AT T E N T I O N
■Modification et mise au rebut des éléments du système du coussin
gonflables SRS
Ne mettez pas votre véhicule au rebut et n’effectuez pas les modifications
suivantes sans consulter votre concessionnaire Toyota. Les coussins gon-
flables SRS peuvent être défaillants ou se déployer (se gonfler) accidentel-
lement, provoquant la mort ou de graves blessures.
● Installation, retrait, démontage et réparation des coussins gonflables SRS
● Réparations, modifications, retrait ou remplacement du volant, du tableau
de bord, de la planche de bord, des sièges ou de leur garniture, des mon-
tants avant, latéraux et arrière ou des rails latéraux de toit
● Réparations ou modifications de l’aile avant, du pare-choc avant, ou des
flancs de l’habitacle
● Installation d’un protège-calandre (pare-buffles, pare-kangourou, etc.), de
chasse-neige, de treuils
● Modifications du système de suspension du véhicule
● Installation d’appareils électroniques, tels qu’une radio émetteur/récepteur
et d’un lecteur CD
● Aménagements de votre véhicule pour une personne ayant un handicap
physique

592
COROLLA_TMMMS_TMMC_U (OM12F00U)

593
Index
COROLLA_TMMMS_TMMC_U (OM12F00U)What to do if...
(Troubleshooting) .................... 594
Alphabetical index ..................... 600
Vehicles with a navigation system:
For details of equipment re lated to the navigation sys-
tem, such as the audio system, refer to the “Navigation
System Owner's Manual”.

594
COROLLA_TMMMS_TMMC_U (OM12F00U)
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your keys or mechanical keys, new genuine keys or mechanical
keys can be made by your Toyota dealer. (P. 94)
●If you lose your keys or electronic keys, the risk of vehicle theft increases
significantly. Contact your Toyota dealer immediately. ( P. 96)
●Is the key battery weak or depleted? (P. 463)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( P. 166)
●Vehicles with a smart key system:
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of the radio
wave. ( P. 115)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked

595What to do if... (Troubleshooting)
COROLLA_TMMMS_TMMC_U (OM12F00U)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (P. 101)
●The function to prevent the electronic key from being left inside the trunk
will operate and you can open the trunk as usual. Take the key out from the
trunk. ( P. 108)
The rear door cannot be opened
The trunk lid is closed with the electronic key left inside
(vehicles with a smart key system)

596What to do if... (Troubleshooting)
COROLLA_TMMMS_TMMC_U (OM12F00U)
●Vehicles with a manual transmission:
Do you turn the key with the clutch pedal depressed firmly?
(P. 161)
●Except vehicles with a manual transmission:
Is the shift lever in P? ( P. 161)
●Is the steering wheel unlocked? ( P. 161)
●Is the battery discharged? (P. 531)
●Except vehicles with a manual transmission:
Did you press the engine switch while firmly depressing the brake pedal?
(P. 164)
●Vehicles with a manual transmission:
Did you press the engine switch while firmly depressing the clutch pedal?
(P. 164)
●Except vehicles with a manual transmission:
Is the shift lever in P? ( P. 169)
●Is the electronic key anywhere detectable inside the vehicle?
(P. 112)
●Is the steering wheel unlocked? ( P. 169)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way.
(P. 529)
●Is the battery discharged? ( P. 531)
If you think something is wrong
The engine does not start
(vehicles without a smart key system)
The engine does not start
(vehicles with a smart key system)

597What to do if... (Troubleshooting)
COROLLA_TMMMS_TMMC_U (OM12F00U)
●Vehicles without a smart key system:
Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in the “ON” position. (P. 527)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode. ( P. 527)
●Vehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is pulled from the engine
switch. (P. 162)
●Vehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( P. 169)
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 133)
The shift lever cannot be shifted from P even if you
depress the brake pedal (vehicles with an automatic
transmission or continuously variable transmission)
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or cl ose by operating the power
window switches

598What to do if... (Troubleshooting)
COROLLA_TMMMS_TMMC_U (OM12F00U)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. (P. 168)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( P. 493)
●The brake system warning light is on
Is the parking brake released? (P. 183)
Depending on the situation, other types of warning buzzer may also sound.
( P. 491, 503)
●Is the electronic key left inside the vehicle?
Vehicles with a multi-information display: Check the message on the multi-
information display. ( P. 503)

●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 68)
Vehicles without a smart key system
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.
Vehicles with a smart key system
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine.
●When a warning light turns on, refer to P. 491.
The engine switch is turned off automatically
(vehicles with a smart key system)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)
An alarm is activated and the horn sounds
(vehicles with an alarm)
A warning light turns on
(vehicles with a drive monitor display)

599What to do if... (Troubleshooting)
COROLLA_TMMMS_TMMC_U (OM12F00U)
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 491, 503.
●Stop the vehicle in a safe place and replace the flat tire with the spare tire.
(P. 513)
●Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( P. 540)
A warning light turns on or a warning message or indica-
tor is displayed (vehicles with a multi-information display)
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

600
COROLLA_TMMMS_TMMC_U (OM12F00U)
Alphabetical index
Alphabetical index
A/C .................................... 380, 386Air conditioning filter ............. 461
ABS (Anti-lock Brake System)...... 211 Function ................................ 211
Warning light ......................... 492
Air conditioning filter .............. 461
Air conditioning system ............................ 380, 386 Air conditioning filter ............. 461
Airbags ....................................... 34
Airbag operating conditions .... 41
Airbag precautions for your child .............................. 36
Airbag warning light .............. 492
Correct driving posture ........... 26
Curtain shield airbag operating conditions ............................. 41
Curtain shield airbag precautions ........................... 39
General airbag precautions .... 36
Locations of airbags................ 34
Modification and disposal of airbags ............... 40
Side airbag operating conditions ............................. 41
Side airbag precautions .......... 36
Side and curtain shield airbags
operating conditions ............. 41
Side and curtain shield airbags
precautions ........................... 36
SRS airbags............................ 34
Alarm .......................................... 68
Anchor brackets ........................ 57 Antennas
(smart key system) ............... 111
Anti-lock Brake System (ABS) ...................................... 211 Function ................................ 211
Warning light......................... 492
Assist grips .............................. 406
Audio input ..................... 227, 286
Audio system ........................... 222 Antenna ................................ 231
Audio input............................ 227
AUX port/USB port ..................................... 227
Bluetooth
® audio .................. 255
CD player.............................. 232
iPod ...................................... 241
MP3/WMA disc ..................... 232
Optimal use .......................... 228
Portable music player ........... 227
Radio .................................... 230
Steering wheel audio switch ................................. 226
USB memory ........................ 248
Automatic light control system.................................... 186
Automatic transmission ......... 172 If the shift lever
cannot be shifted from P .... 527
AUX port ........................... 227, 286
