navigation system TOYOTA CAMRY HYBRID 2022 Owners Manual

5
1
9 7 6
5
4
3
2
8
7-1. Essential information
Emergency flashers .......... 490
If your vehicle has
to be stopped in
an emergency ................. 491
If the vehicle is submerged
or water on the road is
rising ............................... 492
7-2. Steps to take in
an emergency
If your vehicle needs
to be towed ..................... 493
If you think something
is wrong........................... 496
If a warning light turns
on or a warning
buzzer sounds................. 497
If a warning message
is displayed ..................... 507
If you have a flat tire .......... 513
If the hybrid system will
not start ........................... 525
If the electronic key
does not operate
properly ........................... 527
If the 12-volt battery
is discharged ................... 530
If your vehicle
overheats ........................ 537
If the vehicle becomes
stuck................................ 5418-1. Specifications
Maintenance data
(fuel, oil level, etc.) .......... 544
Fuel information ................. 553
Tire information.................. 556
8-2. Customization
Customizable features ....... 569
8-3. Items to initialize
Items to initialize ................ 577
Reporting safety defects for
U.S. owners ............................. 580
Reporting safety defects for
Canadian owners ..................... 581
Seat belt instructions for
Canadian owners
(in French)................................ 582
SRS airbag instructions for
Canadian owners
(in French)................................ 583
What to do if...
(Troubleshooting) ..................... 594
Alphabetical index ...................... 597
7When trouble arises8Vehicle specifications
9For owners
Index
For information regarding the equipment listed below, refer to “NAV-
IGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
• Navigation system
• Audio system
• Rear view monitor system• Toyota parking assist monitor
• Panoramic view monitor
• Connected Services

17Pictorial index
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 222
Headlight switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 230
Headlights/side marker lights/parking lights/tail lights/
license plate lights/daytime running lights . . . . . . . . . . . . . . . . P. 230
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . P. 238
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 238
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 439
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . P. 490
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 429
Tilt and telescopic steering lock release lever . . . . . . . . . . P. 177
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 366
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 366
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 370
Audio
*1, 2
Audio Plus*1, 2
Premium Audio*1, 2
Clock*2
4
5
6
7
8
9
10
*1: If equipped
*2: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

19Pictorial index
Meter control switches . . . . . . . . . . . . . . . . . . . . . . . . . P. 105, 119
Paddle shift switches
*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 216
Vehicle-to-vehicle distance switch . . . . . . . . . . . . . . . . . . . . P. 294
Cruise control switches
Dynamic radar cruise control with full-speed range . . . . . . . . . P. 287
Audio remote control switches
*2
LTA (Lane Tracing Assist) switch . . . . . . . . . . . . . . . . . . . . . P. 267
Phone switch
*2
Talk switch*2
1
2
3
4
5
6
7
8
*1: If equipped
*2: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

1042. Instrument cluster
The multi-information display presents the driver with a variety of driv-
ing-related data, such as the current outside temperature. The multi-
information display can also be used to change the display settings
and other settings.
Shift position (P. 2 1 6 )
Menu icon display area
Displays the following items.
When a menu icon is not selected, the outside temperature and clock are
displayed.
• Menu icons (P. 106)
• Outside temperature (P. 100)
• Clock
*
*
: For clock settings, refer to “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
Content display area
A variety of information can be displayed by selecting a menu icon. Addi-
tionally, warning or suggestion/advice pop-up displays will be displayed in
some situations.
• Menu icon content (P. 1 0 6 )
• Suggestion function (P. 114)
• Warning message (P. 507)
Odometer/trip meter (P. 114)
Indicators (P. 94)
Multi-infor mation display (4.2-inch display)
Summary of functions
1
2
3
4
5

1172. Instrument cluster
2
Instrument cluster
The multi-information display presents the driver with a variety of driv-
ing-related data, such as the current outside temperature. The multi-
information display can also be used to change the display settings
and other settings.
Indicators (P. 94)
Driving assist system status display area
Displays the operational status of the following systems:
• Dynamic radar cruise control with full-speed range (P. 287)
• LTA (Lane Tracing Assist) (P. 267)
Speed limit display (vehicles with a navigation system)
(U.S.A. only)/RSA (Road Sign Assist) (if equipped) (P. 282)
Clock
For clock settings, refer to “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
RSA (Road Sign Assist) (if equipped) (P. 282)
Speedometer
The speedometer display can be enabled/disabled in on the multi-
information display. (P. 126)
Multi-infor mation display (7-inch display)
Summary of functions
1
2
3
4
5
6

1202. Instrument cluster
Select a menu icon to display its content.
Warning message display (P. 507)
This menu icon will be displayed only when a warning message can be
displayed.
Select to display warning messages and measures to be taken if a mal-
function is detected.
Eco-friendly driving information (P. 121)
Select to display fuel consumption data in various forms.
Driving assist system information
Select to perform the following:
Display the operational status of the following systems:
• Dynamic radar cruise control with full-speed range (P. 287)
• LTA (Lane Tracing Assist) (P. 267)
• RSA (Road Sign Assist) (if equipped) (P. 282)
Display the following navigation system-linked information (if equipped):
• Route guidance
• Compass display
Audio system-linked display
Select to enable selection of an audio source or track on the meter
using the meter control switches.
Vehicle information
Select to perform the following:
Display the following information:
• Energy monitor (P. 142)
• Tire inflation pressure (P. 445)
Enable/Disable the following systems:
• Intuitive parking assist (if equipped) (P. 317)
• BSM (Blind Spot Monitor) function (P. 310)
• RCTA (Rear Cross Traffic Alert) function (P. 326)
This function can also be enabled/disabled on .
Settings display (P. 126)
Select to change the meter display settings and other settings.
Menu icons

1292. Instrument cluster
2
Instrument cluster
Press and hold to change the settings of the following item:
■ HUD (Head-up display) (if equipped) (P. 136)
Press to enable/disable the head-up display.
Press and hold to change the settings of the following items:
ItemSettingsDetails
Vol u me1 (Low)
Select to change the volume of
the intuitive parking assist
buzzer. 2 (Medium)
3 (Loud)
ItemSettingsDetails
HUDOn
Select to enable/disable the
head-up display.
Off
ItemSettingsDetails
HUD Brightness/PositionSelect to adjust the brightness/
position of the head-up display.
• Press the / switch to
adjust the display brightness.
• Press the / switch to
adjust the display position.
HUD Driving sup-
port
Tachometer set-
tings
Select to change the display
between the following:
• Hybrid System Indicator
• Tachometer
• No content
Navigation sys-
tem (if equipped)
Select to enable/disable head-up
display content.Driving Assist
Compass
(if equipped)
RotationSelect to adjust the angle of the
head-up display.
Press the / switch to
adjust the display angle.

1362. Instrument cluster
The head-up display is linked to the meters and navigation system (if
equipped) and projects a variety of information in front of the driver,
such as the current vehicle speed.
Driving assist system status/navigation system-linked display area
(if equipped) (P. 138)
The following pop-up displays will be displayed in certain situations:
• Pre-collision warning (pre-collision system)
• Alert from the Parking Support Brake system (if equipped)
Shift position/speed limit/RSA (Road Sign Assist) display area
• Shift position (P. 216)
• Speed limit (vehicles with a navigation system) (U.S.A. only)
• RSA (Road Sign Assist) display (if equipped) (P. 282)
Vehicle speed display
Hybrid System Indicator/Tachometer (P. 1 3 8 )
Information display area (P. 139)
The following pop-up displays will be displayed in certain situations:
• Warning/message
• Hands-free system status
• Audio system operation status
Head-up display
: If equipped
Summary of functions
1
2
3
4
5

1382. Instrument cluster
◆Driving assist system status display
Displays the operational status of the following systems:
• Dynamic radar cruise control with full-speed range (P. 287)
• LTA (Lane Tracing Assist) (P. 2 6 7 )
• RSA (Road Sign Assist) (if equipped) (P. 282)
• Intuitive parking assist (if equipped) (P. 317)
◆Navigation system-linked display area (if equipped)
Displays the following items, which are linked to the navigation sys-
tem:
■Street name
When the navigation system is performing route guidance, the
name of the next street will be displayed on the top of the display
area.
■Route guidance to destination
Displayed when the navigation system is performing route guid-
ance. When approaching an intersection, an arrow will be displayed
to indicate the suggested direction of travel.
■Compass
Displays the direction of travel.
■Hybrid System Indicator
Charge area
Hybrid Eco area
Eco area
Power area
Displayed content is the same
as that displayed on the meter
(Hybrid System Indicator). For
details, refer to P. 102.
■
Tachometer
Displays the engine speed in revolutions per minute.
Driving assist system status/navigation system-linked display
area (if equipped)
Hybrid System Indicator/Tachometer
1
2
3
4

1402. Instrument cluster
■Head-up display
The head-up display may seem dark or hard to see when viewed through
sunglasses, especially polarized sunglasses.
Adjust the brightness of the head-up display or remove your sunglasses.
■Display brightness
The brightness of the head-up display can be adjusted on of the multi-
information display. Also, it is automatically adjusted according to the ambient
brightness.
■Enabling/disabling of the head-up display
If the head-up display is disabled, it will remain disabled when the power
switch is turned off then back to ON mode.
■Street name display (vehicles with a navigation system)
Only street names which are included in the map data will be displayed.
WARNING
■Before using the head-up display
●Check that the position and brightness of the head-up display image does
not interfere with safe driving. Incorrect adjustment of the image’s position
or brightness may obstruct the driver’s view and lead to an accident,
resulting in death or serious injury.
●Do not continuously look at the head-up display while driving as you may
<00490044004c004f000300570052000300560048004800030053004800470048005600570055004c004400510056000f000300520045004d004800460057005600030052005100030057004b004800030055005200440047000f0003004800570046001100
030044004b00480044004700030052004900030057004b0048[ vehicle.
■Caution for changing settings of the head-up display
As the hybrid system needs to be operating while changing the settings of
the head-up display, ensure that the vehicle is parked in a place with ade-
quate ventilation. In a closed area such as a garage, exhaust gases includ-
ing harmful carbon monoxide (CO) may collect and enter the vehicle. This
may lead to death or a serious health hazard.
