display TOYOTA COROLLA 2009 10.G Navigation Manual

COROLLA_Navi_U(L/O 0801)
5
Table of Contents
Quick guide —
— Overview buttons and guidance screen 10. . . . . . . . . . .
— Registering home 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
— Registering preset memory points (Quick access) 14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
— Operation flow: guiding the route 16 . . . . . . . . . . . . . . . . .
— Setting home as the destination 17 . . . . . . . . . . . . . . . . . .
Navigation system function index 18 . . . . . . . . . . . . . . . . . . .
1 Basic Functions 〈Basic information before operation〉
Display operation 22
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Initial screen 23
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
Touch screen operation 25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Inputting letters and numbers/List screen operation 26
. . . . . . . . . . . . .
Function help 29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Map screen operation 30
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Current position display 30
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen scroll operation 30
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switching the screens 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map scale 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Foot print map 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Orientation of the map 39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2009 COROLLA Navigation from Aug. ’08 Prod. (OM12B17U)
Quick
Guide
1
2
3
4
5
6
7
Index

COROLLA_Navi_U(L/O 0801)
6
2 Destination Search
Quick reference (“Destination” screen)42
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search 43
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Selecting the region to search 44
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by Home 46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by Quick access 46
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Address” 47
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “POI
∗”5 1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Phone #” 58
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Emergency” 59
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Memory” 59
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Previous” 60
. . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Map” 61
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Intersection” 61
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Freeway Ent./Exit” 62
. . . . . . . . . . . . . . . . . . .
Destination search by “Coordinates” 63
. . . . . . . . . . . . . . . . . . . . . . . .
Deleting set destinations 64
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting route guidance 65
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
3 Route Guidance
Route guidance screen 70
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Typical voice guidance prompts 73
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Distance and time to destination 75
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting and deleting destination 76
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding destinations 76
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Reordering destinations 76
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting destinations 77
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Setting route 78
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Search condition 78
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Detour setting 79
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Route preference 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Starting route from adjacent road 81
. . . . . . . . . . . . . . . . . . . . . . . . . .
Map view 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Display POI
∗ icons 82
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Route overview 84
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Route preview 85
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Route trace 86
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
∗: Point of Interest
2009 COROLLA Navigation from Aug. ’08 Prod. (OM12B17U)

10
0U5111aX
No.NameFunctionPage
1
Northup or
headingup
symbolThis symbol indicates a map view with
northup or headingup. Touching this
symbol changes the map orientation.
39
2Scale indicatorThis figure indicates the map scale.37
3“MAP/VOICE”
buttonPush this button to repeat a voice guid-
ance, cancel one touch scroll, start
guidance, and display the current posi-
tion.
30, 74
4“DEST” buttonPush this button to display the “Destina-
tion” screen.12, 14, 16, 17, 42, 43
5“MENU” buttonPush this button to display the “Menu”
screen.90, 92, 93, 94,96, 110, 191
6“DISP/TILT”
buttonPush this button to display the “Display”
screen.22, 137
COROLLA_Navi_U(L/O 0801)
2009 COROLLA Navigation from Aug. ’08 Prod. (OM12B17U)
Quick guide —
— Overview buttons and guidance screen

11
No.NameFunctionPage
7“INFO” buttonPush this button to display the “Informa-
tion” screen.128, 132, 138, 141
8Zoom out buttonTouch this button to reduce the map
scale.37
9“Mark”
Touch this button to register the current
position or the cursor position as a
memory point.
31
10“Route”Touch this button to change the route.76, 78
11“Map View”
Touch this button to browse information
about guidance route, to set the Points
of Interest to be displayed on the
screen, or to record the route.
82, 84, 85, 86
12“ OFF”
Touch this button to obtain a broader
view. Some of the buttons on the screen
are not displayed. They are displayed
again by touching “ON ”.
11 4
13Zoom in buttonTouch this button to magnify the map
scale.37
14Foot print map
buttonTouch this button to display the foot print
map and the building information.37
15
Screen
configuration
buttonTouch this button to change the screen
mode.34
16Distance and time
to destinationDisplays the distance, the estimated
travel time to the destination, and the
estimated arrival time at the destination.
75
17XM NavTraffic
markThis mark is displayed when XM Nav-
Traffic information is received.120
18
“GPS” mark
(Global
Positioning
System)Whenever the vehicle is receiving sig-
nals from the GPS, this mark is dis-
played.
178
COROLLA_Navi_U(L/O 0801)
2009 COROLLA Navigation from Aug. ’08 Prod. (OM12B17U)

12
0U5113X
1Push “DEST” button.
2Touch .
If home has not been registered, you can
register it by touching
.
3There are 11 different methods to
search your home.
See “Destination search” on page 43.
4Touch “Enter”.
The “Memory Point” screen is displayed.
COROLLA_Navi_U(L/O 0801)
2009 COROLLA Navigation from Aug. ’08 Prod. (OM12B17U)
— Registering home

14
0U5112X0U5112X
1Push “DEST” button.
2Touch one of the quick access
buttons.
You can set a memory point to one of the
quick access buttons which has not been
set.
3There are 12 different methods to
search preset memory points.
See “Destination search” on page 43.
4Touch “Enter”.
The “Memory Point” screen is displayed.
COROLLA_Navi_U(L/O 0801)
2009 COROLLA Navigation from Aug. ’08 Prod. (OM12B17U)
— Registering preset memory points
(Quick access)

COROLLA_Navi_U(L/O 0801)
18
Map
Displaying mapsPage
Viewing the map screen10
Displaying the current vehicle position30
Viewing the current position vicinity map30
Changing the scale37
Changing the map orientation39
Displaying POIs∗82
Displaying the estimated travel/arrival time to the destination75
Selecting the dual map screen34
Viewing foot print map37
Deleting map screen touch screen buttons11 4
Searching destinationPage
Searching the destination (by home, POI∗, phone #, etc.)43
Changing the selected region44
Operating the map location of the selected destination65
Route guidance
Before starting route guidancePage
Setting the destination65
Viewing alternative routes65
Starting route guidance65
Before starting or during route guidancePage
Viewing the route65
Adding destinations76
Changing the route78
Displaying the estimated travel/arrival time to the destination75
∗: Point(s) of Interest
2009 COROLLA Navigation from Aug. ’08 Prod. (OM12B17U)
Navigation system function index

COROLLA_Navi_U(L/O 0801)
19
During route guidancePage
Suspending route guidance92
Adjusting route guidance volume93
Deleting the destination64, 77
Displaying the entire route map84
Useful functions
Memory pointsPage
Registering your own memory points96
Marking icons on the map96
InformationPage
Displaying vehicle maintenance timing128
Displaying the calendar132
2009 COROLLA Navigation from Aug. ’08 Prod. (OM12B17U)

SECTION 1
BASIC FUNCTIONS
21
BASIC FUNCTIONS
Basic information before operation
Display operation 22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
 Initial screen 23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
 Touch screen operation 25
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Inputting letters and numbers/List screen operation 26
. . . . . . . . .
 Function help 29
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
 Map screen operation 30
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Current position display 30
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen scroll operation 30
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switching the screens 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map scale 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Foot print map 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Orientation of the map 39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
COROLLA_Navi_U(L/O 0801)
2009 COROLLA Navigation from Aug. ’08 Prod. (OM12B17U)

BASIC FUNCTIONS
22
1. Push the “DISP/TILT” button.
2. Touch “TILT”.
INFORMATION
To adjust the screen settings such as
brightness, see “Screen adjustment”
on page 137.
Adjustment of the angle of the display can
be done by touching “TILT”. Each touch
“TILT” will tilt the display to positions
1,2, 3 and then back to 0 in the reverse
order.
Vehicles with smart key system—
If the “ENGINE START STOP” switch is
set at OFF, the display will automatically
move back to position
0. The display will
automatically resume the previous posi-
tion when the engine switch is in ACCES-
SORY or IGNITION ON mode.
Vehicles without smart key system—
If the engine switch is set at OFF, the dis-
play will automatically move back to posi-
tion
0. The display will automatically re-
sume the previous position when the
engine switch is in “ACC” or “ON” position.
COROLLA_Navi_U(L/O 0801)
2009 COROLLA Navigation from Aug. ’08 Prod. (OM12B17U)
Display operation
