Page 391 of 612

3916-1. Using the air conditioning system and defogger
6
Interior features
COROLLA_TMMMS_TMMC_U (OM12F00U)
Close the vent
Sliding the knob to the most
outer position.
Open the vent
■Operation of the air conditioning system in Eco drive mode (if equipped)
In Eco drive mode, the air conditioning system is controlled as follows to pri-
oritize fuel efficiency:
● Engine speed controlled to restrict heating/cooling capacity.
● Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.
● Fan speed restricted when automatic mode is selected
To improve air conditioning performance, perform the following operations:
● Adjust the fan speed.
● Turn off Eco drive mode. ( P. 175)
■ Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed.
1
2
Page 392 of 612

3926-1. Using the air conditioning system and defogger
COROLLA_TMMMS_TMMC_U (OM12F00U)■
Fogging up of the windows
●The windows will easily fog up when the humidity in the vehicle is high.
Turning on will dehumidify the air from the outlets and defog the wind-
shield effectively.
● If you turn off, the windows may fog up more easily.
● The windows may fog up if the recirculated air mode is used.
■ Outside/recirculated air mode
●When driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to recirculated air mode. This is effective in
preventing outside air from entering the vehicle interior. During cooling oper-
ation, setting the recirculated air mode will also cool the vehicle interior
effectively.
● Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.
Page 393 of 612

3936-1. Using the air conditioning system and defogger
6
Interior features
COROLLA_TMMMS_TMMC_U (OM12F00U)■
When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on
●In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.
Vehicles without a smart key system
● Recirculated air mode is selected as a default mode when the engine switch
is turned to the “ON” position.
Vehicles with a smart key system
● Recirculated air mode is selected as a default mode when the engine switch
is turned to IGNITION ON mode.
● It is possible to switch to outside air mode at any time by pressing .
■ When the outside temperature is low
The dehumidification function may not operate even when is pressed.
■ Ventilation and air conditioning odors
●To let fresh air in, set the air conditioning system to the outside air mode.
● During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.
● To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time immediately after the air conditioning system is started in automatic
mode.
■ Air conditioning filter
P. 461
■ Customization that can be co nfigured at Toyota dealer
Settings (e.g. air conditioning setting) can be changed.
(Customizable features P. 570)
Page 394 of 612

3946-1. Using the air conditioning system and defogger
COROLLA_TMMMS_TMMC_U (OM12F00U)
CAUTION
■To prevent the windshield from fogging up
● Do not use during cool air operation in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
■ To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
NOTICE
■To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.
● Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.
Page 395 of 612

395
6
Interior features
COROLLA_TMMMS_TMMC_U (OM12F00U)
6-2. Using the interior lights
Front interior light/personal lights (P. 396)
Rear interior light ( P. 397)
Engine switch light (vehicles with a smart key system)
Interior li ghts list
1
2
3
Page 396 of 612

3966-2. Using the interior lights
COROLLA_TMMMS_TMMC_U (OM12F00U)■
Front interior light
Off
Door position
On
■Personal lights
When a light is on due to its door link switch, the light will not turn off
even if the lens is pressed.
Front interior light/personal lights
Ty p e AType B
1
2
3
Ty p e AType B
On/off On Off
1
2
Page 397 of 612

3976-2. Using the interior lights
6
Interior features
COROLLA_TMMMS_TMMC_U (OM12F00U)
On
Door position
Off
■Illuminated entry system
Vehicles without a smart key system
When the interior light switch is in the door position, the interior light automat-
ically turns on/off according to the engine switch position, whether the doors
are locked/unlocked and whether the doors are open/closed.
Vehicles with a smart key system
When the interior light switch is in the door position, the interior light and
engine switch light automatically turn on/off according to engine switch mode,
the presence of the electronic key, whether the doors are locked/unlocked
and whether the doors are open/closed.
■ To prevent battery discharge
The following lights will go off automatically after 20 minutes:
●Front interior light/personal lights
● Rear interior light
● Trunk light
■ Customization
Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 570)
Rear interior light
1
2
3
Page 398 of 612

398
COROLLA_TMMMS_TMMC_U (OM12F00U)
6-3. Using the storage features
List of storage features
Glove box ( P. 399)
Bottle holders ( P. 400) Console box (
P. 399)
Cup holders ( P. 401)
CAUTION
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
● Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
● Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
■ When driving or when the storag e compartments are not in use
Keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
1
2
3
4
Page 399 of 612

3996-3. Using the storage features
6
Interior features
COROLLA_TMMMS_TMMC_U (OM12F00U)
Pull up the lever to open the glove
box.
Console box
Lift the lid while pulling up the
knob on the right side.
Upper level box
Lift the lid while pulling up the
knob on the left side.
Glove box
Console box
Page 400 of 612

4006-3. Using the storage features
COROLLA_TMMMS_TMMC_U (OM12F00U)■
Front
■Rear
■
When using the holder as a bottle holder
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
Bottle holders
CAUTION
■Items unsuitable for the bottle holder
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
■Items that should not be st owed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottles in the bot-
tle holders, or glass or paper cups containing liquid. The contents may spill
and glass cups may break.
