853-1. Basic operation
3
Navigation system
CAMRY_CAMRY HV(TMMK)_Navi_(U)
*: This function is not available in some countries or areas.
1 Press the “MENU” button.
2 Select “Info”.
3 Select “Traffic Incidents”.
When the route has not been
set
Select to display traffic infor-
mation for the current road.
( P. 8 6 ) Select to display nearby traf-
fic information. (
P.86)
Select to display a map with
predictive traffic data.
( P.86)
Select to display traffic along
the saved routes. ( P.86)
When the route has been set
Select to display traffic infor-
mation for the set route.
( P.86)
Select to display nearby traf-
fic information. ( P.86)
Select to display a map with
predictive traffic data.
( P.86)
Select to display traffic along
the saved routes. ( P.86)
●If a large amount of information is
being received, it may take longer
than normal for th e information to
be displayed on the screen.
●If traffic information cannot be
received because the vehicle is
outside of HD Radio coverage
area, it may still be able to be
received using DCM. ( P.184)
Tr af fic infor mation*
Traffic data can be received
via HD RadioTM broadcast
or via DCM (Data Communi-
cation Module) to display
traffic information on the
map screen.
Displaying the traffic
screen
A
B
C
D
A
B
C
D

873-1. Basic operation
3
Navigation system
CAMRY_CAMRY HV(TMMK)_Navi_(U)“Options”: Select to add, edit or
delete personal traffic routes.
(
 P. 1 1 7 )
 If routes have not been regis-
tered yet, a confirmation
screen will be displayed.
Select “Yes” to register the
route.
4 Select the desired traffic
information.
5 Check that the traffic informa-
tion is displayed.
“Detail”: Select to display detailed
traffic information.
1 Select on the map
screen. ( P.76)
2 Select “Traffic Information”.
3 Check that the traffic informa-
tion is displayed.
●The icons indicate traffic incidents
such as construction, accidents,
etc. Select an ic on to hear more
detail by voice.
●The arrows indic ate the flow of
traffic. The color changes depend-
ing on the speed.
Displaying traffic informa-
tion on the map

883-2. Destination search
CAMRY_CAMRY HV(TMMK)_Navi_(U)
3-2.Destination search
The destination screen enables
to search for a destination. The
destination screen can be
reached by the following meth-
ods:
■From the map screen
1 Press the “MAP” button.
2 Select .
3 Follow the steps in “From the
menu screen” from step 3.
( P. 8 8 )
■From the menu screen
1 Press the “MENU” button.
2 Select “Destination”.
3 Select the desired search
method.
Select to set a destination by home. (
P.89)
Select to search for a desti-
nation by entering keywords.
( P.89)
Select to search for a desti-
nation via the Toyota
response center.
* (  P.298)
Select to search for a desti-
nation from a registered entry
in “Favorites”. ( P. 9 0 )
Select to search for a desti-
nation from recent set desti-
nations. ( P. 9 0 )
Select to search for a desti-
nation from emergency ser-
vice points. ( P.91)
Select to search for a desti-
nation by address. ( P. 9 1 )
Select to search for a desti-
nation by point of interest.
( P.92)
Select to search for a desti-
nation from contact data
which had been transferred
to the navigation system from
a registered Bluetooth
®
phone. ( P.91)
*: This function is not available in
some countries or areas.
●To hide the destination screen,
touch any part of the map screen.
Destination search
operation
Destination screen
A
B
C
D
E
F
G
H
I

893-2. Destination search
3
Navigation system
CAMRY_CAMRY HV(TMMK)_Navi_(U)
The selected state (province)
can be changed to set a desti-
nation from a different state
(province) by using “Address” or
“Point of Interest”.
1Display the destination
screen. ( P.88)
2 Select “Address” or “Point of
Interest”.
3 Select “Change State/Prov-
ince”.
4 Select the desired state
(province).
 To change countries, select
“Change Country”.
To use this function, it is neces-
sary to register a home address.
( P.108)
1 Display the destination
screen. ( P.88)
2 Select “Home”.
 The navigation system per-
forms a search for the route
and the route overview is dis- played. (
P.97)
The destination can be
searched by entering various
keywords.
1 Display the destination
screen. ( P. 8 8 )
2 Select “Search”.
3 Enter characters on the key-
board.
4 Select “Search”.
5 When there is more than 1
result, select the desired item
from the list.
: Select to display updated infor-
mation about the selected entry.
This function is displayed only
when there is information from the
Cloud.
●To search for a facility name using
multiple search words, put a
space between each word.
●Search results may differ depend-
ing on the connected services
subscription status and communi-
cation status.
Selecting search area
Setting home as destina-
tion
Searching by keyword

913-2. Destination search
3
Navigation system
CAMRY_CAMRY HV(TMMK)_Navi_(U)
1Display the destination
screen. ( P.88)
2 Select “Emergency”.
3 Select the desired emer-
gency category.
4 Select the desired destina-
tion.
●The navigation system does not
guide in areas where route guid-
ance is unavailable. ( P.122)
To use this function, it is neces-
sary to have contact data which
had been transferred to the nav-
igation system from a registered
Bluetooth
® phone. ( P.256)
1 Display the destination
screen. ( P.88)
2 Select “Contacts”. 3
Select the desired contact.
4 Select “Addresses”.
5 Select the desired address.
6 Follow the steps in “Search-
ing by keyword” from step 4.
( P.89)
●This function may not be available
depending on the type of Blue-
tooth
® phone.
1Display the destination
screen. ( P. 8 8 )
2 Select “Address”.
 If a state (province) has not
been selected yet,
“State/Province” screen is dis-
played. ( P.89)
3 Enter a house number and
select “Search”.
Searching by emergency
Searching by contact
Searching by address

933-2. Destination search
3
Navigation system
CAMRY_CAMRY HV(TMMK)_Navi_(U)
POI.
●To search for a facility name using
multiple search words, put a
space between each word.
1 Select “Sort/Category/City”.
2 Select “Enter a city name”.
3 Enter a city name and select
“Search”.
“Any City”: Select to cancel the city
setting.
4Select the desired city name.
5 Select the desired POI.
1 Select “Sort/Category/City”.
2 Select “Change POI cate-
gory”.
3 Select the desired category.
 If there is more than 1 result
for the selected category, a
detailed list will be displayed.
“List All Categories”: Select to dis-
play all POI categories.
4 Select the desired POI. 1
Select “Category”.
2 Select the desired search
point.
Select to search for POIs
near your current position.
Select to search for POIs
along the set route.
Select to search for POIs
near a specific city center.
( P.94)
Select to search for POIs
near a destination.
When more than 1 destina-
tion has been set, a list will
be displayed on the screen.
Select the desired destina-
tion.
3 Select the desired POI cate-
gory.
 Select “Other POIs” to select
other than default POI catego-
ries. The following button can
be displayed.
“List All Categories”: Select to dis-
play all POI categories.
“Favorite POI Categories”: Select to
use the 6 POIs that have been pre-
viously set. ( P.115)
4 Select the desired POI.
Selecting a city to search
Selecting from the catego-
ries
Searching by category
A
B
C
D

943-2. Destination search
CAMRY_CAMRY HV(TMMK)_Navi_(U)
●The names of POIs located within
approximately 200 miles (320 km)
from the selected search point can
be displayed. They are displayed
up to 200 names.
1Select “Near a City Center in
XX
*”.
2 Enter a city name and select
“Search”.
“Last 5 Cities”: Se lect the desired
city name from the list of the last 5
cities.
3 Select the desired city name.
4 Select “OK” when the city
center map screen is dis-
played.
5 Follow the steps in “Search-
ing by category” from step 3.
( P. 9 3 )
*: XX represents the selected
search area name.
●If the navigation system has never
been used, selecting the city
name from “Last 5 Cities” will not
be available.
1 Select “Phone #”.
2 Enter a phone number and
select “OK”.
 If multiple locations with the
same phone number exist,
the list screen will be dis-
played.
●If there is no match for the entered
phone number, a list of identical
numbers with different area codes
will be displayed.
To use this function, it is neces-
sary to register a home and/or a
favorite location. Up to 2 favor-
ites can be registered as preset
destinations. ( P.108, 109)
To set the home or a preset des-
tination as the destination,
select the corresponding button.
Vehicles without a smart key
system
1 Turn the engine switch to the
“ACC” or “ON” position.
Vehicles with a smart key sys-
tem
1 Turn the engine
switch to ACCESSORY or
IGNITION ON mode.
2 Press the “MAP” button.
When “Near a City Center in
XX
*” is selected
Searching by phone num-
ber
One-touch setting
home/favorite as a desti-
nation

953-2. Destination search
3
Navigation system
CAMRY_CAMRY HV(TMMK)_Navi_(U)
3Select the desired item.
Select to set the registered
home as the destination.
Select to set a registered
favorite as the destination.
(Up to 2 favorites can be reg-
istered as preset destina-
tions.)
 The estimated time of arrival
to the registered home and
preset destinations from the
current position will be dis-
played.
 If the home or a preset desti-
nation has not been regis-
tered, “Save Home” or “Save
Favorite” will be displayed,
respectively. To register a
home or preset destination,
select the corresponding but-
ton.
●When the destination is very close
to the current position, “Nearby”
will be displayed.
●The one-touch buttons for home
and favorites will disappear after
the vehicle has been driven for a
while.
●The color of the estimated arrival
time indicator may change
depending on the traffic informa-
tion received.
●This function is available when
“Automatic Destination List Info” is
set to on. ( P. 1 1 3 )
A
B

973-2. Destination search
3
Navigation system
CAMRY_CAMRY HV(TMMK)_Navi_(U)
Select to search for the route.
(P. 9 6 )
• If a destination has already been
set, “Go Directl y” and “Add to
Route” will be displayed.
“Go Directly”: Select to delete the
existing destination(s) and set a
new one.
“Add to Route”: Select to add a
destination to the current route.
Select to register as a mem-
ory point.
Select to call the registered
number.
Select to update information
about the selected entry.*
*: This function is displayed only when there is information from
the Cloud. ( P. 8 9 )
Current position
Destination point
Select to display a list of the
turns required to reach the
destination. ( P. 9 8 )
Select to change the route.
( P.99)
Select the desired route from
3 possible routes. ( P.98)
Type of route and its distance
Distance of the entire route
Select to start guidance.
Select and hold to start demo
mode. ( P.98)
Displayed when the route
displayed is from the Cloud.
( P.99)
Confirm destination
screen
A
B
C
D
5RXWHRYHUYLHZVF\
UHHQ
A
B
C
D
E
F
G
H
I

993-2. Destination search
3
Navigation system
CAMRY_CAMRY HV(TMMK)_Navi_(U)
Distance to the next turn
Turn direction at the intersec-
tion
Select to display the map of
the selected point.
●Not all road names on the route
may appear on the list. If a road
changes its name without requir-
ing a turn (such as on a street that
runs through 2 or more cities), the
name change will not appear on
the list. The street names will be
displayed in order from the start-
ing point, along wit h the distance
to the next turn or the destination.
Destinations can be added,
reordered or deleted, and condi-
tions for the route to the destina-
tion can be changed.
1 Select “Edit Route”.
2 Select the desired item.
Select to add destinations.
( P. 9 9 )
Select to delete destinations.
( P. 9 9 )
Select to reorder destina-
tions. ( P.105)
Select to set route prefer-
ences. ( P.106) 1
Select “Add”.
2 Search for an additional des-
tination in the same way as a
destination search. ( P.88)
 Up to 5 destinations can be
set.
3 Select “Add” at the position in
the route which you want to
add the destination.
1 Select “Delete”.
2 Select “Yes” when the confir-
mation screen appears.
 If more than 1 destination has
been set, select the destina-
tion(s) to be deleted. (The
navigation system will recal-
culate route(s) to the remain-
ing set destination(s).)
*: This function is not available in
some countries or areas.
When starting route guidance or
rerouting, a route can be pro-
vided automatically by the
Cloud. This function is available
when dynamic route setting is
enabled. ( P. 1 1 3 )
Editing route
B
C
D
A
B
C
D
$GGLQJGHVWLQDWLRQV
'HOHWLQJGHVWLQDWLRQV
$URXWHIURPWK\
H&ORXG
