turn signal bulb TOYOTA COROLLA 2018 Owners Manual (in English)

15Pictorial index
COROLLA_TMMMS_TMMC_U (01999-02509)Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . P. 263
To prevent freezing (windshield wiper de-icer)
* . . . . . . . . . . . P. 376
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 204
Refueling method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 204
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 540
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 440
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . P. 546
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 263
Checking/rotation/tire pressure warning system
*. . . . . . . . P. 440
Coping with flat tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 509
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 425
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 425
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 540
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 531
Headlights/daytime running lights
*. . . . . . . . . . . . . . . . . . . P. 193
Front turn signal/parking lights . . . . . . . . . . . . . . . . . . . . . . P. 193
Daytime running lights
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 193
Front side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 193
Turn signal lights
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 191
Stop/tail lights/rear side marker lights . . . . . . . . . . . . . . . . P. 193
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . P. 181, 184, 189
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 193
4
5
6
7
Light bulbs of the exterior lights for driving
(Replacing method: P. 461, Watts: P. 547)
*: If equipped
8
9
10
11
12
13
14
15

1914-2. Driving procedures
4
Driving
COROLLA_TMMMS_TMMC_U (01999-02509)
Right turn
Lane change to the right (move
the lever partway and release
it)
The right hand signals will flash 3
times.
Lane change to the left (move
the lever partway and release
it)
The left hand signals will flash 3
times.
Left turn
■Turn signals can be operated when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
■ If the indicator flashes faster than usual
Check that a light bulb in the front or rear turn signal lights has not burned
out.
■ If the turn signals stop flashing before a lane change has been per-
formed
Operate the lever again.
■ To discontinue flashing of the turn signals during a lane change
Operate the lever in the opposite direction.
■ When the lever is pushed and held partway
The turn signals will keep flashing until the lever is released.
■ Customization
The number of times the turn signals flash during a lane change can be
changed. (Customizable features →P. 564)
Turn signal lever
Operating instructions
1
2
3
4

4617-3. Do-it-yourself maintenance
7
Maintenance and care
COROLLA_TMMMS_TMMC_U (01999-02509)
Check the wattage of the light bulb to be replaced. (→P. 547)
■Front
Light bulbs
You may replace the following bulb s yourself. The difficulty level
of replacement varies depending on the bulb. If necessary bulb
replacement seems difficult to perform, contact your Toyota
dealer.
For more information about replacing other light bulbs, contact
your Toyota dealer.
Preparing for light bulb replacement
Bulb locations
Front turn signal/parking lights
Front side marker lights1
2

4627-3. Do-it-yourself maintenance
COROLLA_TMMMS_TMMC_U (01999-02509)■
Rear
Back-up lights (bulb type)
Rear turn signal lights
Stop/tail/rear side marker lights
License plate lights1
2
3
4

4647-3. Do-it-yourself maintenance
COROLLA_TMMMS_TMMC_U (01999-02509)■
Front turn signal/parking lights
Turn the bulb base counter-
clockwise.
Remove the light bulb.
When installing, reve rse the steps listed.
1
2
3

4657-3. Do-it-yourself maintenance
7
Maintenance and care
COROLLA_TMMMS_TMMC_U (01999-02509)■
Stop/tail/rear side marker lights and rear turn signal lights
Open the trunk lid and
remove the clips.
To prevent damage to the vehi-
cle, cover the tip of the screw-
driver with a rag.
Partly remove the luggage
trim cover.
Turn the bulb base counter-
clockwise.Rear turn signal light
Stop/tail/rear side marker
light
Remove the light bulb. Rear turn signal light
Stop/tail/rear side marker
light
When installing, reve rse the steps listed.
1
2
3
1
2
4
1
2
5

4687-3. Do-it-yourself maintenance
COROLLA_TMMMS_TMMC_U (01999-02509)■
Replacing the following bulbs
If any of the lights listed below
has burnt out, have it replaced by
your Toyota dealer.
● Headlights/daytime running lights (if equipped)
● Daytime running lights (if equipped)
● High mounted stoplight
● Side turn signal lights (if equipped)
● Back-up lights (LED type)
■LED light bulbs
The headlights, daytime running lights, high mounted stoplight, and
back-up
lights (LED type) consist of a number of LEDs. If any of the LEDs burns out,
take your vehicle to your Toyota dealer to have the light replaced.
■ Condensation build-up on the inside of the lens
Temporary condensation build-up on the inside of the headlight lens does not
indicate a malfunction.
Contact your Toyota dealer for more information in the following situations:
●Large drops of water have built up on the inside of the lens.
● Water has built up inside the headlight.
WARNING
■Replacing light bulbs
● Turn off the lights. Do not attempt to replace the bulb immediately after
turning off the lights.
The bulbs become very hot and may cause burns.
● Do not touch the glass portion of the light bulb with bare hands. When it is
unavoidable to hold the glass portion, use and hold with a clean dry cloth
to avoid getting moisture and oils on the bulb.
Also, if the bulb is scratched or dropped, it may blow out or crack.
● Fully install light bulbs and any parts used to secure them. Failure to do so
may result in heat damage, fire, or water entering the headlight unit. This
may damage the headlights or cause condensation to build up on the lens.
■ To prevent damage or fire
Make sure bulbs are fully seated and locked.

5479-1. Specifications
9
Vehicle specifications
COROLLA_TMMMS_TMMC_U (01999-02509)
*1: Light bulbs not listed in this table are LED bulbs.
*2: If equipped
Light bulbs*1
Light bulbsBulb No.WTy p e
ExteriorFront side marker
lights
W5W 5 B
Front turn signal/park-
ing lights Ty pe A
Ty pe B 7444NA
WY21W 28/8
21 B
Side turn signal
lights*2⎯ 5B
Rear turn signal lights ⎯21 B
Stop/tail and rear side
marker lights 7443 21/5 A
License plate lights ⎯5A
Back-up lights
(bulb
type)
*2921 16 A
Interior Vanity lights
⎯8A
Front personal/inte-
rior lights (vehicles
without a moon roof) ⎯
8A
Front personal/inte-
rior lights (vehicles
with a moon roof) ⎯
5A
Rear interior light ⎯8C
Trunk light ⎯3.8 A
A: Wedge base bulbs (clear)
C: Double end bulbs B: Wedge base bulbs (amber)

598Alphabetical index
COROLLA_TMMMS_TMMC_U (01999-02509)
Emergency flashers ................ 470
Engine....................................... 540ACCESSORY mode ............. 176
Compartment ........................ 429
Engine switch................ 171, 174
Hood ..................................... 425
How to start the engine......................... 171, 174
Identification number ............ 539
If the engine will not start ...... 521
Ignition switch (engine switch) ........... 171, 174
Overheating .......................... 531
Engine coolant ......................... 433
Capacity ................................ 542
Checking ............................... 433
Preparing and checking before winter....................... 263
Engine coolant temperature gauge.................................. 77, 86
Engine immobilizer system ...... 67
Engine oil ................................. 430 Capacity ................................ 540
Checking ............................... 430
Preparing and checking
before winter....................... 263
Engine switch .................. 171, 174
Entune Audio ........................... 273
Audio input ............................ 272
AUX port/USB port ..................................... 272
Bluetooth
® audio................... 320
CD player .............................. 290
iPod....................................... 296
MP3/WMA disc ..................... 290
Optimal use........................... 287
Portable music player ........... 272
Radio .................................... 288
Steering wheel audio
switch ................................. 338
USB memory ........................ 301
Entune Audio Plus
*
Entune Premium Audio*
EPS (Electric Power Steering) ..... 257
Function ................................ 257
Warning light......................... 481
Flat tire Vehicles with a spare tire...... 509
Floor mats .................................. 24
Fluid Brake .................................... 545
Continuously variable
transmission ....................... 544
Washer ................................. 439
Front interior light ................... 385
Front passenger occupant classification system .............. 47
Front seats ............................... 130 Adjustment............................ 130
Cleaning ............................... 411
Correct driving posture ........... 26
Head restraints ..................... 134
Seat heaters ......................... 383
Front turn signal lights ........... 191 Replacing light bulbs ............ 464
Turn signal lever ................... 191
Wattage ................................ 547
Fuel ........................................... 204 Capacity................................ 540
Fuel gauge........................ 77, 86
Fuel pump shut off system ... 479
Information............................ 548
Refueling .............................. 204
Type.............................. 540, 548
Warning light......................... 481
Fuel filler door ......................... 204
Refueling .............................. 204
Fuel pump shut off system..... 479
Fuses ........................................ 458
F

600Alphabetical index
COROLLA_TMMMS_TMMC_U (01999-02509)
JackPositioning the jack ............... 427
Vehicle-equipped jack........... 510
Jack handle .............................. 510
Jam protection function Moon roof.............................. 148
Power window....................... 144
Keyless entry Smart key system ......... 108, 117
Wireless remote
control......................... 108, 118
Keys .......................................... 102
Battery-saving function ......... 124
Electronic key ....................... 102
Engine switch................ 171, 174
If the electronic key does not operate properly ........... 523
Key number plate.................. 102
Keyless entry ........................ 103
Mechanical key ..................... 103
Replacing the battery ............ 455
Warning buzzer..................... 123
Wireless remote control ........ 103
Knee airbags .............................. 34 LATCH anchors ......................... 59
LDA (Lane Departure
Alert with steering
control)................................... 226 Lane departure alert
function............................... 226
Steering control function ....... 227
Vehicle sway warning ........... 227
Lever Auxiliary catch lever.............. 425
Hood lock release lever....................... 425
Shift lever.............. 181, 184, 189
Turn signal lever ................... 191
Wiper lever ........................... 202
License plate lights ................. 193 Light switch ........................... 193
Replacing light bulbs ............ 467
Wattage ................................ 547
Light bulbs
Replacing.............................. 461
Wattage ................................ 547
Lights
Front Interior light ................. 385
Headlight switch ................... 193
Illuminated entry system ....... 386
Interior lights list.................... 384
Personal lights ...................... 385
Rear interior light .................. 386
Replacing light bulbs ............ 461
Trunk light ............................. 119
Turn signal lever ................... 191
Vanity lights .......................... 392
Wattage ................................ 547
Lock steering column ..... 172, 178
J
K
L
