park assist TOYOTA CAMRY 2013 XV50 / 9.G Owners Manual

When driving2
133
2-1. Driving proceduresDriving the vehicle............ 134
Engine (ignition) switch (vehicles without a
smart key system).......... 145
Engine (ignition) switch (vehicles with a smart
key system).................... 148
Automatic transmission (vehicles without paddle
shift switches) ................ 155
Automatic transmission (vehicles with paddle
shift switches) ................ 159
Turn signal lever .............. 166
Parking brake ................... 168
Horn ................................. 169
2-2. Instrument cluster Gauges and meters ......... 170
Indicators and warning lights .............................. 180
2-3. Operating the lights and wipers
Headlight switch ............... 186
Fog light switch ................ 193
Windshield wipers and washer ........................... 195 2-4. Using other driving
systems
Cruise control ................... 200
Driving assist systems ..... 204
BSM (Blind Spot Monitor) ....... 209
2-5. Driving information Cargo and luggage .......... 219
Vehicle load limits ............ 223
Winter driving tips ............ 224
Trailer towing ................... 228
Dinghy towing .................. 229

143
2-1. Driving procedures
2
When driving
CAUTION
■
When braking
●When the brakes are wet, drive more cautiously.
Braking distance increases when the brakes are wet, and this may cause
one side of the vehicle to brake differently than the other side. Also the
parking brake may not securely hold the vehicle.
● If the power brake assist function does not operate, do not follow other
vehicles closely and avoid hills or sharp turns that require braking.
In this case, braking is still possible, but the brake pedal should be
depressed more firmly than usual. Also, the braking distance will increase.
● Do not pump the brake pedal if the engine stalls.
Each push on the brake pedal uses up the reserve for the power-assisted
brakes.
● The brake system consists of 2 individual hydraulic systems; if one of the
systems fails, the other will still operate. In this case, the brake pedal
should be depressed more firmly than usual and the braking distance will
increase.
If this happens, do not continue to drive the vehicle. Have your brakes
fixed immediately.
NOTICE
■When driving the vehicle
●Do not depress the accelerator and brake pedals at the same time during
driving, as this may restrain driving torque.
● Do not use the accelerator pedal or depress the accelerator and brake
pedals at the same time to hold the vehicle on a hill.
■ When parking the vehicle
Always shift the shift lever to P. Failure to do so may cause the vehicle to
move or the vehicle may accelerate suddenly if the accelerator pedal is acci-
dentally depressed.

527
Alphabetical index
Back-up lights
Replacing light bulbs ............ 408
Wattage ................................ 483
Battery Checking .............................. 372
If the vehicle has
discharged battery ............. 460
Preparing and checking
before winter ...................... 224
Blind Spot Monitor .................. 209
Bottle holders .......................... 300
Brake Fluid...................................... 371
Parking brake ....................... 168
Brake assist ............................. 204
Break-in tips ............................ 135
BSM .......................................... 209 Care
Exterior ..................................342
Interior ...................................345
Seat belts ..............................346
Cargo capacity .........................219
Cargo net ..................................322
CD player ..................................256
Chains .......................................224
Child-protectors .........................54
Child restraint system Booster seats, definition ........119
Booster seats, installation .....123
Convertible seats, definition .............................119
Convertible seats, installation ...........................123
Front passenger occupant
classification system ........... 113
Infant seats, definition ...........119
Infant seats, installation.........123
Installing CRS with LATCH anchors ...............................124
Installing CRS with
seat belts ............................126
Installing CRS with top tether straps ........................129BC
