker panel to effectively dissipate the impact energy during a
frontal collision, thus minimizing the deformation of the cabin.
The front, center and rear pillar garnishes provide an impact-absorbing structure consisting of internal ribs
that dampen the impact.
6. Seat
A seat fabric has been changed on the CE grade models to improve the seat appearance.
7. Seat Belt
The shape of the tongue plate has been changed to help improve the usability of the seat belt.

Toyota Supports ASE CertificationPage 1 of 2
PG032±99
Title:
YEAR 2000 READINESS DISCLOSURE
Models:
All Models
Technical Service
BULLETIN
December 24, 1999

Based upon information we have obtained from our suppliers,
1
all factory±installed
systems in Toyota cars, sports utility vehicles and trucks distributed and/or sold by Toyota
(ªVehiclesº)
2 will not be affected by the change of date from 1999 to the year 2000.
Toyota anticipates no problems with past, current or future Toyota brand vehicles or
Genuine Toyota parts and accessories regarding year 2000 readiness. We hope the
following information is helpful to you.
Please contact our Customer Service Department at 1±800±331±4331 should you have
any other questions.
All Models
WARRANTY STATEMENT WITH RESPECT TO TOYOTA BRAND VEHICLES
Toyota is pleased to confirm that the manufacturer's limited express warranty and
Toyota's powertrain warranty warrant that all factory±installed systems in new Vehicles
and Toyota Certified Used Vehicles shall be free of any defect arising solely due to a
change in date from the year 1999 to the year 2000.
3
With respect to Vehicles no longer covered under such Toyota limited express warranty,
Toyota is not aware of any operational safety or functional impact the year 2000 date
change would have upon any factory±installed system in Toyota Vehicles. Should Toyota
become aware of any material impact to the operational safety or functionality of such
systems, Toyota shall publish such information promptly.
WARRANTY STATEMENT WITH RESPECT TO GENUINE TOYOTA PARTS AND
ACCESSORIES
Toyota is pleased to confirm that the manufacturer's limited express warranty warrants
that all new Toyota Genuine Parts and Accessories shall be free of any defect arising
solely due to a change in date from the year 1999 to the year 2000.
3
With respect to products no longer covered under a Toyota limited express warranty,
Toyota is not aware of any operational safety or functional impact the year 2000 date
change would have upon such products. Should Toyota become aware of any material
impact to the operational safety or functionality of such a product, Toyota shall publish
such information promptly.
1 Toyota relies on the statements made by its suppliers and has not independently verified such information.2 Vehicles includes alternative fuel vehicles.3 Please refer to terms of limited express warranty for disclaimers, limitations and restrictions.
PRODUCT GENERAL INFORMATION
Introduction
Applicable
Vehicles
Warranty
