TOYOTA COROLLA 2020 Accessories, Audio & Navigation (in English)

612-3. Other settings
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
2
Basic function
*: Entune Premium Audio only
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Vehicle”.
4 Select the desired items to
be set.
Select to set maintenance.
*1
( P.62)
Select to set vehicle customi-
zation.
*2
Vehicle settings
Settings are available for
maintenance, vehicle cus-
tomization, etc.
Displaying the vehicle
settings screen
Vehicle settings screen
A
B

622-3. Other settings
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
Select to set valet mode.
(P. 6 3 )
Select to set dealer informa-
tion.
*3, 4
*1: Entune Premium Audio only
*2: Refer to the “OWNER’S MAN- UAL”.
*3: Entune Audio Plus with DCM only
*4: This function is not made avail-able in some countries or areas.
*: Entune Premium Audio only
When the system is turned on,
the maintenance reminder
screen displays when it is time
to replace a part or certain com-
ponents. ( P. 2 6 )
1 Display the vehicle settings
screen. ( P.61)
2 Select “Maintenance”.
3 Select the desired item.
The system is set to give
maintenance information with
the maintenance reminder
screen. ( P.26)
Select to set a reminder for a
part or component. ( P. 6 2 ) Select to add a reminder
other than the provided ones.
Select to cancel all reminders
which have been entered.
Select to reset all reminders
which have expired.
Select to call the registered
dealer.
Select to register/edit dealer
information. (
P.63)
●When the vehicle needs to be ser-
viced, the scree n button color will
change to orange.
1 Select the desired part or
component screen button.
2 Set the conditions.
Select to enter the next main-
tenance date.
Select to enter the driving
distance until the next main-
tenance check.
Select to cancel the condi-
tions which have been
entered.
Select to reset the conditions
Maintenance*
C
D
A
B
0DLQWHQDQFHLQIRUPDWLRQ
VHWWLQJ
C
D
E
F
G
A
B
C
D

632-3. Other settings
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
2
Basic function
which have expired.
3 Select “OK” after entering the
conditions.
●For scheduled maintenance infor-
mation, refer to “Scheduled Main-
tenance Guide” or “Owner’s
Manual Supplement”.
●Depending on driving or road con-
ditions, the actual date and dis-
tance that mainte nance should be
performed may differ from the
stored date and distance in the
system.
Dealer information can be regis-
tered in the system. With dealer
information registered, route
guidance to the dealer is avail-
able.
1 Select “Set Dealer”.
2 Select the desired item to
search for the location.
( P. 7 9 )
 The editing dealer screen
appears after setting the loca-
tion.
3 Select the desired items to
be edited.
Select to enter the name of a
dealer. ( P.63) Select to enter the name of a
dealer member. (
P.63)
Select to set the location.
( P.63)
Select to enter the phone
number. ( P.63)
Select to delete the dealer
information displayed on the
screen.
Select to set the displayed
dealer as a destination.
( P.86)
1 Select “Dealer” or “Contact”.
2 Enter the name and select
“OK”.
1 Select “Location”.
2 Scroll the map to the desired
point ( P.72) and select
“Enter”.
1 Select “Phone #”.
2 Enter the phone number and
select “OK”.
The security system can be set
to on by entering a security code
(4-digit number).
Dealer setting
A
(GLWLQJGHDOHURUFRQWDFW
QDPH
(GLWLQJWKHORFDWLRQ
(GLWLQJSKRQHQXPEHU
6HWWLQJWKHY\
DOHWPRGH
B
C
D
E
F

642-3. Other settings
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
When set to on, the system will
become inoperative once the
electrical power source is dis-
connected until the security
code is entered.
1Display the vehicle settings
screen. ( P.61)
2 Select “Valet Mode”.
3 Enter the 4-digit personal
code and select “OK”.
4 Enter the same 4-digit per-
sonal code again and select
“OK”.
 The system will request that
you input the security code
again to confirm that you
remember it correctly.
 When valet mode activates,
the system stops and a secu-
rity code (4-digit number)
standby screen is displayed.
●If the 4-digit personal code is for-
gotten, please contact your Toyota
dealer.
1 Enter the 4-digit personal
code and select “OK”.
●If an incorrect security code
(4-digit number) is entered 6
times, the system will not accept
another security code (4-digit
number) for 10 minutes.
*: Entune Audio Plus with DCM
only. This function is not made
available in some countries or
areas.
Dealer information can be regis-
tered in the system. If the vehi-
cle alert screen is displayed,
selecting the call dealer button
on the screen will call the phone
number registered in the dealer
information.
1 Display the vehicle settings
screen. ( P. 6 1 )
2 Select “Dealer Info”.
3 Select the desired items to
be edited.
Select to enter the name of a
dealer. ( P.65)
Select to enter the name of a
dealer member. ( P.65)
Select to enter the phone
number. ( P.65)
Select to delete the dealer
information displayed on the
screen.
If the valet mode has been
activated
Setting dealer informa-
tion
*
A
B
C
D

652-3. Other settings
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
2
Basic function
1 Select “Edit” next to “Dealer”
or “Contact”.
2 Enter the name and select
“OK”.
1 Select “Edit” next to “Phone
#”.
2 Enter the phone number and
select “OK”.Editing dealer or contact
name
Editing phone number

662-3. Other settings
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)

67
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
3
Navigation system
Navigation system
.3-1. Basic operationNavigation ...................... 68
Map screen operation .... 70
Map screen information . 72
Traffic information .......... 76
3-2. Destination search Destination search opera-tion ............................... 79
Starting route guidance .. 86
3-3. Route guidance Route guidance screen .. 90
Typical voice guidance prompts ........................ 94
Editing route ................... 94
3-4. Setup Navigation settings......... 97
Detailed navigation settings .................................. 102
Traffic settings ............. 105
Use of information accumu- lated by navigation system
.................................. 110
3-5. Tips for the navigation system
GPS (Global Positioning System) ..................... 111
Map database version and covered area ............. 113

683-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3-1.Basic operation
*: Entune Premium Audio only
2D north up, 2D heading up or 3D heading up symbol (P. 7 1 )
Indicates whether the map orientation is set to north-up or hea d-
ing-up. The letter(s) under this symbol indicate the vehicle’s
heading direction (e.g. N for north). In 3D map, only a heading-up
view is available.
Destination button ( P. 7 9 )
Select to display the destination screen.
Map options button ( P.72)
Select to display the map options screen.
Route options button ( P.94)
Select to display the route options screen.
Mute button
Select to mute the voice guidance. When set to on, the indicato r
Navigation*
The navigation system indicates your present position and
assists in locating a desired destination. To display the map
screen, press the “MAP” button.
Map screen overview
A
B
C
D
E

693-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
will illuminate.
Zoom in/out button ( P. 7 0 )
Select to magnify or reduce the map scale. When either button i s
selected, the map scale indicator bar appears at the bottom of the
screen.
Micro city map button ( P. 7 0 )
Select to display the micro city map screen.
Route information bar ( P.90)
Displays the distance with the estimated travel time/arrival time to
the destination. The route information bar fills from left to r ight as
the vehicle progresses on the route.
Delete destination button ( P.22)
Select to delete destinations.
Speed limit icon ( P.72)
Indicates the speed limit on the current road. The display of t he
speed limit icon can be set to on/off.
●When the vehicle i s not receiving
GPS signals, such as when driv-
ing in a tunnel, will be
displayed at the bottom left corner
of the screen.
●Press the “MAP” button to display
the address of the current position
on the map screen or repeat voice
guidance.
F
G
H
I
J

703-1. Basic operation
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
1Press the “MAP” button.
2 Check that the current posi-
tion map is displayed.
 To correct the current posi-
tion manually:  P.104
●While driving, the cu rrent position
mark is fixed on the screen and
the map moves.
●The current position is automati-
cally set as the vehicle receives
signals from the GPS (Global
Positioning System). If the current
position is not correct, it is auto-
matically corrected after the vehi-
cle receives signals from the GPS.
●After the 12-volt battery discon-
nection, or on a new vehicle, the
current position may not be cor-
rect. As soon as the navigation
system receives signals from the
GPS, the correct c urrent position
is displayed.
1 Select or to change
the scale of the map screen.
●The scale indicator bar appears at
the bottom of the screen.
●Select and hold or to con-
tinue changing the scale of the
map screen.
●The scale of the map screen can
also be changed by selecting the
scale bar directly. This function is
not available while driving.
●Pinch outward on the screen to
zoom in and pinch inward to zoom
out.
●In areas where a micro city map is
available, will change to
when the map screen is
set to the smallest scale.
For areas covered by the micro
city map (some major cities), a
micro city map on a scale of 75
ft. (25 m) can be selected.
When the map is scaled down to
150 ft. (50 m), changes to
and can be selected to
display the micro city map.
Map screen operation
Current position display
Map scale
Micro city map
