2714-5. Using the driving support systems
4
Driving
WARNING
●Light from the headlights of an oncoming vehicle, the sun, etc. enters the
camera.
●The vehicle is driven on a slope.
●<0037004b0048000300590048004b004c0046004f00480003004c0056000300470055004c00590048005100030052005100030044000300550052004400470003005a004b004c0046004b00030057004c004f005700560003004f0048004900570003005200
5500030055004c004a004b0057000f00030052005500030044[ winding road.
●The vehicle is driven on an unpaved or rough road.
●The traffic lane is excessively narrow or wide.
●The vehicle is extremely tilted due to carrying heavy luggage or having
improper tire pressure.
●<0037004b004800030047004c00560057004400510046004800030057005200030057004b00480003005300550048004600480047004c0051004a000300590048004b004c0046004f00480003004c005600030048005b00570055004800500048004f005c00
030056004b0052005500570011[
●The vehicle is moving up and down a large amount due to road conditions
during driving (poor roads or road seams).
●When driving in a tunnel or at night with the headlights off or when a head-
light is dim due to its lens being dirty or it being misaligned.
●The vehicle is struck by a crosswind.
●The vehicle is affected by wind from a vehicle driven in a nearby lane.
●<0037004b0048000300590048004b004c0046004f00480003004b004400560003004d00580056005700030046004b00440051004a004800470003004f0044005100480056000300520055000300460055005200560056004800470003004400510003004c00
510057004800550056004800460057004c005200510011[
●Tires which differ by structure, manufacturer, brand or tread pattern are
used.
●When tires of a size other than specified are installed.
●Snow tires, etc. are equipped.
●<0037004b0048000300590048004b004c0046004f00480003004c0056000300450048004c0051004a000300470055004c00590048005100030044005700030048005b00570055004800500048004f005c0003004b004c004a004b0003005600530048004800
4700560011[

5157-2. Steps to take in an emergency
7
When trouble arises
When replacing tires on a vehicle with wheel lock nuts, use the follow-
ing procedures to remove and install the wheel lock nuts. The wheel
lock key is stored in the tray inside the luggage compartment. Always
return the wheel lock key to its original position after use, so that it
does not get lost. (P. 513)
■Removal
For ease of removal, the wheel lock nut should always be the first
one loosened.
Place the wheel lock key on top of the wheel lock nut, turning
until the wheel lock key and wheel lock nut patterns engage.
Place the wheel nut wrench on the wheel lock key, and while
applying pressure on the wheel lock key, loosen the wheel lock
nut.
■Installation
For ease of installation, the wheel lock nut should always be the
last one tightened.
By hand, install a wheel lock nut on the wheel to be installed.
Place the wheel lock key on top of the wheel lock nut, turning
until the wheel lock key and wheel lock nut patterns engage.
Place the wheel nut wrench on the wheel lock key, and while
applying pressure on the wheel lock key, tighten the wheel lock
nut to the recommended torque.
Wheel lock nut (if equipped)
NOTICE
■When using a wheel lock key
Do not use an impact wrench. Using an impact wrench may cause perma-
nent damage to wheel lock nut and wheel lock key. If in doubt about wheel
lock application, contact your Toyota dealer.
1
2
1
2
3
